ROMANCE 28
f i r e - p a r t s . c o m
WARNING: If the information in these
instructions is not followed exactly, a fire or
explosion may result causing property
damage, personal injury or death.
FOR YOUR SAFETY: Do not store or use
gasoline or other flammable vapors and
liquids in the vicinity of this or any other
appliance.
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
THE INSTALLATION MUST BE IN ACCORDANCE WITH LOCAL CODES OR, IN THE
ABSENCE OF LOCAL CODES, WITH THE CURRENT NATIONAL FUEL GAS CODE
ANSI Z223.1 (USA) OR THE CURRENT CAN/CGA B149 INSTALLATION CODES
PLEASE KEEP THIS INSTRUCTIONS MANUAL
OWNER`S MANUAL
(CANADA).
FOR FUTURE REFERENCE
Stove Builder International Inc.,
1700 LÉON-HARMEL, QUÉBEC, (QUÉBEC), CANADA, G1N 4R9
Tel : ( 418 ) 527-3060
Fax : ( 418 ) 527-4311
www.osburn-mfg.com
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electric switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
010517/45042A_feb 03
Advertisement
Table of Contents
Related Manuals for Osburn Romance 28
Summary of Contents for Osburn Romance 28
- Page 1 ROMANCE 28 OWNER`S MANUAL f i r e - p a r t s . c o m WHAT TO DO IF YOU SMELL GAS: WARNING: If the information in these instructions is not followed exactly, a fire or • Do not try to light any appliance.
-
Page 2: Table Of Contents
Direct Vent Installation ............................7 Critical Length of Venting Pipes ........................7 Terminal Vent Location ..........................8 Installation of Osburn Wall Venting Kits ......................9 Vented Gas Stove Installation ("B-Vent")......................11 Critical Length of Venting Pipes ........................11 Stove conversion for a "B-Vent" installation only ..................12 Gas Piping............................... -
Page 3: General Information
ROMANCE 28 STOVE GENERAL INFORMATION The ROMANCE 28 GAS STOVE is a high-efficiency gas appliance with a maximum input rating of 28 500 BTU/h (8,4 kW) with natural gas or 26 000 BTU/h (7,6 kW) with propane. It features an adjustable millivolt valve and a constant pilot independent of any electrical source. -
Page 4: Romance 28 Dimensions
ROMANCE 28 STOVE Romance 28 Dimensions Dimensions Height : 28 po / 712 mm Width : 31 po / 788 mm Depth : 21 1/4 po / 540 mm Ceramic Glass 10 1/4 po x 18 po 260 mm x 457 mm... -
Page 5: Burner
ROMANCE 28 STOVE Burner Natural Gas Propane LP Maximum Input, BTU/h (kW) minimum : 19 000 (5,6) 20 000 (5,9) maximum : 28 500 (8,4) 26 000 (7,6) Inlet Pressure Inch WC (kPa) minimum : (1,3) 11,0 (2,8) maximum :... -
Page 6: Installation
• In Massachusetts the Romance 28 may be installed in a bedroom only when used as a direct vent unit (sealed combustion), no b-vent installation in bedroom or bathroom is allowed. For other states or provinces may be installed in a bedroom provided that all required clearances are met a wall thermostat is installed and where the maximum input is within 50 cubic feet of room volume per 1000 BTU/hr, (i.e.1500... -
Page 7: Clearances To Combustibles
ROMANCE 28 STOVE Clearances to combustibles Clearance between the stove and any combustible material must also be maintained while installing your appliance. CLEARANCE Back (in) Side (in)) Corners (in) Top (in) Front (in) Pipe (in) 1 ½ Note 1 Floor... -
Page 8: Direct Vent Installation
ROMANCE 28 STOVE Direct Vent Installation Critical Length of Venting Pipes The following table shows the maximum length to be respected while installing your appliance with venting pipes (4"X6 5/8") from Simpson Dura- Vent, Security Chimneys International (Secure Vent), or Selkirk (Direct-Temp) only. -
Page 9: Terminal Vent Location
Terminal Vent Location Your Romance 28 stove vents through a vent terminal installed on the roof or on the outside of any exterior wall of your house. Many restrictions apply to the vent terminal location that should be considered before locating your stove. -
Page 10: Installation Of Osburn Wall Venting Kits
ROMANCE 28 STOVE Installation of Osburn Wall Venting Kits Osburn Direct And Corner Vent Kit Installation AC02000: Coaxial 4" X 6 5/8" rigid vent system with black finish includes : 1- 45° Elbow 2- 24" Pipe 3- 90° Elbow 4- 24" Pipe... - Page 11 ROMANCE 28 STOVE Osburn Direct Vent Kit for Basement Installation AC02010: Coaxial 4" X 6 5/8" rigid vent system with black finish includes : 1- 45° Elbow 2- Two 24" Pipes 3- 90° Elbow 4- 24" Pipe 5- Adjustable pipe...
-
Page 12: Vented Gas Stove Installation ("B-Vent")
ROMANCE 28 STOVE Vented Gas Stove Installation ("B-Vent") Instead of using a standard B-vent pipe it is possible to use a 4" flexible aluminum chimney lining system into an existing chimney. The existing chimney must be a code complying masonry or listed fuel burning chimney system: ‘B’... -
Page 13: Stove Conversion For A "B-Vent" Installation Only
Stove conversion for a "B-Vent" installation only The following instructions are not for a direct vent installation. Your Osburn stove is coming to you ready for a direct vent installation. You can buy a conversion kit to be able to install it as a "B-Vent" unit. To convert your stove, just follow the instructions: 1. - Page 14 ROMANCE 28 STOVE 4. Remove discard metallic plate (6) from the rear heat shield using a flat screw driver. Unscrew just a little bit the two screws located each side of the chimney connector. Install the venting hood (5) by sliding it into place.
-
Page 15: Gas Piping
ROMANCE 28 STOVE Gas Piping • Route a 3/8" minimum NPT iron pipe gas line to the desired location. • Install a shutoff valve to the gas line. Tighten securely using a pipe joint compound. • Check the gas line piping for leaks. Use a soap and water solution. -
Page 16: Ember Kit Installation
ROMANCE 28 STOVE Ember Kit Installation CAUTION: Blocking gas ports with rock wool will result in poor light-up performance, delayed ignition, affect flame aspect and form carbon deposit on logs. 1. Place some pieces of rock wool fibers approximately 1/2" large behind the front gas ports. -
Page 17: Operating Your Stove
ROMANCE 28 STOVE OPERATING YOUR STOVE For your safety ATTENTION : • A QUALIFIED INSTALLER MUST PERFORM INSTALLATION OF THE APPLIANCE VENTING PIPING AND ADJUSTMENTS • D URING OPERATION THIS STOVE IS HOT O NOT TOUCH EEP CHILDREN CLOTHING FURNITURE AND FLAMMABLE MATERIALS AWAY •... -
Page 18: Shut Down Instructions
50 pi 12GA To use your Romance 28 with the wall thermostat, follow the lighting procedure and set the gas control to the ON position. Simply set your wall thermostat to a comfortable temperature and the stove will do the rest. -
Page 19: The Benefits Of Installing A Blower
The benefits of installing a blower A blower can be installed at the back of your OSBURN stove. This option is necessary if you wish to redistribute into a room the heat trapped at the back of your stove. By forcing hot air toward the front, the blower enables you to extend the radiation power of your stove. -
Page 20: Optional Thermodisc (Ac05530)
ROMANCE 28 STOVE Optional Thermodisc (AC05530) Follow the installation instructions included with the optional thermodisc. The fixation holes are located at the back of the stove on the lower right corner. Refer to the drawing on this page. Note : The blower will start when the... -
Page 21: Maintenance Instructions
When replacing the glass, you should change the glass gasket to make sure you keep it sealed. • If the gasket is damaged, replace it with an identical one. To get a new gasket, refer to your Osburn dealer. -
Page 22: Burner
ROMANCE 28 STOVE Burner Removing the Burner • Open the glass door. Remove the burner contour (2) and the deflector (3). Unscrew the two screws on each side of the burner (1). • Slide the burner out from the venturi towards the left. Get it out from the stove. -
Page 23: Options
ROMANCE 28 STOVE OPTIONS DESCRIPTION PART # Millivolt Wall Thermostat AC05558 Tangential blower with variable speed control AC02050 Direct Vent Kit and Corner Installation AC02000 Direct Vent Kit Basement Installation AC02010 REMPLACEMENT PARTS DESCRIPTION PART # 5 logs set AC05791... -
Page 24: Limited Warranty
