Osburn Inspire 2000 OA10243 Installation Instructions Manual

Minimalist base kit

Advertisement

Quick Links

Instructions d'installation
ensemble de base minimaliste
Installation Instructions
Minimalist Base Kit
- INSPIRE 2000 -
OA10243
Imprimé au Canada
45969AF
Printed in Canada
2018-11-26

Advertisement

loading
Need help?

Need help?

Do you have a question about the Inspire 2000 OA10243 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Osburn Inspire 2000 OA10243

  • Page 1 Instructions d’installation ensemble de base minimaliste Installation Instructions Minimalist Base Kit - INSPIRE 2000 - OA10243 Imprimé au Canada 45969AF Printed in Canada 2018-11-26...
  • Page 2 L’INSTALLATION DE LA BASE MINIMALISTE NE CONFÈRE PAS AU POÊLE LE STATUT D’ENCASTRABLE. IL EST DONC INTERDIT DE L’INSTALLER DANS UN ÂTRE DE MAÇONNERIE. THE INSTALLATION OF THE MINIMALIST BASE DOES NOT GIVE THE STOVE THE INSERT STATUS. IT IS THEREFORE FORBIDDEN TO INSTALL IT IN A MASONRY HEARTH.
  • Page 3 1. Application / Application Cet ensemble de base minimaliste est conçu pour être installé sur le poêle à bois Inspire 2000. Cet ensemble comprend un système de fixation pour le poêle ainsi qu’un ensemble d’entrée d’air frais. This minimalist base kit is designed to be installed on an Inspire 2000 wood stove. This kit includes a mounting system for the stove and a fresh air intake kit.
  • Page 4 3. Contenu de l’ensemble / Kit Contents Joint d’étanchéité / Gasket Plaque / Plate Cordon préencollé / Self-adhesive (J) 1x (K) 1x gasket (N) 5,5 pi. Boîtier d’entrée d’air frais / Fresh air Écrou / Nut Vis / Screw intake housing (H) 8x (F) 6x (O) 1x...
  • Page 5 4. Outils requis / Required Tools ou / or Visseuse embout Robertson Ciseaux / Cissors Clé à cliquet embout Torx Tournevis Robertson ou ou Phillips #2 / Robertson or #30 / Ratchet with Torx bit Phillips #2 / Robertson or Phillips bit driver #2 Phillips screwdriver #2 Clé...
  • Page 6 Pour alléger le poids du poêle, retirer les briques (D), les espaceurs (C) et le bouchon à cendres (E). / To lighten the weight of the stove remove the bricks (D), the spacers (C) and the ash plug (E). Retirer les 4 boulons (F), les 4 écrous (H) et la plaque du bouchon (G). / Remove the four bolts (F), the four nuts (H) and the ash plug plate (G).
  • Page 7 Coller le joint d’étanchéité (J) sur la plaque Couper le cordon préencollé (N) aux bonnes (K). / Stick the gasket (J) on the plate (K). dimensions et l’installer sur les rebords du boîtier d’entrée d’air frais (O). / Cut to length the self-adhesive gasket (N) and install it on the fresh air intake housing (O).
  • Page 8 Retirer les deux vis (M) ainsi que le panneau décoratif (L) de chaque côté. / Remove both screws (M) and the decorative panel (L) on both sides. Soulever le poêle et le déposer sur le boîtier d’entrée d’air (O). / Lift the stove and put it on the air intake housing (O).
  • Page 9 Visser l’arrière du boîtier (O) sur le poêle avec 2 vis (P). Fix the back of the air intake housing (O) to the stove with 2 screws (P). 10. Visser l’avant du boîtier (O) sur le poêle avec 2 vis (P). Fix the front of the air intake housing (O) to the stove with 2 screws (P).
  • Page 10 11. Fixer le couvercle du contrôle d’air (Q) sur le poêle avec deux vis (P). Centrer l’ouverture avec la tige. / Fix the air control cover (Q) on the stove with two screws (P). Center the opening with the rod. 12.
  • Page 11 13. Soulever le poêle et installer les boulons élévateurs (T). / Lift the stove and install the 4 leveling bolts (T). 14. Remettre les deux vis (M) ainsi que le panneau décoratif (L) de chaque côté. / Put back both screws (M) and the decorative panel (L) on both sides.
  • Page 12 15. Remettre les briques (D), les espaceurs (C) et le panneau décoratif (A). / Put back the bricks (D), the spacers (C) and the decorative panel (A). 16. Installer la brique du centre (U). / Install the center brick (U) Page...
  • Page 13 17. Fixer le poêle sur la base avec deux vis appropriées pour le type de base utilisé. / Fix the stove on the base with 2 appropriate screws for the type of material used for the base. Page...
  • Page 14 NOTES : Page...
  • Page 16 Stove Builder International Inc. Fabricant de poêles International inc. 250, rue de Copenhague, 250, rue de Copenhague, St-Augustin-de-Desmaures (Québec) Canada St-Augustin-de-Desmaures (Québec) Canada G3A 2H3 G3A 2H3 418-908-8002 418-908-8002 https://www.osburn-mfg.com/en/ www.osburn-mfg.com tech@sbi-international.com tech@sbi-international.com...
