- Page 1 4x4 HDTV Matrix U S E R M A N U A L www.gefen.com...
- Page 2 Chatsworth CA 91311 www.gefen.com support@gefen.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. The 4x4 HDTV Matrix is a trademark of Gefen Inc.
-
Page 3: Table Of Contents
Introduction / Operation Notes Features Panel Layout Using the 4x4 HDTV Matrix RMT16-IR Installation Dip Switch Guidelines IR Codes RS-232 Interface 4x4 HDTV Matrix Rack Mount Diagram Specifi cations Terminology Warranty TABLE OF CONTENTS... -
Page 4: Introduction / Operation Notes
Thank you for purchasing the 4x4 HDTV Matrix. The 4x4 HDTV Matrix switches four HDTV sources to any four DVI displays. The 4x4 HDTV Matrix switcher has four DVI inputs and four DVI outputs. Matrix input #1 and the DVI port of source #1 connects using a male to male DVI cable. The DVI port of source #2 connects to DVI input #2. -
Page 5: Features
FEATURES Features • Allows any DVI/HDMI display to view any source at any time • Allows any source to be displayed on multiple displays at the same time • Maintains resolutions up to 1080p, 2K, and 1920x1200 • Maintains highest DVI single link video resolution •... -
Page 6: Panel Layout
PANEL LAYOUT... -
Page 7: Using The 4X4 Hdtv Matrix
USING THE 4X4 HDTV MATRIX Connect all the sources to the HDMI inputs on the 4x4 HDTV Matrix, using the supplied cables. Connect the HDMI/DVI displays to the outputs on the 4x4 HDTV Matrix. Connect the 24VDC powersupply to the 4x4 HDTV Matrix Controlling the 4x4 HDTV Matrix using the RMT16-IR: Pressing Buttons... -
Page 8: Rmt16-Ir Installation
RMT16-IR Installation 1. Remove battery cover from the back of the RMT16-IR remote. 2. Verify that dip switches 1 & 2 are in the down (OFF) position. 3. Insert the battery, hold the battery so that you can see the positive side facing up. The side that is not marked must be facing down. -
Page 9: Dip Switch Guidelines
To access the Dip Switches, remove all screws from the bottom and sides of the Gefen unit. Remove the hex screw heads from each side of the RS-232 and DVI ports. Carefully slide the unit apart. The 8 Bank of Dip Switches are located on the main PCB. -
Page 10: Ir Codes
In the event of IR confl icts, please do the following: 1. Remove the battery cover from the back of the RMT16-IR remote. 2. Locate the Dip Switches above the batteries 3. Switch the Dip Switches on the RMT16-IR to any of the combinations pictured below. 4. -
Page 11: Rs-232 Interface
Binary Table ASCII Corresponding RMT16-IR Button Additional control of the EDID modes and IR channel are possible using the RS-232 interface. For any of these modes to be successfully written to the EEPROM, all Dip Switches must be in the OFF position. ASCII EDID Mode OK is printed out on screen when a mode has successfully been changed. -
Page 12: 4X4 Hdtv Matrix Rack Mount Diagram
4x4 HDTV MATRIX RACK MOUNT DIAGRAM... -
Page 13: Specifi Cations
SPECIFICATIONS Video Amplifi er Bandwidth ... 1.65 Gbps Input Video Signal ... 1.2 volts p-p Input DDC Signal ... 5 volts p-p (TTL) Single Link Range ...1080p / 1920 x 1200 DVI Input/Output Connector ...DVI-D Remote Control Port ... RS-232 Female, Mini-Stereo Power Consumption ... -
Page 14: Terminology
TERMINOLOGY Short form for Display Data Channel. It is a VESA standard for communication between a monitor and a video adapter. Using DDC, a monitor can inform the video card about its properties, such as maximum resolution and color depth. The video card can then use this information to ensure that the user is presented with valid options for confi...
