4x4 HDMI Matrix U S E R M A N U A L www.gefen.com...
Page 2
Chatsworth, CA 91311 www.gefen.com support@gefen.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. The 4x4 HDMI Matrix is a trademark of Gefen Inc.
Thank you for purchasing the 4x4 HDMI Matrix. The 4x4 HDMI Matrix switches four HDTV sources to any four HDMI displays. The 4x4 HDMI Matrix switcher has four HDMI inputs and four HDMI outputs. Matrix input #1 and the HDMI port of HDTV source #1 connects using a male to male HDMI cable. The HDMI port of HDTV source #2 connects to HDMI input #2.
FEATURES Features • Allows any HDMI display to view any source at any time • Allows any source to be displayed on multiple displays at the same time • Maintains resolutions up to 1080p, 2K, and 1920x1200 • Maintains highest HDMI single link video resolution •...
USING THE 4X4 HDMI MATRIX Connect all the sources to the HDMI inputs on the 4x4 HDMI Matrix, using the supplied cables. Connect the HDMI/DVI displays to the outputs on the 4x4 HDMI Matrix. Connect the 24VDC power supply to the 4x4 HDMI Matrix Controlling the 4x4 HDMI Matrix using the RMT16-IR: Pressing Buttons...
RMT16-IR INSTALLATION 1. Remove battery cover from the back of the RMT16-IR remote. 2. Verify that dip switches 1 & 2 are in the down (OFF) position. 3. Insert the battery, hold the battery so that you can see the positive side facing up. The side that is not marked must be facing down.
1, 2, and 5. Please refer below for the different EDID modes. To access the Dip Switches, remove all screws from the bottom and sides of the Gefen unit. Remove the hex screw heads from each side of the RS-232 port and above each HDMI connector.
In the event of IR confl icts, please do the following: 1. Remove the battery cover from the back of the RMT16-IR remote. 2. Locate the Dip Switches above the batteries 3. Switch the Dip Switches on the RMT16-IR to any of the combinations pictured below. 4.
Binary Table ASCII Corresponding RMT16-IR Button Additional control of the EDID modes and IR channel are possible using the RS-232 interface. For any of these modes to be successfully written to the EEPROM, all Dip Switches must be in the OFF position. ASCII EDID Mode OK is printed out on screen when a mode has successfully been changed.
SPECIFICATIONS Video Amplifi er Bandwidth ... 1.65 Gbps Input Video Signal ... 1.2 volts p-p Input DDC Signal ... 5 volts p-p (TTL) Single Link Range ...1080p / 1920 x 1200 HDMI Input/Output Connector ... Type A 19-pin Female Remote Control Port ... RS-232 Female, Mini-Stereo Power Consumption ...
TERMINOLOGY Short form for Display Data Channel. It is a VESA standard for communication between a monitor and a video adapter. Using DDC, a monitor can inform the video card about its properties, such as maximum resolution and color depth. The video card can then use this information to ensure that the user is presented with valid options for confi...
