- Page 1 4x4 DVI / HDTV Matrix U S E R M A N U A L www.gefen.com...
- Page 2 Chatsworth, CA 91311 www.gefen.com support@gefen.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. The 4x4 DVI Matrix is a trademark of Gefen Inc.
-
Page 3: Table Of Contents
Introduction Operation Notes Back Panel Layout Back Panel Descriptions Wiring Diagram Warranty TABLE OF CONTENTS... -
Page 4: Introduction
INTRODUCTION Thank you for purchasing the 4x4 DVI Matrix The 4x4 DVI Matrix switches four computers (PC or MAC) to any four DVI digital displays with USB keyboard and mouse. The 4x4 DVI Matrix switcher has four DVI inputs and four DVI outputs. Matrix input#1 and the graphics port of Computer #1 connects using a male to male DVI cable. -
Page 5: Operation Notes
OPERATION NOTES READ THESE NOTES BEFORE IN STALL ING OR OPERATING THE 4X4 DVI/HDTV MATRIX • The 4x4 HDTV Matrix is the same as the 4x4 DVI Matrix, but the USB may or may not be functional • You should connect all the cables and power supply prior to connecting power to the computers and 4x4 DVI Matrix •... -
Page 6: Back Panel Layout
BACK PANEL LAYOUT... -
Page 7: Back Panel Descriptions
BACK PANEL DESCRIPTIONS 24VDC - Connect to 12-24VDC power supply. Remote - 2 wire serial remote control RMT4 - RJ45 connector connects to the ex•tend•it RMT-4 remote control. Each RMT-4 controls one of the outputs by switching to one of the inputs. USB In - USB input from each source (computer). -
Page 8: Wiring Diagram
WIRING DIAGRAM... - Page 9 USING THE 4X4 DVI MATRIX Connect all the computers to DVI In and USB In on the 4x4 DVI Matrix, using the supplied cables. DVI In 1 and USB In 1 must be connected to the same computer, all the other inputs must connect the same way. Connect the USB devices and DVI displays to the outputs on the 4x4 DVI Matrix using the supplied cables.
-
Page 10: Warranty
Gefen Inc. warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen Inc. is notifi ed within two (2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
