  • Page 1 60Hz, 4:2:0 8x8 Matrix for HDMI GTB-HD4K2K-848-BLK User Manual Release A5...
  • Page 2 Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this unit near water. Clean only with a dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
  • Page 3 Gefen warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen is notified within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifications.

  • Page 4: Technical Support

    Technical Support (818) 772-9100 (800) 545-6900 8:00 AM to 5:00 PM Monday - Friday, Pacific Time (818) 772-9120 Email support@gefen.com http://www.gefen.com Mailing Address Gefen, LLC c/o Customer Service 20600 Nordhoff St. Chatsworth, CA 91311 Product Registration Register your product here: http://www.gefen.com/kvm/Registry/Registration.jsp...
  • Page 5 4K Ultra HD 8x8 Matrix for HDMI is a trademark of Gefen, LLC. © 2015 Gefen, LLC. All Rights Reserved. All trademarks are the property of their respective owners. Gefen, LLC reserves the right to make changes in the hardware, packaging, and any accompanying documentation without prior written notice.
  • Page 6 Licensing This product uses software that is subject to open source licenses, including one or more of the General Public License Version 2 and Version 2.1, Lesser General Public License Version 2.1 and Version 3, BSD, and BSD-style licenses. Distribution and use of this product is subject to the license terms and limitations of liability provided in those licenses.
  • Page 7 RS-232 Serial interface for remote control via a computer or automation control system • IP control via Telnet, UDP, and the built-in web server interface • IR remote control • Gefen Syner-G™ software’s Discovery and Show-Me features simplify initial IP configuration • Field-upgradeable firmware via web server interface • Surface-mountable CINEMA...

  • Page 8: Packing List

    Packing List The 4K Ultra HD 8x8 Matrix for HDMI ships with the items listed below. If any of these items are not present in the box when you first open it, immediately contact your dealer or Gefen. • 1 x 4K Ultra HD 8x8 Matrix for HDMI •...
  • Page 9 This page left intentionally blank.

  • Page 10: Table Of Contents

    Table of Contents Getting Started Introduction......................2 Matrix ......................2 IR Remote Control ..................5 Installing the IR Remote Battery ..............7 Setting the IR Remote Channel ..............7 Installation ......................8 Connection Instructions ................. 8 Sample Wiring Diagram ................9 Basic Operation Routing Basics ....................
  • Page 11 Table of Contents Manage EDID > Assign ................116 Manage EDID > Bank Names ..............119 Manage EDID > Upload/Download ............120 Configuration > Change IP Settings ............122 Configuration > Telnet Login Settings ............123 Configuration > UDP Connection Settings ..........124 Configuration >...
  • Page 12 This page left intentionally blank.

  • Page 13: Getting Started

    4K Ultra HD 8x8 Matrix for HDMI Getting Started...

  • Page 14: Introduction

    Introduction Page Title Matrix Power Lock Power In - In + Out - Out + Lock Menu Power Lock Power In - In + Out - Out + Lock Menu 4K Ultra HD 8x8 Matrix for HDMI 4K Ultra HD 8x8 Matrix RS-232 IR Ext...
  • Page 15 Introduction Page Title page | 3...
  • Page 16 RS-232 Connect an RS-232 cable from this port to the automation device. IR Ext Connect an IR extender (Gefen part no. EXT-RMT-EXTIRN) to this port. This mini-USB port is used for upgrading the firmware. IP Control Connect a CAT-5e cable (or better) from this port to the network.

  • Page 17: Ir Remote Control

    Introduction IR Remote Control Name Description Activity indicator This LED will be activated momentarily each time an input or output button is pressed. Input buttons Press these buttons to select an input (1 - 8). Output buttons Press these buttons to select an output (A - H).
  • Page 18 Introduction P/N: RMT-848IRN www.gefen.com Name Description DIP switch bank Use these DIP switches to set the IR channel of the remote. See the next page for more information. Primary battery slot Holds the battery for operating the remote. (shown without battery) Use only 3V CR2032-type batteries.

  • Page 19: Installing The Ir Remote Battery

    Setting the IR Remote Channel P/N: RMT-848IRN In order for the included IR remote control to communicate with the 4K Ultra HD 8x8 Matrix www.gefen.com for HDMI, the IR remote control must be set to the same channel as the matrix. Use the #set_ir command to set the IR channel of the matrix.

  • Page 20: Installation

    RS-232 Connect an RS-232 cable from the RS-232 port on the matrix to the RS-232 connector on the automation controller. ► Connect an IR extender (Gefen part no. EXT-RMT-EXTIRN) to the IR Ext port on the matrix. Power ► Connect the included power supply to the 24V DC power receptacle on the matrix.

  • Page 21: Sample Wiring Diagram

    HDMI CABLE DB-9 CABLE CAT-5 CABLE IR EXTENDER 4K Ultra HD Source Units with HDMI Outputs (for IP Control) EXT-RMT-EXTIRN IR Extender GTB-HD4K2K-848-BLK 4K Ultra HD 8x8 Matrix for HDMI RS-232 Controller 4K Ultra HD Displays with HDMI Inputs GTB-HD4K2K-848-BLK...
  • Page 22 This page left intentionally blank.

  • Page 23: Basic Operation

    4K Ultra HD 8x8 Matrix for HDMI Basic Operation...

  • Page 24: Routing Basics

    This display shows the current routing status of the matrix and is also used to display additional system information. When the unit is powered on, the following screen is displayed: GEFEN 8x8 HDMI MATRIX After a few moments, the status screen is displayed. The status screen is shown below:...

  • Page 25: Determining The Current Routing State

    Routing Basics Determining the Current Routing State In the example below, the first row (OUT) represents each HDMI output on the matrix. The bottom row (IN) represents each HDMI input on the matrix. Together, these two rows display the current routing state. Starting on the bottom row, we can see that Input 3 has been routed to Outputs A, B, C, and D.

  • Page 26: Selecting Sources And Outputs

    Fundamentals Selecting Sources and Outputs Press the Out - or Out + button once. The routing state for Output A will be displayed. Power OUT:A Lock IN:1 Power In - In + Out - Out + Lock Menu Out buttons Press the Out - or Out + button again to cycle through the routing state for each output.
  • Page 27 Fundamentals Consecutively pressing the Out - button will cycle through each output, from right to left, starting with Output H. Power OUT: Lock Power In - In + Out - Out + Lock Menu Once the desired output has been selected, press the In + or In - button. Consecutively pressing the In - button will decrement the input source value by a factor of 1 (within a range of 1 - 8).
  • Page 28 Fundamentals Consecutively pressing the In + button will increment the input source value by a factor of 1 (within a range of 1 - 8). For example, if Input 6 was originally routed to Output G, then pressing the In + button will route Input 7 to Output G. Power OUT: Lock...

  • Page 29: Locking The Matrix

    Fundamentals Locking the Matrix To prevent an accidental routing change or power-down (by pressing the Power button), the front-panel buttons on the 4K Ultra HD 8x8 Matrix for HDMI can be locked. Locking the matrix also disables several RS-232 / Telnet commands. Press the Lock button on the front-panel.

  • Page 30: Fast Switching Technology

    Fast Switching Technology WITCHING ECHNOLOGY Fast Switching Technology (FST) is a Gefen software implementation for HDMI products. FST was created to improve the lengthy HDMI authentication process, based on the HDMI and HDCP specifications. FST provides quicker audio/video source switching and greatly improves the overall audio/ video system behavior and performance when more than one display is used in the system setup.

  • Page 31: Fast / Slow Switching Modes

    Fundamentals Fast / Slow Switching Modes Each HDMI input can be set to fast mode or slow mode. It is recommended that each HDMI input be set to fast mode for best performance. Consecutively press the Menu button on the front panel until the switching mode screen is displayed.
  • Page 32 Fundamentals Press the Out - button to move to the left, through each input. Power Lock MODE: Power In - In + Out - Out + Lock Menu Once the desired input has been selected, press the In + or In - button to toggle between fast or slow switching mode.

  • Page 33: Ir Control

    IR Control Setting the IR Channel In order for the 4K Ultra HD 8x8 Matrix for HDMI to communicate with the included IR Remote Control, both the matrix and the IR Remote Control must be set to the same IR channel. Refer Setting the IR Remote Channel (page 7) for instructions on setting the IR channel for the included IR remote control unit.
  • Page 34 IR Control After setting the IR address, make sure that the DIP switches on the IR Remote Control are set according to the information in the LCD display. Power IR ADDRESS : 1 Lock 1 - ON , 2 - OFF Power In - In +...

  • Page 35: Using The Ir Remote

    IR Control Using the IR Remote Buttons 1- 8 on the IR remote control correspond to each HDMI input (Input 1 - 8) on the Matrix. Buttons A - H correspond to each HDMI output (Output A - H). To route a source to a display, press the desired output first, then press the input.
  • Page 36 IR Control After the input and output have been selected on the IR Remote Control, the numbers on the far right-hand of the LCD display will disappear and the new routing state will be displayed in the LCD display. Power OUT:ABCDEFGH Lock IN:12445678...

  • Page 37: Using The Ir Extender

    There may be situations where the IR sensor is blocked by a cabinet or other mounting device. In this case, an IR extender (Gefen part no. EXT-RMT-EXTIRN) can be connected to the IR Ext port on the matrix. The sensor on the IR extender behaves exactly like the sensor on the top panel of the matrix.

  • Page 38: Edid Management

    EDID Management External EDID Management The 4K Ultra HD 8x8 Matrix for HDMI features EDID Management. Before the source can send video or audio signals, the source device reads the EDID (Extended Display Identification Data) from the output devices connected to the matrix. The EDID contains information about what type of audio/video data that the source can send to each output device.
  • Page 39 This page left intentionally blank.
  • Page 40 This page left intentionally blank.

  • Page 41: Advanced Operation

    4K Ultra HD 8x8 Matrix for HDMI Advanced Operation...

  • Page 42: Ip Configuration

    When using the IP to 2 x RS-232 Converter for the first time, it is recommended that the unit be configured using the Gefen Syner-G™ Software Suite. The Gefen Syner-G™ Software Suite is free software that is available from the Gefen Web site. Download and install the Gefen Syner-G™ Software Suite. Download the application here: http://www.gefen.com/synerg/...
  • Page 43 IP Configuration Under the Device Settings section, enter the desired IP address, subnet mask, gateway IP address, Web GUI port, and Telnet port in the supplied fields. If desired, the Description field can be changed as well. This is useful to identify if you have multiple units running on a network.

  • Page 44: Rs-232 Configuration

    RS-232 Configuration RS-232 Interface DE-9 DA-15 RS-232 Controller Matrix DB-25 Only TXD, RXD, and GND pins are used. DC-37 RS-232 Settings Description Setting 19200 Baud rate DD-50 Data bits None Parity Stop bits None Hardware flow control Important When sending Telnet or RS-232 commands, a carriage return (0d) and a line feed (0a) must be included at the end of the command.

  • Page 45: Commands

    Commands Command Description #display_telnet_welcome Enables or disables the Telnet welcome message #echo Enables or disables command feedback #fadefault Sets the unit to factory-default settings #hdcp Enables or disables HDCP on an input #help Displays the help list #hpd_pulse Sends an HPD pulse to the selected output #ipconfig Displays the IP configuration of the matrix #lock_edid...
  • Page 46 Commands Command Description #show_hdcp Displays the HDCP state of the specified input #show_hpd Displays the HPD state of the specified input #show_http_port Displays the HTTP listening port #show_input_name Displays the name of the specified input #show_ip Displays the IP address of the matrix #show_ir Displays the IR channel of the matrix #show_mac_addr...
  • Page 47 Commands #display_telnet_welcome Enables / disables the Telnet welcome message during a Telnet session. Syntax #display_telnet_welcome Parameters param1 Integer [0 ... 1] Value Description Disable welcome message Enable welcome message Example #display_telnet_welcome 1 TELNET WELCOME SCREEN IS ENABLED page | 35...
  • Page 48 Commands #echo Enables / disables (toggles) the RS-232 feedback. Syntax #echo param1 Parameters param1 Integer [0 ... 1] Value Description Disable feedback Enable feedback Example #echo 1 LOCAL ECHO IS ON page | 36...
  • Page 49 Commands #fadefault Resets the matrix to factory-default settings. Outputs are unmasked and all IP and UDP settings are reset to default settings. Syntax #fadefault Parameters None Example #fadefault Related Commands #resetip page | 37...
  • Page 50 Commands #hdcp Enables / disables HDCP detection on the selected input. Syntax #hdcp param1 Parameters param1 Integer [0 ... 1] Value Description Disable HDCP Enable HDCP Example #hdcp 4 0 INPUT 4 HDCP IS DISABLE Related Commands #show_hdcp page | 38...
  • Page 51 Commands #help Displays the list of available RS-232 / Telnet commands. Help on a specific command can be displayed when using param1. Syntax #hdcp param1 Parameters param1 Integer [0 ... 1] Example #help #sipadd #SIPADD PARAM 1 SET THE IP ADDRESS PARAM 1 = XXX.XXX.XXX.XXX WHERE XXX: 0 - 255 page | 39...
  • Page 52 Commands #hpd_pulse Cycles the HPD line on the specified input. Issuing this command is identical to physically disconnecting and reconnecting the cable between the source and the matrix. If param1 = 0, then all inputs will receive the HPD pulse Syntax #hpd_pulse param1 Parameters...
  • Page 53 Commands #ipconfig The #ipconfig command displays the current TCP settings. Syntax #ipconfig Parameters None Example #ipconfig IP Configuration is : IP: 10.5.64.247 NETMASK: 255.255.0.0 GATEWAY: 10.5.64.1 Related Commands #resetip #sgateway #show_netmask #sipadd #snetmask page | 41...
  • Page 54 Commands #lock_edid Secures the Local EDID by disabling the automatic loading of the downstream EDID when the matrix is powered. Syntax #lock_edid param1 Parameters param1 Integer [0 ... 1] Value Description Disable Enable Example #lock_edid 1 MATRIX EDID IS LOCKED Related Commands #set_edid page | 42...
  • Page 55 Commands #lock_matrix Locks or unlocks the matrix. When the matrix is locked, all functions are disabled including the front panel, RS-232, and Telnet. Syntax #lock_matrix param1 Parameters param1 Integer [0 ... 1] Value Description Unlock Lock Example #lock_matrix 1 MATRIX IS LOCKED page | 43...
  • Page 56 Commands #mask Masks the video on the specified output(s). If param1 = 0, then all outputs are masked. Use the #unmask command to disable output masking. Syntax #mask param1 Parameters param1 Integer / Character [0, A ... H] Examples #mask A F G OUTPUTS A, F, G ARE MASKED #mask 0 ALL OUTPUTS ARE MASKED...
  • Page 57 Commands #power Powers ON or OFF the matrix. Syntax #power param1 Parameters param1 Integer [0 ... 1] Value Description Power OFF Power ON Example #power 1 Related Commands #reboot page | 45...
  • Page 58 Commands #reboot Reboots the matrix. Executing this command is the equivalent of cycling power on the matrix. The matrix must be rebooted after changing any of the IP settings Syntax #reboot Parameters None Example #reboot MATRIX WILL REBOOT SHORTLY *REBOOT UNIT IN 2 SECONDS Related Commands #power page | 46...
  • Page 59 Commands #recall_preset Loads the specified routing preset. Syntax #recall_preset Parameters None Example #recall_preset 2 RECALLED THE ROUTING STATE OF PRESET 2 Related Commands #save_preset #set_preset_name #show_preset_name page | 47...
  • Page 60 Commands #resetip Resets the IP configuration to factory-default settings. The matrix must be rebooted after executing this command. Syntax #resetip Parameters None Example #resetip Related Commands #fadefault page | 48...
  • Page 61 Commands #save_preset Saves the current routing state to the specified preset. Syntax #save_preset param1 Parameters param1 Integer [1 ... 8] Example #save_preset 2 CURRENT ROUTING STATE IS SAVED TO PRESET 2 Related Commands #recall_preset #set_preset_name #show_preset_name page | 49...
  • Page 62 Commands #set_bank_name Assigns a name to the specified bank. Syntax #set_bank_name param1 param2 Parameters param1 Integer [1 ... 8] param2 String Example #set_bank_name 5 SonyXBR SonyXBR NAME IS ASSIGNED TO BANK 5 Related Commands #show_bank_name page | 50...
  • Page 63 Commands #set_device_descr Assigns a name to the matrix. The description cannot exceed 30 characters in length Syntax #set_device_descr param1 Parameters param1 String Example #set_device_descr 8x8Matrix DEVICE DESCRIPTION NAME IS SET TO 8x8Matrix Related Commands #show_device_descr page | 51...
  • Page 64 Commands #set_edid Sets the specified EDID type to an input or bank. If param1 = default or param1 = dynamic, then set param2 = 0. Syntax #set_edid param1 param2 param3 param4 Parameters param1 String param1 Description default Use default EDID dynamic Use dynamic EDID bank...
  • Page 65 Commands When param1 = dynamic, the specified input will be set to Dynamic EDID. This can be observed by accessing the Manage EDID tab, in the Web interface. When an input is set to Dynamic EDID, the input will use the EDID of the last selected output during the routing process.
  • Page 66 Commands #set_http_port Specifies the Web server listening port. The matrix must be rebooted after executing this command. The default port setting is 80. Use the #show_http_port command to display the current HTTP listening port. Syntax #set_http_port param1 Parameters param1 Integer [1 ...
  • Page 67 Commands #set_input_name Assigns a name to the specified input. Syntax #set_input_name param1 param2 Parameters param1 Integer [1 ... 8] param2 String Example #set_input_name 3 Blu-ray Blu-ray NAME IS ASSIGNED TO INPUT 3 Related Commands #set_output_name #show_input_name #show_output_name page | 55...
  • Page 68 Commands #set_ir Sets the IR channel for the matrix. The default IR channel setting is 0. The IR channel for the switch can also be set under the Configuration tab within the Web interface. Configuration > System Configuration for more information. Syntax #set_ir param1 Parameters...
  • Page 69 Commands #set_output_name Assigns a name to the output on the matrix. The name of the output is limited to 15 characters. Names longer than 15 characters will be truncated. To name an output, use #set_output_name command. Syntax #set_output_name param1 param2 Parameters param1 Character...
  • Page 70 Commands #set_preset_name Assigns a name to the specified preset. The name of the preset is limited to 8 characters. To display the name of a preset, use the #show_preset_name command. Syntax #set_preset_name param1 param2 Parameters param1 Integer [1 ... 8] param2 String Example...
  • Page 71 Commands #set_telnet_pass The #set_telnet_pass command sets the Telnet password. The password is case-sensitive and cannot exceed 8 characters in length. The default password is Admin. Syntax #set_telnet_pass param1 Parameters param1 String Example #set_telnet_pass 3v3r3st TELNET Interface Password Is Set. page | 59...
  • Page 72 Commands #set_telnet_port The #set_telnet_port command sets the Telnet listening port. The matrix must be rebooted after executing this command. The default port setting is 23. Use the #show_telnet_port command to display the current Telnet listening port. Syntax #set_telnet_port param1 Parameters param1 Integer [1 ...
  • Page 73 Commands #set_udp_port The #set_telnet_port command sets the Telnet listening port. The matrix must be rebooted after executing this command. The default port setting is 23. Use the #show_telnet_port command to display the current Telnet listening port. Syntax #set_udp_port param1 Parameters param1 Integer [1 ...
  • Page 74 Commands #set_udp_remote_ip Sets the remote UDP IP address. The IP address must be specified using dot-decimal notation. The default UDP remote IP address is 192.168.1.255. The matrix must be rebooted after executing this command. Syntax #set_udp_port param1 Parameters param1 String Example #set_udp_remote_ip 192.168.1.80 REMOTE UDP IP ADDRESS IS SET...
  • Page 75 Commands #set_udp_remote_port Sets the remote UDP listening port. The default remote UDP listening port is 50008. The matrix must be rebooted after executing this command. Syntax #set_udp_remote_port param1 Parameters param1 Integer [0 ... 65535] Example #set_udp_remote_port 50007 UDP COMMUNICATION PORT 50007 IS SET Related Commands #set_udp_port #show_udp_port...
  • Page 76 Commands #set_webui_ad_pass The #set_webui_ad_pass command sets the Administrator password for the Web GUI. The password is case-sensitive and cannot exceed 7 characters in length. The default password is Admin. Syntax #set_webui_ad_pass param1 Parameters param1 String Example #set_webui_ad_pass bo55man Web UI Administrator Password Is Set. Related Commands #set_webui_op_pass page | 64...
  • Page 77 Commands #set_webui_op_pass The #set_webui_ad_pass command sets the Operator password for the Web GUI. The default password is Admin. Syntax #set_webui_op_pass param1 Parameters param1 String Example #set_webui_op_pass m1ni0n Web UI Operator Password Is Set. Related Commands #set_webui_ad_pass page | 65...
  • Page 78 Commands #sgateway Sets the gateway address. The gateway must be typed using dot-decimal notation. The matrix must be rebooted after executing this command. The default gateway is 192.168.1.1. Syntax #sgateway param1 Parameters param1 String Example #sgateway 10.5.64.1 GateWay Address 10.5.64.1 Is Set. Please Reboot The Unit. Related Commands #ipconfig #show_gateway...
  • Page 79 Commands #show_bank_name Displays the name for the specified EDID bank. Syntax #show_bank_name param1 Parameters param1 Integer [1 ... 8] Example #show_bank_name 5 THE NAME FOR BANK 5 IS: SonyXBR Related Commands #set_bank_name page | 67...
  • Page 80 Commands #show_device_descr Displays the device description. Use the #set_device_descr command to set the device description. Syntax #show_device_descr Parameters None Example #show_device_descr DEVICE DESCRIPTION NAME IS SET TO 8x8Matrix Related Commands #set_device_descr page | 68...
  • Page 81 Commands #show_discovery Displays the current state of the discovery feature. Syntax #show_discovery Parameters None Example #show_discovery DISCOVERY PROTOCOL IS ENABLED Related Commands #show_me #use_discovery page | 69...
  • Page 82 Commands #show_fw Displays the current version of firmware. Syntax #show_fw Parameters None Example #show_fw FIRMWARE VERSION = GTB-HD4K2K-848 v1.0H page | 70...
  • Page 83 Commands #show_gateway Displays the gateway address of the matrix. Syntax #show_gateway Parameters None Example #show_gateway GATEWAY ADDRESS IS: 10.5.64.1 Related Commands #ipconfig #sgateway #sipadd #snetmask page | 71...
  • Page 84 Commands #show_hdcp Displays the HDCP status of the specified input. Use the #hdcp command to enable or disable HDCP. Syntax #show_hdcp Parameters None Example #show_hdcp 3 INPUT 3 HDCP IS ENABLED Related Commands #hdcp page | 72...
  • Page 85 Commands #show_hpd Displays the HPD status of the specified output. The name of the output is included in the feedback. Syntax #show_hpd param1 Parameters param1 Character [A ... H] Example #show_hpd D HPD OF OUTPUT D(OUTPUT4) IS HIGH Related Commands #show_hpd page | 73...
  • Page 86 Commands #show_http_port Displays the current HTTP listening port of the matrix. Use the #set_http_port command to set the HTTP listening port. Syntax #show_http_port Parameters None Example #show_http_port HTTP COMMUNICATION PORT IS: 80 Related Commands #set_http_port page | 74...
  • Page 87 Commands #show_input_name Displays the name of the specified input. To name an input, use the #set_input_name command. Syntax #show_input param1 Parameters None Example #show_input_name 3 THE NAME FOR INPUT 3 IS: Blu-ray Related Commands #set_input_name #set_output_name #show_output_name page | 75...
  • Page 88 Commands #show_ip Displays the current gateway address of the matrix. Use the #sipadd command to set the IP address of the matrix. Syntax #show_ip Parameters None Example #show_ip IP ADDRESS IS: 10.5.64.247 Related Commands #ipconfig #show_gateway #show_netmask #sipadd page | 76...
  • Page 89 Commands #show_ir Displays the current IR channel of the matrix. The IR channel of the matrix must match the IR channel of the IR remote control. See Setting the IR Remote Channel (page 7) more information. Syntax #show_ir Parameters None Example #show_ir CURRENT IR CHANNEL IS: 0...
  • Page 90 Commands #show_mac_addr The #show_mac_addr command displays the MAC address of the matrix. Syntax #show_mac_addr Parameters None Example #show_mac_addr MAC ADDRESS IS: 00-1a-07-11-01-76 page | 78...
  • Page 91 Commands #show_mask Displays the mask status of the specified output. Syntax #show_mask param1 Parameters param1 Character [A ... H] Example #show_mask b OUTPUT B(OUTPUT2) IS UNMASKED Related Commands #mask page | 79...
  • Page 92 Commands #show_me Enables or disables the show me feature on the matrix. Syntax #show_me Parameters param1 Integer [1 ... 2] param1 Description Disabled Enabled Example #show_me 1 SHOW ME IS ON Related Commands #show_discovery #use_discovery page | 80...
  • Page 93 Commands #show_netmask Displays the current subnet mask address of the matrix. Use the #snetmask command to set the subnet mask address. Syntax #show_netmask Parameters None Example #show_netmask NETMASK ADDRESS IS: 255.255.255.0 Related Commands #snetmask page | 81...
  • Page 94 Commands #show_out_colordpt Displays the highest color depth supported by the specified display based on the EDID of the connected sink (display) device. If no display is attached to the specified output, then the command will return: NO SIGNAL Syntax #show_out_colordpt param1 Parameters param1 Character...
  • Page 95 Commands #show_out_res The #show_out_res command displays the highest resolution supported by the specified display based on the EDID of the connected sink (display) device. If no display is attached to the specified output, then the command will return: NO SIGNAL Syntax #show_out_res param1 Parameters...
  • Page 96 Commands #show_output_name Displays the name of the output. To name an output, use the #set_output_name command. Syntax #show_output_name param1 Parameters param1 Character [A ... H] Example #show_output_name D THE NAME FOR OUTPUT D IS: Samsung Related Commands #set_input_name #set_output_name #show_input_name page | 84...
  • Page 97 Commands #show_preset_name Displays the name for the specified preset. To assign a name to a preset, use the #set_preset_name command. Syntax #show_preset_name param1 Parameters param1 Integer [1 ... 8] Example #show_preset_name 4 THE NAME FOR PRESET 4 IS: MBedRoom Related Commands #recall_preset #save_preset #set_preset_name...
  • Page 98 Commands #show_r Displays the routing status of the specified output. Syntax #show_r param1 Parameters param1 Character [A ... H] Example #show_r B OUTPUT B(OUTPUT2) IS ROUTED TO INPUT 3(INPUT3) Related Commands page | 86...
  • Page 99 Commands #show_rsense Displays the Rsense status of the specified output. Syntax #show_rsense param1 Parameters param1 Character [A ... H] Example #show_rsense A RSENSE OF OUTPUT A(OUTPUT1) IS LOW Related Commands #show_hpd page | 87...
  • Page 100 Commands #show_telnet_port Displays the current Telnet port of the matrix. Use the #set_telnet_port command to set the Telnet listening port. Syntax #show_telnet_port Parameters None Example #show_telnet_port TELNET COMMUNICATION PORT IS: 23 Related Commands #set_telnet_port page | 88...
  • Page 101 Commands #show_telnet_username Displays the user name for the current Telnet session. Syntax #show_telnet_username Parameters None Example #show_telnet_username User Name For TELNET Is : Admin Related Commands #set_telnet_pass page | 89...
  • Page 102 Commands #show_udp_port Displays the current local UDP listening port. Use the #set_udp_port command to set the local UDP listening port. Syntax #show_udp_port Parameters None Example #show_udp_port UDP COMMUNICATION PORT IS: 50007 Related Commands #set_udp_port page | 90...
  • Page 103 Commands #show_udp_remote_ip Displays the remote UDP IP address. Use the #set_udp_remote_ip command to set the remote UDP IP address. Syntax #show_udp_remote_ip Parameters None Example #show_udp_remote_ip REMOTE UDP IP ADDRESS IS: 192.168.1.80 Related Commands #set_udp_remote_ip page | 91...
  • Page 104 Commands #show_udp_remote_port Displays the remote UDP port. Use the #set_udp_remote_port command to set the remote UDP remote port. Syntax #show_udp_remote_port Parameters None Example #show_udp_remote_ip REMOTE UDP COMMUNICATION PORT IS: 50008 Related Commands #set_udp_remote_port page | 92...
  • Page 105 Commands #show_ver_data Displays the current software and hardware version. Syntax #show_ver_data Parameters None Example #show_ver_data SOFTWARE AND HARDWARE VERSION: v3.2B PCB-1707*B page | 93...
  • Page 106 Commands #sipadd Sets the IP address of the matrix. The IP address must be entered using dot-decimal notation. The matrix must be rebooted after executing this command. The default IP address is 192.168.1.72. Use the #show_ip #ipconfig command to display the current IP address of the matrix.
  • Page 107 Commands #snetmask The #snetmask command sets the subnet mask. The net mask must be entered using dot-decimal notation. The matrix must be rebooted after executing this command. The default net mask is 255.255.255.0. Use the #ipconfig #show_netmask command to display the current net mask of the matrix. Syntax #snetmask param1 Parameters...
  • Page 108 Commands #unmask The #unmask command unmasks the specified output(s). Use the #mask command to mask the specified output(s). Multiple outputs may be specified. If param1 = 0, then all outputs are unmasked. Syntax #unmask param1 [...param8] Parameters param1 Integer / Character [0, A ...
  • Page 109 Commands #use_discovery Enables or disables the discovery feature. By default, the discovery feature is enabled. Syntax #use_discovery param1 Parameters param1 Integer [0 ... 1] param1 Description Disabled Enabled Example #use_discovery 1 DISCOVERY PROTOCOL IS ENABLED Related Commands #show_discovery #show_me page | 97...
  • Page 110 Commands #use_telnet_pass Enables or disables the password credentials for each Telnet session. The default setting is 0 (disabled). Use the #set_telnet_pass command to set the Telnet password. Syntax #use_telnet_pass param1 Parameters param1 Integer [0 ... 1] param1 Description Disabled Enabled Example #use_telnet_pass 0 Telnet Interface Password Is Disable...
  • Page 111 Commands #use_udp_enable Enables or disables UDP access mode. Syntax #use_udp_enable param1 Parameters param1 Integer [0 ... 1] param1 Description Disabled Enabled Example #use_udp_enable 0 UDP ACCESS IS DISABLE page | 99...
  • Page 112 Commands Displays the current routing status of the matrix. Masking and locking status of the matrix is also provided. Do not precede the m command with the “#’ symbol. Syntax Parameters None Example Out: A B C D E F G H In: 1 2 3 4 5 6 7 8 ALL OUTPUTS ARE UNMASKED MATRIX IS UNLOCKED...
  • Page 113 Commands Displays the routing status of the specified output. Do not precede the n command with the “#’ symbol. If param1 = 0, then the routing state for all outputs is returned. Syntax n param1 Parameters param1 Integer / Output [0, A ...
  • Page 114 Commands Routes the specified input to the output. Do not precede this command with the “#” symbol. Also see the command. If param2 = 0, then the specified input (param1) will be routed to all outputs. Up to eight inputs can be specified at a time (param2 - param9). Syntax r param1 param2 [...param9] Parameters...
  • Page 115 Commands The s command routes the specified input to all outputs. Do not precede this command with the “#” symbol. Syntax s param1 Parameters param1 Integer [1 ... 8] Example INPUT 6 IS SET TO ALL OUTPUTS. Related Commands #show_r page | 103...

  • Page 116: Web Interface

    Web Interface Using the built-in Web Server Access the built-in Web interface by entering the IP address of the matrix that was specified in the section IP Configuration (page 30). Once connected to the matrix, the login screen will be displayed. Username Select the username from the drop-down list.

  • Page 117: Main > Routing

    Web Interface The Web GUI is divided into four main pages: Main, I/O Setup, Manage EDID, and Configuration. Each main page is represented by a tab at the top-most portion of the screen. The Main, I/O Setup, and Manage EDID pages have their own set of sub-tabs. Click on the desired tab / sub-tab to open the desired page.
  • Page 118 Web Interface Name (Outputs) The name of the output. This name can be changed using the #set_output_name command or through the I/O Setup > I/O Names (page 112) page of the Web interface. Outputs (Outputs) Check to select the currently active output. Input # (Inputs) Click the radio button next to the desired input to be routed.
  • Page 119 Web Interface Lock Matrix Locks / unlocks the matrix. Once the matrix is locked, settings cannot be changed using the front-panel buttons or through the Web GUI. When the matrix is locked, the button text will read “Unlock Matrix” and a red bar will appear across the top portion of the screen with the text “Matrix is LOCKED”.

  • Page 120: Main > I/O Status

    Web Interface Main > I/O Status Output Displays the state of each output for each of the following: Name, RSENSE, Mask, HPD (Hot-Plug Detect), HDCP, and Video Mode. Name Displays the name of the output. The name of the output can be changed using #set_output_name command or through the I/O Setup >...
  • Page 121 Web Interface Input Displays the state of each input for each of the following: Input name, Color Depth, Color Space, HDCP, 3D, Active Signal, Vertical Resolution, Horizontal Resolution, Progressive / Interlaced, Refresh Rate, and Video Mode. page | 109...

  • Page 122: Main > Display Info

    Web Interface Main > Display Info Choose EDID Select the EDID from the drop-down list. The selected EDID will be copied from the Output or selected EDID Bank to the desired input(s) and used by the source. Options 1 - Bank1 ... 8 - Bank8 A - Output1 ...

  • Page 123: I/O Setup > Preset Names

    Web Interface I/O Setup > Preset Names Preset # The number of each preset. Name Type the desired name of each preset in these fields. Save Changes Saves the current changes to the name of the preset(s). Cancel Restores the previous name or each preset, if a change was made. page | 111...

  • Page 124: I/O Setup > I/O Names

    Web Interface I/O Setup > I/O Names Output The number of the output. Name (Output) Type the desired name of each output in these fields. Input # The number of each input. Name (Input #) Type the desired name of each the input in these fields. Save Changes Saves the current changes to the name of the output and/or input(s).

  • Page 125: I/O Setup > Hpd Control

    Web Interface I/O Setup > HPD Control Input # The number of the input. Name The name of the input. The name of each input can be changed using the #set_input_name command or through the I/O Setup > I/O Names (page 112) page of the Web interface.

  • Page 126: I/O Setup > Fst

    Web Interface I/O Setup > FST Displays the switching state of each input. Input # The name of the input. Name The name of the input. The name of each input can be changed using the #set_input_name command or through the I/O Setup ► I/O Names page of the Web interface.

  • Page 127: I/O Setup > Hdcp

    Web Interface I/O Setup > HDCP Information Some computers will enable HDCP if an HDCP-compliant display is detected. Check the box under the Disable column to force the computer to ignore detection of an HDCP-compliant display. The Disable feature does not decrypt HDCP content.

  • Page 128: Manage Edid > Assign

    Web Interface Manage EDID > Assign Lock EDID Secures the Local EDID and disables automatic EDID loading during power-up. If the Lock EDID button is clicked (enabled), the “EDID locked on power cycle” message will be displayed in red. The local EDID information will now be locked once the matrix is rebooted.
  • Page 129 Web Interface Copy To Place a check mark in the desired check box to select or deselect the desired input(s). These check-boxes can only be used when the EDID Mode is set to Custom - User. EDID Modes Select the EDID mode from the drop-down list. Options Custom - Last Output Custom - User...
  • Page 130 Web Interface Internal - 1080p 2 ch audio This mode can be used as a generic EDID. Resolutions up to 1080p Full HD are supported along with 2-channel audio. Internal - 1080p Multi ch Same as above except with multichannel audio support. External - Output1 Uses the (downstream) EDID of the sink device connected to Output 1.

  • Page 131: Manage Edid > Bank Names

    Web Interface Manage EDID > Bank Names Bank # Indicates the EDID bank number. Name Type the desired name of the EDID bank in this field. Save Changes Saves the current name change to the EDID bank(s). Cancel Restores the previous names for each EDID bank, if changes were made. page | 119...

  • Page 132: Manage Edid > Upload/Download

    Web Interface Manage EDID > Upload/Download Browse... Click this button to select the EDID file to be uploaded. Select Bank Location Click this drop-down list to select the bank to where the EDID will be uploaded. Options 1 - Bank 1 ... 8 - Bank 8 Upload Click this button to upload the EDID to the specified bank.
  • Page 133 Web Interface Select EDID File to Download Click this box to select the EDID that is to be saved to a file. The EDID file will be saved in binary (.bin) format. Options 1 - Bank 1 ... 8 - Bank 8 A - OUTPUT1 ...

  • Page 134: Configuration > Change Ip Settings

    Web Interface Configuration > Change IP Settings Change IP Settings Assigns the IP address, subnet, gateway, HTTP listening port, Telnet port, and UDP port. The MAC address cannot be changed. Save Settings Saves the current settings for the Change IP Settings. After clicking this button, the Web interface will display a dialog indicating that the matrix must be rebooted for changes to take effect.

  • Page 135: Configuration > Telnet Login Settings

    Web Interface Configuration > Telnet Login Settings Old Password Type the current (old) password in this field. New Password Type the new password in this field. Force Password on Connect Click this check box to have the matrix prompt for a password each time a Telnet session is started.

  • Page 136: Configuration > Udp Connection Settings

    Web Interface Configuration > UDP Connection Settings Remote UDP IP Address Type the remote UDP IP address in this text box. Remote UDP Port Enter the remote UDP port in this text box. Enable UDP Access Check this box to enable UDP access. If this box is unchecked, the UDP access will be unavailable.

  • Page 137: Configuration > Web Login Settings

    Web Interface Configuration > Web Login Settings Username Click this drop-down list to select the user name. The credentials for the selected user name can now be changed. Old Password Type the current (old) password in this field. New Password Type the new password in this field.

  • Page 138: Configuration > System Configuration

    Web Interface Configuration > System Configuration Download Click this button to download the current matrix configuration to a file. (continued on next page) page | 126...
  • Page 139 Web Interface Browse Click this button to select the firmware file to be uploaded. See Upgrading using the Web interface for details on updating the firmware. Browse Click this button to select the saved configuration file to be loaded into memory. Restore Uploads the selected configuration file to the matrix.
  • Page 140 This page left intentionally blank.

  • Page 141: 4 Appendix

    4K Ultra HD 8x8 Matrix for HDMI Appendix page | 129...

  • Page 142: Mounting Instructions

    Mounting Instructions The matrix can be mounted vertically in a wall or cabinet with wood/drywall screws as shown in the diagram above. There should be an inch or two of clearance between the edges of the unit and any walls or vertical surfaces to allow for enough clearance for insertion and retraction of cables at the HDMI connectors.

  • Page 143: Firmware Upgrade Procedure

    DO NOT power-off or disconnect the AC power cord from the matrix during the firmware upgrade process. Download the firmware from the Support section of the Gefen Web site. Extract the firmware file from the .ZIP file. Power-ON the 4K Ultra HD 8x8 Matrix for HDMI.

  • Page 144: Upgrading Using The Usb Port

    DO NOT power-off or disconnect the AC power cord from the matrix during the firmware upgrade process. Download the firmware from the Support section of the Gefen Web site. Power-ON the 4K Ultra HD 8x8 Matrix for HDMI. Connect a USB cable between the computer and the 4K Ultra HD 8x8 Matrix for HDMI.

  • Page 145: Specifications

    Specifications Connectors, Controls, and Indicators Video Input • 8 x HDMI Type A, 19-pin, female, locking Video Output • 8 x HDMI Type A, 19-pin, female, locking • 1 x Mini-B RS-232 • 1 x DB-9, female Ethernet • 1 x RJ-45 Power Receptacle •...
  • Page 146 *Preferred Stretch it. Switch it. Split it. Gefen’s got it. ® 20600 Nordhoff St., Chatsworth CA 91311 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 1-800-545-6900 818-772-9100 818-772-9100 fax: 818-772-9120 fax: 818-772-9120 www.gefen.com www.gefen.com support@gefen.com support@gefen.com...

Table of Contents
