WARNING: Do not mount the camera on any soft material. The camera
may fall and be damaged.POE, Power, DIDO, Audio Connection:
h. Adjust the Lens
1) Adjust The Lens Angle
i. The lens holder can be rotated clockwise or counter clockwise.
ii. Release the tilt screw on both side of the device to tilt the lens up or
down. After completion, tighten the tilt screw.
iii. Release the video adjustment screw and to adjust the lens direction.
After completion, tighten the video adjustment screw.
2) Adjust The View Angle and Focus
i. Release the zoom ring controller bar and then slide it left or right to
(This function applies to all VD series, except the VD-***Nf and VD-***Af.)
