3. Below " Device Appearance Description" is for VD-501Af-series
IR Leds
RJ45 Connector
Conduit Plug and
Conduit Hole
Terminal Block
(For Power)
Focus Control Bar (*)
NOTE
1. SD Card Capacity (*) - The network camera is compatible with SD/SDHC (Maximum
32GB) cards.
2. (*) These are optional features. Please refer to the Product List for the full list of
optional features available for the product.
7
LENS
Tilt Screw
Reset Button
Terminal Block
(For Audio in/out, DI/DO)
View Angle
Control Bar (*)
SD/SDHC
Card Slot (*)
