Integrated Peripherals

This Menu Setup allows you to configure your IDE, USB keyboard, Floppy Drive, Parallel Port,
Serial Port and IR function.
Internal PCI/IDE
IDE Primary Master PIO : Auto
IDE Primary Slave PIO : Auto
IDE Secondary Master PIO: Auto
IDE Secondary Slave PIO: Auto
Primary Master UltraDMA: Auto
Primary Slave UltraDMA: Auto
Secondary MasterUltraDMA: Auto
Secondary Slave UltraDMA: Auto
IDE Burst Mode
IDE HDD Block Mode
Onboard FDC Controller : Enabled
Onboard Serial Port 1
Onboard Serial Port 2
IR Address Select
IR Mode
IR IRQ Select
Onboard Parallel Port 1 : 378/IRQ7
Parallel Port Mode
Internal PCI/IDE
The chipset contains a PCI IDE interface that supports two IDE channels: Primary (IRQ 14) and
Secondary (IRQ 15). Each channel supports two IDE devices, so the system is capable of
supporting a total of four IDE devices. Select Primary, Secondary, or Both to activate chipset
IDE interface(s) installed on your system board.
IDE Primary/Secondary Master/Slave PIO
The four IDE PIO (Programmed Input/Output) fields let you set a PIO mode (0-4) for each of the
four IDE devices that the onboard IDE interface supports. Modes 0 through 4 provide
successively increased performance. In Auto mode, the system automatically determines the best
mode for each device.
The choice: Auto, Mode 0, Mode 1, Mode 2, Mode 3, Mode 4.
IDE Primary/Secondary Master/Slave UltraDMA
Ultra DMA/33 implementation is possible only if your IDE hard drive supports it and the
operating environment includes a DMA driver (Windows 95 OSR2 or a third-party IDE bus
master driver). If your hard drive and your system software both support Ultra DMA/33, select
Auto to enable BIOS support.
The Choice: Auto, Mode 0, Mode 1, Mode 2
IDE Burst Mode
Selecting Enabled reduces latency between each drive read/write cycle, but may cause instability
WinFast
ROM PCI/ISA BIOS (2A6INLB9)
INTEGRATED PERIPHERALS
AWARD SOFTWARE, INC.
: Both ECP Mode Use DMA
PS/2 mouse function
USB Controller
USB Keyboard Support
Init Display First
VGA Shared Memory Size : 8 MB
Current SYSFAN Speed
Current CPUFAN Speed
+ 5V : 5.00
: Enabled + 2.5V: 2.52
: Enabled
: 3F8/IRQ4
: 2F8/IRQ3
: 2F8H
ESC : Quit
: HP SIR
F1 : Help
: IRQ3
F5 : Old Values (Shift)F2 : Color
F6 : Load Basic Defaults
: ECP+EPP
F7 : Load Best Defaults
®
6200MA User's Manual
: 1
: Enabled
: Enabled
: Disabled
: PCI Slot
: 4753 RPM
: 4753 RPM
+ 3.3V: 3.31
Vcore : 2.02
↑↓← →: Select Item
PU/PD/+/- : Modify
37
