Leadtek Research Inc.
in IDE subsystems that cannot support such fast performance. If you are getting disk drive errors,
try setting this value to Disabled. This field does not appear when the Internal PCI/IDE field is
Disabled.
IDE HDD Block Mode
Block mode is also called block transfer, multiple commands, or multiple sector read/write. If
your IDE hard drive supports block mode (most new drives do), select Enabled for automatic
detection of the optimal number of block read/writes per sector the drive can support.
The Choice: Enabled, Disabled
Onboard FDC Controller
This should be enabled if your system has a floppy disk drive (FDD) installed. Even so
equipped, when you add an additional higher performance controller this item should be set to
Disabled.
The choice: Enabled, Disabled.
Onboard Serial Port 1/Port 2
Select an address and corresponding interrupt for the first and second serial ports.
The choice: 3F8/IRQ4, 2E8/IRQ3, 3E8/IRQ4, 2F8/IRQ3, Disabled, Auto.
IR Address Select
Select the Onboard IrDA port..
The choice: Disabled, 2E8H, 2F8H, 3E8H, 3F8H , 3E0H, 2E0H.
IR Mode
Select an operating mode for the second serial port.
The choice: IrDA, Normal, ASK IR.
IR IRQ Select
You could select the IRQ for the IR.
The choice: IRQ3, IRQ4, IRQ10, IRQ11.
Onboard Parallel Port
This item allows you to determine I/O address to access onboard parallel port controller.
The choice: 378H/IRQ7, 278H/IRQ5, 3BCH/IRQ7, Disabled.
Parallel Port Mode
Select an operating mode for the onboard parallel (printer) port. SPP (Normal), EPP (Extended
Parallel Port), ECP (Extended Capabilities Port), ECP+EPP four modes can be selected. Select
Normal unless you are certain that both your hardware and software support EPP or ECP mode.
The choice: SPP, EPP, ECP, ECP+EPP
ECP Mode Use DMA
This item is available while you set the Parallel Port Mode Item to ECP mode or ECP+EPP mode.
You can choose DMA1 or DMA3
The choice: 1, 3
PS/2 Mouse function
Your system has a PS/2 mouse port and when you install a serial pointing device, select
Disabled.
USB Controller
Select Enabled to enable the system Universal Serial Bus (USB) controller when you have USB
peripherals.
38
