Specifications

CPU Support
Intel Socket 370 Celeron Series
and other Socket 370 CPUs
System BIOS (2 MB Flash ROM)
AWARD BIOS, supports PnP,
APM, Multi-Device booting
features (Floppy, LS120,
CD-ROM, IDE, SCSI, ZIP,
ATAPI)
ACPI (Advanced Configuration
Power Interface)
Boot-up anti-virus support
Main Memory
Support 3.3V SDRAM
Support three 3.3V unbuffered
DIMM sockets for max 1.5GB
memory size
Super I/O chip on board
One Parallel (SPP/ECP/EPP)
Two Serial (16650A) compliant
One floppy drive connector
Power-on events
Keyboard password, WOL
(Wake-on-Lan) network card,
Modem ring on, RTC alarm
Software power-off control for
WIN95
Over-ride power button
Two Ultra DMA-33/66 IDE ports
Support up to PIO mode 4,
Multi-word DMA mode2 and
Ultra DMA33/66 MB/Sec
Bus master drivers for all well
known OS.
8
CPU/SDRAM/PCI clock
Support Synchronous
CPU/SDRAM (system clock)
66/75/83/90/95/100/105/112/124
/133 MHz
Chipset
SiS 620/5595 chipsets
Onboard PCI Audio
Ess Solo-1 (ES1938S) audio chip
CD-quality, 16-bit stereo audio
controller
Programmable independent sample rate
from 4KHz to 48KHz for record and
playback
Onboard Super AGP VGA
Support hardware 2D/3D
Video/Graphics Accelerators
Shared System Memory Area 2MB,
4MB, 8MB
Expansion slots
3 PCI, 1 ISA slot, one PCI/ISA
shared.
Other feature support
Hardware monitoring
Two Fan speed monitor input
Fulfills Year 2000 BIOS
compliance
Board Size: 244 mm x 230mm
