5. When the Message "Misfeed detected." Appears
7
Close Misfeed Clearing Guides [FN3] and
[FN2].
8
Raise Top Offset Tray cover [FN1].
9
Pull out the sheet of paper and lower Top
Offset Tray cover [FN1].
10
Open Misfeed Clearing Guide [FN4] at the
right side of the Finisher.
11
4015O108AA
12
FN1
1166O173AA
13
14
FN1
1166O174AA
NOTE
If a misfeed has occurred in the Staple Unit, see
FN4
"Clearing the Staple Misfeed"
1166O183AA
Remove the sheet of paper.
Open Misfeed Clearing Guide [FN5], and
remove the sheet of paper.
FN5
Close Misfeed Clearing Guide [FN4].
Slide the Mailbin Finisher back against the
machine.
1166O184AA
1166O185AA
4015O109AA
p.6-35
