Remote Management
This switch enables or disables the Remote Management mode. Enabling Remote
Management on the Remote module allows all SNMP-configurable features for
both the Host and Remote modules to be configured from the Host module.
When the Remote Management feature is enabled on the Remote module, the
remote module must either be installed in an unmanaged chassis or in a
managed chassis with the SNMP-management disabled (iMediaCenter chassis
with the SNMP switch turned off, or iMediaChassis chassis with the SNMP
management module removed).
By default this feature is set to Disabled.
This feature can only be selected by setting the DIP switches manually.

Installation

iMcV-DS3/E3/STS-1 modules can be installed in any iMediaChassis or
iMediaCenter chassis (remote modules can also be installed in unmanaged
MediaChassis chassis). Each module requires one slot in the chassis. To install a
module, remove the blank brackets covering the slots where the module is to be
installed (if present) by removing the screws on the outside edges of the bracket.
Slide the module into the chassis card guides, until the module is securely seated
in the connector. Secure the module to the chassis by tightening the captive
screw. Save any blanks removed during installation for future use.
It is not recommended that the iMcV-DS3/E3/STS-1 module be installed in an IE-
MediaChassis/DC. The power source in this chassis is not isolated, and cannot
support positive reference ground systems typically used in Telco environments.
The MediaChassis/2-DC and the iMediaChassis/6-DC are suitable alternatives.
NOTE
NOTE
