Then after the module is installed, you can modify the SNMP enabled features by
using the included iView
the software settings take priority over the SNMP enabled feature DIP switch
settings. Make sure that the software settings match the desired configuration
requirements for the installation.
IMC Networks' iView
site: www.imcnetworks.com.
Unmanaged Modules
Before installing the module in an unmanaged chassis, manually configure all of
the desired DIP switch selectable features. In an unmanaged configuration none
of the DIP switch settings can be overridden from software.
DIP Switches
The iMcV-DS3/E3/STS-1 DIP switches are located on S1 and S2 on the PCB. The
S2 DIP switches are factory configured and must not be moved. The S1 DIP
switches provide control over the available iMcV-DS3/E3/STS-1 features.
The location of the S1 DIP switches is displayed in the following diagram:
2
SNMP management software. In a managed chassis,
NOTE
2
software is also available for downloading from the web
2
