Summary of Contents for IMC Networks iMcV-LIM 10/100

  • Page 1 10/100 Operation Manual...
  • Page 2: Warranty

    IMC Networks' instructions and directions for a period of six (6) years after the original date of purchase. IMC Networks warrants to the original end- user purchaser that all SFPs shall be free from defects in materials and workmanship under normal and proper use in accordance with IMC Networks' instructions and directions for a period of one (1) year after the original date of purchase.
  • Page 3: Table Of Contents

    Table of Contents FCC Radio Frequency Interference Statement ............ii Warranty......................ii About the iMcV-LIM 10/100 ................1 Configuration Instructions ..................1 Installing an iMcV-LIM 10/100 ................2 Unmanaged Modules..................2 Modes of Operation...................3 Troubleshooting Features ...................4 Link Fault Detection in FORCE Modes (LFD)............5 LED Operation....................6 Troubleshooting Features ...................7...
  • Page 4: About The Imcv-Lim 10/100

    However, when connected to certain fiber-based devices, there may be difficulty in the installation: if a link partner that is connected to the iMcV-LIM 10/100 media converter is powered down on the copper port, noise on the copper segment may be detected and transferred to the fiber line.
  • Page 5: Installing An Imcv-Lim 10/100

    Managed Modules To manage one or more iMcV-LIM 10/100, an SNMP agent must be present in the chassis. To configure Managed Modules, install the module first, and then configure using the management software. If using management software, software will override hardware DIP Switch settings.
  • Page 6: Modes Of Operation

    Selective Advertising AN (All OFF) NOTE The iMcV-LIM 10/100 cannot be set for Half- or Full-Duplex manually. Duplex is determined by the link partners connected to the iMcV-LIM 10/100. The iMcV-LIM 10/100 media converter is typically installed in pairs and provides compatibility with legacy 10BASE-FL devices, while also providing support for 100Mbps devices.
  • Page 7: Troubleshooting Features

    If a fault occurs on any segment between the two end devices, link LEDs on the end devices will go out. This prevents any failure on the link between the end units from going undetected. As stated, transparency is available when iMcV-LIM 10/100 is operating in PNP (AN) mode: •...
  • Page 8: Link Fault Detection In Force Modes (Lfd)

    10/100 is also down, there is no output. LFD causes the Link Up indicator of the link partner to blink. When the iMcV-LIM 10/100 is in one of the FORCE modes, enable LFD by setting S1 to the ON position.
  • Page 9: Led Operation

    LED Operation The iMcV-LIM 10/100 features several standard and diagnostic LEDs per port. Twisted Pair Port Glows green when a twisted pair link is established. Glows yellow when data is detected on the port. Glows yellow when 100 Mbps data is detected on the port.
  • Page 10: Troubleshooting Features

    S3 to ON with S4 set for the proper speed. Twisted Pair Crossover/Pass-Through Switch The iMcV-LIM 10/100 features a crossover/pass-through push-button switch, located on the faceplate next to the RJ-45 connector, to set the twisted pair connection type.
  • Page 11: Specifications

    Operating Temperature +32°F to +122°F (0°C to +50°C) Storage Temperature -4°F to 158°F (-20°C to +70°C) Humidity 5 - 95% (non-condensing) Power Consumption (typical) 650 mA max. @ 5 VDC For fiber optic specifications, visit the IMC Networks Web site.
  • Page 12: Imc Networks Technical Support

    IMC Networks Technical Support Tel: (949) 465-3000 or (800) 624-1070 (in the U.S. and Canada); +32-16-550880 (Europe) Fax: (949) 465-3020 E-Mail: techsupport@imcnetworks.com Web: www.imcnetworks.com...
  • Page 13: Fiber Optic Cleaning Guidelines

    Dust caps are installed at IMC Networks to ensure factory-clean optical devices. These protective caps should not be removed until the moment of connecting the fiber cable to the device. Should it be necessary to disconnect the fiber device, reinstall the protective dust caps.
  • Page 14: Electrostatic Discharge Precautions

    Electrostatic Discharge Precautions Electrostatic discharge (ESD) can cause damage to any product, add-in modules or stand alone units, containing electronic components. Always observe the following precautions when installing or handling these kinds of products Do not remove unit from its protective packaging until ready to install. Wear an ESD wrist grounding strap before handling any module or component.
  • Page 15: Certifications

    Certifications CE: The products described herein comply with the Council Directive on Electromagnetic Compatibility (2004/108/EC). For further details, contact IMC Networks. Class 1 Laser product, Luokan 1 Laserlaite, Laser Klasse 1, Appareil A’Laser de Classe 1 European Directive 2002/96/EC (WEEE) requires that any equipment that bears this symbol on product or packaging must not be disposed of with unsorted municipal waste.
  • Page 16 The information in this document is subject to change without notice. IMC Networks assumes no responsibility for any errors that may appear in this document. iMcV-LIM 10/100 is a trademark of IMC Networks. Other brands or product names may be trademarks and are the property of their respective companies.
