PART IDENTIFICATION CHART

See the drawings below to identify small parts used in assembly. The number in parentheses below each draw-

ing is the key number of the part, from the PART LIST on page 14. Note: Some small parts may have been

pre-assembled. If a part is not in the parts bag, check to see if it has been preassembled.

M8 Nylon

M10 Nylon

M6 Washer (32)

M8 Washer (33)

Locknut (26)

M10 Washer (37)

M4 x 15mm

M6 x 15mm

M6 x 35mm Screw (31)

M8 x 15mm

Screw (28)

Screw (30)

Screw (25)

M6 x 55mm Screw (35)

M8 x 40mm Bolt (24)

M10 x 180mm Bolt (36)
