Service Indicator Light Diagnostics
NUMBER
ERROR CODE
OF
DESCRIPTION
FLASHES
1
User Fault
2
Battery Fault
3
Left Motor Fault
4
Right Motor Fault
5
Left Park Brake Fault
6
Right Park Brake Fault Check the right park brake, connections and cabling.
7
Remote Fault
8
Controller Fault
9
Communications Fault Contact Invacare/Dealer for service.
10
General Fault
11
Incompatible or
incorrect Remote
Part No. 1143206
POSSIBLE SOLUTION
Release joystick to neutral and try again.
Charge the batteries. Refer to Charging Batteries on page 63.
Check that battery cables are connected properly. Refer to Connecting/
Disconnecting Battery Cables on page 61.
If necessary, replace batteries. Refer to Removing/Installing the Batteries
on page 59.
Check the left motor, connections and cabling.
If necessary, contact Invacare/Dealer for service.
Check the right motor, connections and cabling.
If necessary, contact Invacare/Dealer for service.
Check the left park brake, connections and cabling.
If necessary, contact Invacare/Dealer for service.
If necessary, contact Invacare/Dealer for service.
Check to make sure joystick is connected properly.
Contact Invacare/Dealer for service.
Contact Invacare/Dealer for service.
Contact Invacare/Dealer for service.
Wrong type of remote connected. Contact Invacare/Dealer for service.
