BARCO PROJECTION SYSTEMS
Date :
07022000
R9002390-R9002391-R9002392
R9002397-R9002398-R9002399
INSTALLATION MANUAL
Ciné
8
Art. No. :
R5976065

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cine 8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Barco Cine 8

Summary of Contents for Barco Cine 8

  • Page 1 BARCO PROJECTION SYSTEMS Ciné R9002390-R9002391-R9002392 R9002397-R9002398-R9002399 INSTALLATION MANUAL Date : Art. No. : 07022000 R5976065...
  • Page 2 Due to constant research, the information in this manual is subject to change without notice. Produced by BARCO NV, February 2000. All rights reserved. Trademarks are the rights of their respective owners. BARCO n.v./Projection Systems Noordlaan 5 B-8520 Kuurne Belgium Tel : +32/56/368211 Fax : +32/56/351651 E-mail : sales.bps@barco.com...

  • Page 3: Table Of Contents

    Table of Contents TABLE OF CONTENTS TABLE OF CONTENTS ...................... I-1 SAFETY INSTRUCTIONS ....................1-1 Safety Instructions ............................1-1 Notice on Safety ............................1-1 installation INSTRUCTIONS .......................... 1-1 OWNER’S RECORD ............................. 1-1 Safety indication on the product ........................1-1 Safety Warning .............................. 1-2 FEDERAL COMMUNICATION COMMISSION (FCC STATEMENT) ..............
  • Page 4 Table of Contents AC POWER CONNECTION ....................5-1 Power Connection ............................5-1 AC Power (mains) cord connection ....................... 5-1 Preparing your power cord ..........................5-1 AC Power check ............................5-2 AC Input power (mains) voltage adaptation ....................5-2 Fuses ................................5-3 Switching on ..............................
  • Page 5 Table of Contents GAMMA CORRECTIONS ....................B-1 Gamma Corrections ............................B-1 Warning Entering Gamma corrections ......................B-1 How to adjust ? ............................. B-1 Blue Gamma Correction ..........................B-1 Red and Blue Midlights Correction ........................B-2 Back to the factory preset values .........................B-2 5976065 BARCOCINE 8 10022000...

  • Page 6: Safety Instructions

    Safety Instructions SAFETY INSTRUCTIONS Safety Instructions This equipment is built in accordance with the requirements of the international safety standards EN60950, UL 1950 and CSA C22.2 No.950, which are the safety standards of information technology equipment including electrical business equipment. These safety standards impose important requirements on the use of safety critical components, materials and isolation, in order to protect the user or operator against risk of electric shock and energy hazard, and having access to live parts.
  • Page 7 Safety Instructions TO PREVENT FIRE OR ELECTRICAL SHOCK HAZARD, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE This equipment has been tested and found to comply with the limits of a class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 8 Safety Instructions Never spill liquid of any kind on the product. Should any liquid or solid object fall into the cabinet, unplug the set and have it checked by qualified service personnel before resuming operations. 6. Lightning - For added protection for this video product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet.
  • Page 9 Safety Instructions The use of controlled ambient lighting, such as incandescent spot light or a dimmer, is recommended for proper room illumination. Where possible, care should also be taken to ensure that the floors and walls of the room in which the projector is to be installed are non-reflecting, dark surfaces.

  • Page 10: Unpacking And Projector Dimensions

    Save the original shipping carton and packing material, which will come in handy if you ever have to ship your projector. For maximum protection, repack your projector as it was originally packed at the factory. 1 BARCO CINE 8 projector 1 Remote Control Unit plus 2 x 1.5V batteries 1 Power cord with outlet plug type CEE7 or ANSI 73.11...
  • Page 11 5976065 BARCOCINE 8 07022000...

  • Page 12: Installation Guidelines

    INSTALLATION GUIDELINES Installation guidelines Careful consideration of things such as image size, ambient light level, projector placement and type of screen to use are critical to optimize the use of the projection system. Operation temperature : Max. ambient temperature : 40 °C (104°F) Min.
  • Page 13 To indicate a correct installation position it is necessary to know : • The distance from projector to ceiling in case of Ceiling mounted or the distance from projector to floor in case of Table mounted; • The distance from projector to screen. •...

  • Page 14: Scan Adaptations

    To obtain the right values, you can make use of the option included in the Installation Adjustment Mode to let the projector calculate the parameters automatically. Please refer to Chapter 8 for details. Used phosphor width on the CRT faceplate (e.g. green CRT) 11.5 cm (4.5 inch) Green phosphor...

  • Page 15: Removing The Top Cover

    Removing the top cover During some installations, it will be convenient to remove the top cover from the projector totally. Proceed as follows : • Pivot the top cover backwards 90° (fully extended); • Push carefully the top cover to the left side (viewing from the rear of the projector) until the hinges are disengaged. This can be facilitated by pressing downwards on the spring tabs next to the hinges.

  • Page 16: Scan Inversion

    Getting access to the scan switches • Open the top cover and remove it from the projector; • Loosen the 3 retaining screws on each side of the projector; • Open the protection plate and pivot it forward (toward lenses). Horizontal Scan Switches Three switches are used, one for each CRT.

  • Page 17: Vertical Scan Switch

    Vertical Scan Switch One vertical switch is used for the three CRT's. See position of the switch (diagrams) for the corresponding projector configuration. To set the vertical scan switch : • Remove the vertical deflection module (the third module viewing from the rear of the projector). To remove the vertical deflection module : - Press the module lock and lift up the module handle;...
  • Page 18 IDENTIFICATION below : COPY A BLOCK IRIS DELETE A BLOCK DELETE ALL BLOCKS GUIDED CHANGE PASSWORD RANDOM ACCESS CINE 8 CHANGE LANGUAGE INSTALLATION RUN TIME Proj. address : 001 SERVICE SET TO MIDPOSITION Soft. Version : 6.00 source 1 CONVERGENCE MID Config.

  • Page 19: Projector Set Up

    Projector setup PROJECTOR SETUP Projector Set Up The DIP switches on the controller board allow the SETUP of the projector : • 8 DIP switches for setting the projector address. • 1 DIP switch for setting the powerup mode. • 3 DIP switches for setting the baud rate for communication.

  • Page 20: Note

    Projector setup The projector's address may be set to any value between 0 and 255. When the address is set, the projector can be controlled now by : • RCU for addresses between 0 and 9. • IBM PC (or compatible) or Apple MAC for addresses between 0 and 255. Addressable with RCU Addressable with PC, MAC or workstation...

  • Page 21: Powerup Mode

    Projector setup When the address button on the RCU is pressed, the projector will display its own address on the screen. Once the address button is pressed, to continue using your RCU, it is necessary to enter an address, even when the displayed address is correct. Use the numeric keys to enter the address.

  • Page 22: Password Mode

    Projector setup The communication speed between the projector and the computer has 8 possible settings. With DIP Switch No. 6, No.7 and No.8 of the 8 DIP switches on the controller board, labelled as ‘Baud rate code (sum)’, it is possible to select the baud rate (communication speed).

  • Page 23: Ac Power Connection

    AC power connection AC POWER CONNECTION Power Connection Use the supplied cord to connect your projector to the wall outlet. Plug the female power connector into the male connector at the back of the projector. 'Ãr…vƒur…hy† &$ÃPu€ &$ à Pu€ $%Ã...

  • Page 24: Fuses

    AC power connection Power cord with an ANSI 73.11 plug The wires of the delivered mains lead (power cord) are colored in accordance with the following code : Yellow and Green Ground (Earth). White Neutral. Black Live. Check the power voltage which is determined by the ART. NR. (Article number) included in the label pasted on the backside of the projector.
  • Page 25 AC power connection Fuses Power selector plug AC Power input board 120V 230V Power selector on 120V Power selector on 230V Warning ! For continued protection against fire hazard : • Replace with the same type of fuse. • Refer replacement to qualified service personnel. AC power Fuses Order Number 230 Vac...

  • Page 26: Start Up In Operational Mode

    AC power connection The projector starts up in stand by. Press a digit key corresponding to the desired source or press STBY key. The projector displays the selected source or the warm up cycle message. When this warm up message appears on the screen, handle as described in 'Start up in Operational Mode'. Start up with "Warm up period"...

  • Page 27: Which Source To Which Input

    Connections SOURCE CONNECTIONS Input Source Connection Input facilities - Composite Video (*) - S-Video (*) - RGBS or RGsB (*) - RGB3S or RG3sB - (R-Y)Y(B-Y)S or (R-Y)Ys(B-Y) [component input] (**) - (R-Y)Y(B-Y)3S or (R-Y)Y3s(B-Y) [component input] (**) (*) If the line double or line multiplier feature is built in, this feature is available via a software on/off toggle. (**) If the line double or line multiplier feature is built in, this feature is available for component video signals on standard frequency via software on/off toggle.

  • Page 28: Connecting A Composite Video Source

    Connections Connecting a Composite Video source. Composite video signals from a VCR, OFF air signal decoder, etc.. Note : If a line doubler or line multiplier is built in, the default position of this line doubler (multiplier) soft option is ON (active). The video input signal will be displayed as a non interlaced image (= improved image stability).

  • Page 29: Input Selection

    Connections Pin configuration 4 pin connector For S-video: For video: Pin 1: earth(ground) luminance Pin 1:earth(ground) video Pin 2: earth(ground) chrominance Pin 2:not connected Pin 3:luminance signal(Y) Pin 3:video signal 1Vpp ±3dB Pin 4:not connected Pin 4:chrominance signal(C) 300mVpp ±3dB Input selection With the RCU or built-in RCU : press digit button 2 Input Priority setting...

  • Page 30: Connecting A Rgb Analog Source To Port 3

    Connections Connecting a RGB Analog source to port 3 Connect your RGB source via an interface to Port 3. Note : If a line doubler or line multiplier is built in, the default position of this line doubler (multiplier) soft option is ON (active). The video input signal will be displayed as a non interlaced image (= improved image stability).
  • Page 31 Connections 75 W resistors on the module : line terminated. 75 W resistors removed : line not terminated. Procedure to remove the line termination resistors : Turn off the projector and unplug the projector power cord. Remove the top cover from the projector (see p.4-1). Remove the RGB Input Auto Sync Tracking Module from the main frame.

  • Page 32: Connecting A Rgb Analog Source With Composite Sync To Port 4/5

    Connections Connecting a RGB Analog source with composite sync to port 4/5. RGB analog input terminals with separate H and V sync inputs, composite sync input or with sync on green. The projector detects automatically where the sync signal is located. Note : If a line doubler or line multiplier is built in, the default position of this line doubler (multiplier) soft option is ON (active).

  • Page 33: Connecting A Component Source

    Connections Connecting a Component source. (R-Y)Y(B-Y) analog input terminals with sync input or with sync on the luminance (Y) input. The projector detects automatically where the sync signal is located. Line doubling or multipling is possible for component video input sources on standard line frequency. Note : If a line doubler or line multiplier is built in, the default position of this line doubler (multiplier) soft option is ON (active).

  • Page 34: Baud Rate For Communication With A Computer

    Connections Set up of the Baud Rate for Communication with a Computer. See 'Change Baudrate PC' in chapter 'Service mode' '  Ã ƒr …v ƒ ur …hy † PO RT 4/5 PO RT 2 P OWE R / MA INS COMM.

  • Page 35: Installation Adjustment Mode

    Installation adjustment mode INSTALLATION ADJUSTMENT MODE Installation Adjustments Press the ADJUST key. The projector displays the 'Main menu' (menu 1). Push the cursor keys é or ê to select 'Service Menus' Press ENTER to select. A warning will be displayed (menu 2). If qualified, press ENTER to continue The Service menus main menu will be displayed (menu 3).

  • Page 36: Projector Distance

    Installation adjustment mode Adjustment Mode Optical Lens Focusing Installation Projector Distance Raster Centering CRT Projection Angle Adjustment Scheimpflug Adjustment The top cover of the projector should be removed in order to gain access to the adjustments. Please refer to chapter 'Installation Guidelines' for how to remove the top cover. Projector Distance On the screen, a drawing will be displayed together with parameters indicating a correct installation position.

  • Page 37: Optical Lens Focusing

    Installation adjustment mode Optical Lens Focusing The optical focusing procedure is performed separately for each lens. The appropriate CRT will be switched on as the user proceeds through the optical focusing adjustment sequence. Each lens has two focus adjustment points, one at the rear of the lens and one at the front. The center of the projected image is focused by loosening the wing nut at the rear end of the lens and rotating the lens barrel until the center of the image is clearly focused.

  • Page 38: Crt Projection Angle Adjustment

    Installation adjustment mode Press ENTER to activate the raster on the Red CRT faceplate. Shift the Red raster with the control stick until the raster is centered on the CRT faceplate. Press ENTER to activate the raster on the Blue CRT faceplate. Shift the Blue raster with the joy stick until the raster is centered on the CRT faceplate.
  • Page 39 Installation adjustment mode Loosen bolts A, B, C and D to pivot the red CRT until the center of the Red image and the center of the Green image coincide. When the angle of the red CRT is corrected, tighten the four bolts. Press ENTER to continue with blue and green crosshairs.

  • Page 40: Scheimpflug Adjustment (Diagonal Image Focusing)

    Installation adjustment mode Scheimpflug Adjustment (Diagonal image focusing) With the diagonal image focusing corrections, it is possible to obtain uniform focus for the total projected image. These corrections must be repeated for each color. The Diagonal image focusing is repeated 3 times, first for green, then for red and then for blue.

  • Page 41: Finishing The Installation Mode

    Installation adjustment mode LENS CORNER FOCUSING CENTER FOCUSING DIAGONAL IMAGE FOCUSING DIAGONAL IMAGE FOCUSING from left bottom to right top from left top to right bottom bolt 02 bolt 05 bolt 01 bolt 00 bolt 04 BLUE IMAGE RED IMAGE GREEN IMAGE bolt 03 e.g.
  • Page 42 Installation adjustment mode 5976065 BARCOCINE 8 10022000...

  • Page 43: G2 Adjustment

    Appendix A: G2 adjustment G2 ADJUSTMENT G2 Adjustment Enter the adjustment mode by pressing ADJUST (menu 1). Highlight SERVICE. Press ENTER to start up the service mode (menu 2). Highlight G2 Adjustment Press ENTER. A safety notice will be displayed to warn the operator (menu 3). If you are qualified, press ENTER to continue with the G2 adjustment, otherwise press EXIT to return to the service moenu.
  • Page 44 Appendix A: G2 adjustment When selecting the G2 adjustment menu, these green LEDs must be out. If not, follow the procedure below to adjust the G2: Open the second metal cover by turning out the retaining screws on both sides and pivot the cover to the front side of the projector Adjust the G2 potentiometers (see Photo 3) very slowly with a plastic tweaker until the LED of the corresponding amplifier just stops illuminating.

  • Page 45: Blue Gamma Correction

    Gamma corrections GAMMA CORRECTIONS Gamma Corrections "RISK OF INCORRECT ADJUSTMENT OF THE PROJECTOR. THE GAMMA CORRECTIONS ARE FACTORY ADJUSTED USING AN ACTAS COLOR ANALYZER ! THEREFORE, ONLY QUALIFIED INSTALLATION OR SERVICE PERSONNEL SHOULD PERFORM THESE ADJUSTMENTS ! " If you are qualified, press ENTER to continue. WARNING RISK OF INCORRECT ADJUSTMENT OF THE...
  • Page 46 Gamma Corrections Push the cursor keys é or ê to highlight the item R & B MIDLIGHTS in the menu (menu 1). Press ENTER. If EXIT is pressed, the projector will return to the Service menu. After ENTER is pressed, a text box with the message "Adjust with arrow key", will be displayed on the screen. Push the cursor keys é...
