This user manual is provided as a free service by FixYourDLP.com. FixYourDLP is in no way responsible
for the content of this manual, nor do we guarantee its accuracy. FixYourDLP does not make any claim
of copyright and all copyrights remain the property of their respective owners.
About FixYourDLP .com
FixYourDLP.com (http://www. xyourdlp.com) is the World's #1 resource for media product news,
reviews, do-it-yourself guides, and manuals.
Informational Blog: http://www. xyourdlp.com
Video Guides: http://www. xyourdlp.com/guides
User Forums: http://www. xyourdlp.com/forum
FixYourDLP's Fight Against Counterfeit Lamps:
http://www. xyourdlp.com/counterfeits
RecycleYourLamp.org – Free lamp recycling services for used lamps:
http://www.recycleyourlamp.org
Lamp Research - The trusted 3rd party lamp research company:
http://www.lampresearch.com
Discount-Merchant.com – The worlds largest lamp distributor:
http://www.discount-merchant.com
Disclaimer
Disclaimer
Sponsors:
Sponsors:
Sponsored by
D
D
M
M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cine VERSUM 60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Barco Cine VERSUM 60

Summary of Contents for Barco Cine VERSUM 60

  • Page 1 Disclaimer Disclaimer This user manual is provided as a free service by FixYourDLP.com. FixYourDLP is in no way responsible for the content of this manual, nor do we guarantee its accuracy. FixYourDLP does not make any claim of copyright and all copyrights remain the property of their respective owners. About FixYourDLP .com FixYourDLP.com (http://www.
  • Page 2 BarcoProjection Cine VERSUM 70/60 R5976691 Owner’s MANUAL T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S 24112003 R5976691/01...
  • Page 3 Barco nv Home Cinema Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.84.30 Fax: +32 56.36.88.62 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S...
  • Page 4 The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on the date of commissioning, at latest 30 days after the transfer of risks. In the event of justified notice of compliant, Barco can repair the fault or provide a replacement at its own discretion within an appropriate period.
  • Page 5 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S...

  • Page 6: Table Of Contents

    Table of contents TABLE OF CONTENTS SAFETY INSTRUCTIONS......................3 General Safety Instructions...............................3 Projector Related Safety Information ............................3 OVERVIEW OF USER’S CONTROLS ..................5 Projector ....................................5 Remote Control..................................5 Rem te Control Operation ................................7 2.3.1 General ..................................7 2.3.2 Battery Insertion in the Remote Control ........................8 MAKING CONNECTIONS ......................9 Removing the Connector Cover ..............................9 Connecting Input Devices .................................9...
  • Page 7 Table of contents T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S R5976691 CINE VERSUM 70/60 24112003...

  • Page 8: Safety Instructions

    SAFETY INSTRUCTIONS 1. SAFETY INSTRUCTIONS Overview • General Safety Instructions • Projector Related Safety Instructions This manual is intended for the user/operator of the installed projector. Any change in cabling or servic- ing of the installed projector must be performed by service personnel having appropriate technical training and experience necessary to be knowledgeable of potential hazards to which they are exposed in performing a task, and of measures to minimize the potential risk to themselves or other persons.
  • Page 9 1. SAFETY INSTRUCTIONS T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S R5976691 CINE VERSUM 70/60 24112003...

  • Page 10: Overview Of User's Controls

    OVERVIEW OF USER’S CONTROLS 2. OVERVIEW OF USER’S CONTROLS Overview • Projector • Remote Control • Remote Control Operation 2.1 Projector Top View The top side of the projector is provided with the following controls: Image 2-1 Projector controls Controls function description Ref.
  • Page 11 2. OVERVIEW OF USER’S CONTROLS Image 2-2 Remote control Ref. Function Description Remote control operation indication Lights up when a button on the remote control is pressed (Visual indication of remote control operation – Battery check). F1-5 buttons Activate PIP functions. (Not available on all models.) ADJ (Adjust button) Toggle button to enter or exit the adjustment mode.

  • Page 12: Rem Te Control Operation

    OVERVIEW OF USER’S CONTROLS 2.3 Remote Control Operation Overview • General • Battery Insertion in the remote control • Visualization of Commands 2.3.1 General How to use This remote control includes a battery powered infrared transmitter which allows the user to control the projector remotely via its own built-in infrared receiver.

  • Page 13: Battery Insertion In The Remote Control

    2. OVERVIEW OF USER’S CONTROLS 2.3.2 Battery Insertion in the Remote Control Where to find the batteries The batteries are not placed in the remote control to avoid remote control operation in its package, resulting in a shorter battery life time.

  • Page 14: Making Connections

    MAKING CONNECTIONS 3. MAKING CONNECTIONS Overview • Removing the connector cover • Connecting input devices • Replacing the connector cover 3.1 Removing the Connector Cover Before you can connect the power cord and input devices to the projector, the connector cover must me removed. How to remove the connector cover 1 Loosen the captive screw (image 3-1).
  • Page 15 3. MAKING CONNECTIONS Connector View Image 3-3 Connectors and power plug Ref. Function Description S-video Connect an S-video cable from the S-video out connector on the video device to this connector. Video (composite) Connect a composite video cable from the video (composite) out connector on the video device to this connector.

  • Page 16: Replacing The Connector Cover

    MAKING CONNECTIONS 3.3 Replacing the Connector Cover After connecting the power cord and input devices to the projector, the connector cover should be replaced. How to replace the connector cover 1 Insert the cover brackets first, and then push down firmly until the cover “snaps” back into place (image 3-5). 2 Tighten the captive screw (image 3-5).
  • Page 17 3. MAKING CONNECTIONS T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S R5976691 CINE VERSUM 70/60 24112003...

  • Page 18: Switching On/Off The Projector

    SWITCHING ON/OFF THE PROJECTOR 4. SWITCHING ON/OFF THE PROJECTOR Overview • Switching on the projector • Switching between STANDBY and OPERATION • Switching off the projector 4.1 Switching on the Projector How to switch on Press the main power switch on the projector. The projector goes from OFF to STANDBY, visualized by blinking of the standby LED.
  • Page 19 4. SWITCHING ON/OFF THE PROJECTOR T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S R5976691 CINE VERSUM 70/60 24112003...

  • Page 20: Source Selection

    SOURCE SELECTION 5. SOURCE SELECTION Overview • Selecting a source • Menu-to-connector comparison 5.1 Selecting a Source More than one input device can be connected to the projector at the same time. The source selection menu allows you to select the in- put source.
  • Page 21 5. SOURCE SELECTION Image 5-2 Menu-to-connector comparison T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S R5976691 CINE VERSUM 70/60 24112003...

  • Page 22: Image Control

    IMAGE CONTROL 6. IMAGE CONTROL Image controls The Brightness, Contrast, Sharpness (Detail), Color and Tint (Hue) functions are accessed directly from the remote control. The adjustment functions, when selected, display a slide bar overlayed on the source image (only if text is On). It is useful to adjust the Brightness whenever the ambient room lighting changes.

  • Page 23: Sharpness (Detail) Control

    6. IMAGE CONTROL Image 6-3 Image 6-4 6.3 Sharpness (Detail) Control How to adjust the Sharpness The Sharpness function is used to adjust the image sharpness of video signals when using a video decoder installed in the projector. To adjust the Sharpness, press the (-) or (+) side of the ’SHARPN’ button (image 6-5). The following barscale is overlayed on the source image (image 6-6).

  • Page 24: Tint Control

    IMAGE CONTROL Image 6-7 Image 6-8 6.5 Tint Control How to adjust the Tint (hue) The Tint function is used to adjust color hue to obtain true color reproduction and is only active for Video and S-Video when using the NTSC 4.43 or NTSC 3.58 color system.
  • Page 25 6. IMAGE CONTROL Aspect Ratio Description Standard television format Workstations format. 2.35:1 or Cinemascope format, frequently used by Hollywood films. Panavision 1.88:1 Film format used by a lot of non-action films. 1.78:1 Wide screen television format/Anamorphic format. Letterbox Forces the letter format of the input signal into the native panel resolution. 2 Press * to scroll through the available options.
  • Page 26 Disclaimer Disclaimer This user manual is provided as a free service by FixYourDLP.com. FixYourDLP is in no way responsible for the content of this manual, nor do we guarantee its accuracy. FixYourDLP does not make any claim of copyright and all copyrights remain the property of their respective owners. About FixYourDLP .com FixYourDLP.com (http://www.
