PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included. If a part is missing, please call 1-888-533-1333.
M10 Split
M8 Washer
M10 Washer
M10 Curved
(63)––8
Washer (62)––2
(64)––6
Washer (80)––2
M4 x 16mm
M6 Bolt Set (67)––2
M8 Locknut
M10 Locknut
Screw (56)––4
(77)––1
(60)––6
M8 x 20mm
M10 x 39mm Screw (75)––2
M8 x 38mm Bolt
M10 x 20mm
Screw (61)––8
(59)––6
Screw (74)––5
M10 x 53mm Screw (73)––1
M10 x 60mm Bolt (72)––1
M10 x 70mm Screw (76)––2
