PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
M4 x 16mm
Screw (101)–22
M8 Locknut
(102)–4
M8 x 22mm M8 x 28mm
Washer (129)–2 Washer (97)–2
M8 x 45mm Bolt
M8 x 13mm M8 x 20mm M8 x 20mm Flat
(96)–4
Screw (82)–4 Screw (95)–2 Head Screw (120)–2
M10 x 115mm Screw
M10 x 25mm
(104)–4
Screw (92)–2
