Assembly - ProForm 20.0 Crosstrainer Elliptical Manual

Star Washer M4 x 13mm M6 Split M8 x 15mm x 4.5mm M8 Split Wave Washer
(100)–3 Washer (93)–2 (98)–8
Washer (88)–8
Washer (99)–4 Washer (72)–4
M10 x 20mm x M10 x 20mm x M10 x 20mm x M10 x 25mm M8 Nylon M10 Nylon
1mm Washer 1.5mm Washer 2mm Washer Washer (94)–4 Locknut (96)–4 Locknut (97)–2
(81)–2 (84)–2 (92)–4
M4 x 16mm M4 x 16mm M6 x 35mm Phillips M8 x 42mm Bolt M8 x 16mm Button
Self-tapping Screw (86)–8 Screw (87)–8 (71)–4 Screw (95)–3
Screw (79)–16
M8 x 75mm Button M10 x 20mm Button M10 x 23mm Shoulder
Screw (107)–4 Screw (91)–4 Screw (80)–8
M10 x 62mm Bolt (89)–2 M10 x 78mm Button Screw (90)–2
