Magnum 1000 Workgroup Hubs
1.4

Ordering Information

Magnum 1008
Magnum 1016
Magnum 1024
Magnum 10xx-pm
Magnum 10xx-48V
GarrettCom, Inc. reserves the right to change specifications, performance
characteristics and/or model offerings without notice.
.
www GarrettCom com
Magnum 1000 Workgroup Hubs
Eight port 10BASE-T Hub with shielded RJ-45
connectors and front-mounted LEDs. Includes a basic
AUI port in the rear; may optionally be ordered instead
with an RPM or BPM in the rear port slot. Internal
universal power supply, up-link switch on port 1.
Stand-alone package, rack- mount brackets optional.
16 port 10BASE-T Hub with shielded RJ-45
connectors and front-mounted LEDs. Includes a
basic AUI port in the rear and one rear bonus
slot for an optional RPM or BPM to be
configured. Internal universal power supply, up-
link switch on port 1. Stand-alone or rack-
mount; brackets (ears) included.
24 port 10BASE-T Hub with shielded RJ-45
connectors and front-mounted LEDs. Includes a
basic AUI port in the rear and one rear bonus
slot for an optional RPM or BPM to be
configured. Internal universal power supply, up-
link switch on port 1. Stand-alone or rack-
mount; brackets (ears) included.
Designates a port module (RPM or BPM) to be
factory installed in the applicable rear-mounted
bonus slot. (Note that the designated port module
option, an RPM or a BPM, must also be
purchased as a line item.)
factory installed in the chassis, see Appendix B.
.
Installation and User Guide (04/02)
Designates optional 48VDC power supply to be
3
