Creating a Power Schedule

The schedule function allows the monitor to automatically change between power on and standby modes at different times.
To program the scheduleN
1. Enter the [SCHEDULE] menu.
Using the remote control, highlight [SCHEDULE SETTINGS] using
a
the  and  buttons.
Press the SET/POINT ZOOM or the  button to enter the Settings menu.
b
Highlight the desired schedule number and press SET/POINT ZOOM
c
button.
The box next to the number will turn yellow.
d
The schedule can now be programmed.
2. Use the  button to highlight the [POWER]. Use the  and  buttons to
set [ON].
To set a power off schedule, set [OFF].
3. Use the  button to highlight the [TIME]. Use the  and  buttons to set the time.
4. Use the  and  buttons to highlight [INPUT]. Use the  and  buttons to choose the input source.
5. Use the  button to select [DATE] or [EVERY WEEK]. Press the SET/POINT ZOOM button on a menu which is suitable for
the schedule.
If the schedule is to be run on a specific day, choose [DATE] and press the SET/POINT ZOOM button.
If a weekly schedule is desired, choose the [EVERY WEEK] using the  and  buttons and pressing SET/POINT ZOOM
button to select. Then select the specific day and press SET/POINT ZOOM button.
6. After a schedule is programmed, the remaining schedules can then be set. Press MENU button to leave the OSD or press
EXIT button to go back to the previous menu.
NOTEN:
• The [DATE & TIME] needs to be set before adding schedules.



• Schedules you configure are saved when exiting the [SCHEDULE INFORMATION] window.

• If multiple schedules are set to start at the same time, the conflicting schedule with the highest number is given
priority.

• Schedules will not run when the [OFF TIMER] is set to [ON].

• If the input is no longer valid, the text displays in red.
For example, if the following settings are changed after the input is set for the schedule, the text changes to red and
input changing does not occur:
- [DUAL DAISY CHAIN MODE] is set to [ENABLE] in [VIDEO OUT SETTINGS] or
- [AUTO INPUT CHANGE] is set to [CUSTOM DETECT] but the input selected at schedule is not selected in
[CUSTOM DETECT].

• Schedules do not run while the [SCHEDULE INFORMATION] menu is open.
Set date and time to the monitorN
TIME ZONEN Set the time difference between the region where the monitor is used and the UTC (Universal Time, Coordinated).
• Initial value: +00:00.
• When using the monitor in Japan, set the time as [+09:00].
INTERNET TIME SERVERN Automatically sets the date and time by synchronizing with the NTP server on the network.
• When synchronizing the time with the NTP server on the network to obtain the correct time, set [INTERNET TIME SERVER]
to [ON]. Then enter the IP address of the NTP server or the [HOST NAME] and perform [UPDATE].
IMPORTANTN
• When a period of about one week has passed after disconnecting the power cord of the monitor, the time will


be initialized and the clock function will stop. When initialized, the date becomes [01.01.2020] and the time
becomes [00:00]. If the clock function has stopped, configure the [DATE & TIME] again.
SCHEDULE:
SCHEDULE SETTINGS
OFF TIMER
RESET
English−44
SETTINGS:
1
POWER: ON
TIME: 04 : 03
INPUT: HDMI1
DATE
YEAR: 2020
MONTH: JANUARY
DAY: 01
EVERY WEEK
SUN MON TUE WED
THU FRI SAT
