12
HM-134 REMOTE-CONTROL MICROPHONE

I Lock functions

The lock function electronically locks keys and switches to
prevent accidental changes and function access from the mi-
crophone.
• All keys, switches and controllers on the transceiver are functional.
ï ï Activating the lock
function
➥ While pushing and holding
[H/L], push [SQL] to turn the
lock function ON and OFF.
• " " appears.
• Only [PWR],
[SQL•MONI], [VOL]+[Y]/[Z] and
[SQL]+[Y]/[Z] are functional.
ï ï Activating the all key
lock function
➥ While pushing and holding
[H/L], turn the power ON by
pushing [PWR] to turn the all
key lock function ON and OFF.
• " " flashes.
• Only [PWR] and [PTT] are func-
tional.
34
[PTT], [H/L],
Appears when the lock
function is in use.
Flashes when the all lock
function is in use.

I Display backlighting

The function display and switches can be backlit for better
visibility under low light conditions. And the backlighting con-
dition can be adjusted independently from the transceiver.
q Push and hold [VOL•DIM] for 1 sec. to enter backlight ad-
justing mode.
• " " with number of backlight level appears in the channel name
indicator.
w Push [Y]/[Z] to adjust the backlight level.
• The backlight level is adjustable between 0 (lights OFF) and 3
(brightest).

I Monitor function

The monitor function releases the noise squelch mute of the
microphone only. (An independent noise squelch system is
employed.)
➥ Push and hold [SQL•MONI] for 1 sec. to activate the mon-
itor function.
• " " flashes and audio is emitted.
• Any key, except [Y]/[Z], cancels the monitor function.
