t CHANNEL SELECTOR [CHANNEL]
Rotate [CHANNEL] to select the operating channels, set
mode contents, etc. (p. 8)
y DIMMER SWITCH [DIMMER]
➥ Push to select one of 8 backlighting (LCD and switches)
levels.
➥ Push and hold for 1 sec. to turn the intercom mode ON.
u CALL CHANNEL SWITCH [CALL]
➥ Push to select the call channel. (p. 6)
➥ Push and hold for 3 sec. to enter call channel program-
ming condition. (p. 9)
➥ While pushing and holding [HI/LO], enters memory
name programming condition. (p. 9)
i CHANNEL 16 SWITCH [16]
➥ Push to select Channel 16. (p. 6)
➥ While turning power ON, push to enter initial set mode.
(p. 14)
o DIAL SWITCH [DIAL]
➥ Push to exit from Channel 16 or call channel.
(p. 6)
➥ While pushing and holding [HI/LO], push to select chan-
nel group. (pgs. 6, 7)
"EUR"
• The version has International channels only and this
PANEL DESCRIPTION
function is not available.
!0 SCAN SWITCH [SCAN/TAG] (p. 13)
➥ When tag channels are programmed, starts and stops
normal or priority scan.
➥ Push and hold [SCAN/TAG] for 1 sec. to set the dis-
played channel as a tag (scanned) channel.
➥ While pushing and holding [HI/LO], push and hold for 3
sec. to clear all tag channels.
!1 DUALWATCH/TRI-WATCH SWITCH [DUAL] (p. 11)
➥ Push to start dualwatch or tri-watch.
➥ When dualwatch/tri-watch is activated, push to stop
them.
