Summary of Contents for A&D SF-6KB
- Page 1 SF/SG Series Price Computing Scales Instruction Manual SF-15KA Max. 15kg Min 0.1kg e=0.005kg SG Series SF Series WM:PD4000340...
-
Page 2: Table Of Contents
SF/SG Series Instruction Manual Index Item Number Description Page Unpacking and Inspecting Specifications Main Operating Components Zero Point Adjustment Tare Adjustment Keypad Tare Entry Setting a Unit Price Storing a Unit Price in Memory Recalling a Unit Price from Memory Totaling Multiple Items with Unit Prices Stored in PLU Memory Clearing Totaling Memory Multiplier Function... -
Page 3: Unpacking And Inspecting
Various models are capable of using rechargeable or 6 D size replaceable batteries. D size replaceable batteries are not shipped with the unit and must be purchased locally: – SF-6KA, 15KA, 30KA AC only – SF-6KB, 15KB, 30KB AC adapter (D size capable) – SF-6KC, 15KC, 30KC AC adapter (rechargeable battery capable) –... -
Page 4: Specifications
SF/SG Series Specifications Specification Table Price Model Capacity Display Type AC Type Battery Lookup Options Type Capability SF- 6KA 6 kg x 2 g Tower AC hardwired None RS-232C SF-15KA 15 kg x 5 g Tower AC hardwired None RS-232C SF-30KA 30 kg x 10 g Tower... -
Page 5: Main Operating Components
SF/SG Series Main Operating Components Power Switch turns the power to the unit on and off. Multiple displays SG Model • Weight of product 1-12 SF-15KA Max. 15kg Min 0.1kg e=0.005kg •Zero & Tare • Price of product Price Lookup •Memory &... -
Page 6: Zero Point Adjustment
SF/SG Series Operating Instructions 1. Zero Point Adjustment The zero point is automatically adjusted when power is turned on. If the display shows a positive or negative weight, the scale must be re-zeroed. How to re-zero: Step 1: Assure that nothing is on the weighing pan. Step 2: Press ZERO Step 3: The WEIGHT display should read:... -
Page 7: Keypad Tare Entry
SF/SG Series Operating Instructions 3. Keypad Tare Entry Note: Usually this function is inhibited. If necessary, please ask your dealer. In addition to the tare adjustment described on the previous page, another tare adjustment is available. It is to enter a TARE value with the numerical keypad. How to enter a TARE using the numerical keypad: Step 1: With nothing on the weighing pan, turn on the SF/SG scale. -
Page 8: Setting A Unit Price
SF/SG Series Operating Instructions Note about keypad tare entry: Err tr “ ” • When a TARE weight has been set, an error message will appear as shown below, if you enter a lower value than the TARE weight. Err tr “... -
Page 9: Storing A Unit Price In Memory
SF/SG Series Operating Instructions 5. Storing a Unit Price in Memory Unit prices can be stored in memory for quick recall, by assigning a unit price to a Price Lookup (PLU) key. The SF series scale has 30 PLU keys, thus can store 30 unit prices. The SG series scale has 12 PLU keys, thus can store 12 unit prices. -
Page 10: Clearing Totaling Memory
SF/SG Series Operating Instructions Final Step - Recalling the TOTAL Press . Each display reads: WEIGHT UNIT PRICE MODE PRICE Total 550.00 Total Number of Totaling Indication Total Price items calculated (TOTAL mode) 8. Clearing Totaling Memory Step 1: While in the TOTAL mode, press Note about Totaling Items: •... -
Page 11: Calculating The Correct Change
SF/SG Series Operating Instructions 10. Calculating the Correct Change The purpose of this function is to allow the operator to determine the correct change to return to the customer once payment has been made. Example: There have been 4 entries and the total cost of the transaction is $80.00. WEIGHT PRICE UNIT PRICE... -
Page 12: Automatic Cancellation Of A Unit Price
SF/SG Series Operating Instructions 12. Automatic Cancellation of a Unit Price In very busy applications, it may be more convenient for the Unit Price entry to return to zero after each operation. Note: To use this function, F2 must be set to 0. Refer to “13. Setting “F” Functions”. To do this, press while the display is in normal operation. - Page 13 SF/SG Series Operating Instructions Settings F1: Auto display off 0: Yes 1: No F2: Cancellation of unit price 0: Selectable 1: No 2: Yes F3: Output Data 0: Key trigger mode 1 1: Key trigger mode 2 (Refer to the note below.) 2: Command mode 3: Stream mode 4: Key trigger mode 3 with delay 5: Key trigger mode 3 without delay...
-
Page 14: Connecting The Scale To The Ad-8124 Label Printer
SF/SG Series Operating Instructions 14. Connecting the Scale to the AD-8124 Label Printer Note about Connection to the AD-8124 • To connect the SF/SG scale to the printer, use an RS-232C crossover cable (D-Sub 9-pin socket type) such as an AX-KO1371-200 (2 m). rP 4.00 “... - Page 15 SF/SG Series Operating Instructions 14-3 Setting the printer internal clock Set the printer internal clock as follows: Example: Set the clock to 9:45, June 10, 2001. Step 1: While holding down , turn the scale’s power switch on. All the displays TARE “- - - - - - -”...
- Page 16 SF/SG Series Operating Instructions Step 6: Press the PLU 2 key. The data will be sent to the printer and the scale will return to the normal weighing mode. If the scale will not return to the normal weighing mode, check the values entered.
- Page 17 SF/SG Series Operating Instructions Step 2: Using the numerical keypad, enter a 3-digit label number. If an error is made, press to clear the values. And re-enter the values. SF series SG series PRICE WEIGHT UNIT PRICE set ln WEIGHT set ln PRICE UNIT PRICE...
