rear lIghts anD sIDe lIghts: changing bulbs
1
Direction indicator lights/side
lights and brake lights
After opening the tailgate, open the flap
of the light concerned.
To remove the rear lights unit, undo
nut 1.
The bulbs are under pres-
sure and can break when
replaced.
risk of injury.
Release the rear light assembly from
outside the vehicle by pulling towards
the rear.
To access the bulbs, unclip the bulb
holder by pressing the two clips 2.
Replace the bulbs.
Clip bulb holder 2 back on.
Refit the rear lights unit.
Retighten nut 1, holding the rear lights
unit in its position and check that it is
secure.
(1/2)
2
3 Brake light
P21 W bulb.
4 Direction indicator lights
PY21 W bulb.
5 side light
R5 W bulb.
6 reversing light
P21W bulb.
7 rear fog light
P21 W bulb.
note: both light units are fitted with
a bulb, but only the bulb on the
driver's side works.
3
4
5
6
7
5.19
