ROOF BARS

1
Access to the mounting
points
Open the doors. Behind seal 2 are
blanking bolts 1 which protect the
mounting bolt locations.
Never remove blanking
bolts 1 without plugging the
holes afterwards.
3.40
When fitting roof bars, replace the
blanking bolts with the mounting bolts
supplied with the roof bars.
2
If original roof bars, ap-
proved by our Technical
Department, are supplied
with screws, only use these
screws for attaching the roof bars to
the vehicle.
For information on the range of
equipment adapted to your vehi-
cle, we advise you to consult an ap-
proved Dealer.
Refer to the fitting instructions for in-
formation on how to fit roof bars and
conditions of use.
Please keep these instructions with
the rest of the vehicle documenta-
tion.
Maximum permissible load on
roof rack: refer to the information
on "Weights" in Section 6.
