3.3

Loading Documents

This section describes how to load documents onto the scanner.

■ How to load documents

1. Align the edges of the document.
Align the edges of the document as follows:
1) Align the edges of the document.
2) Check the number of sheets in the document stack.
HINT
ATTENTION
v
Before loading a stack of document onto the scanner, fan it as follows:
1) Separate the documents into stacks of 5 mm thick or less.
2) Hold both ends of the document stack, and bend the document stack into an arch.
Aligh both edges of the document stack so it can be scanned correctly.
As a guideline the maximum number of sheets that can be loaded on the scanner is
as follows:
- A4-size paper or smaller that makes a document stack of 0.2" (5 mm) or less (50
2
sheets at 64 g/m or 17 lb)
Scanning accuracy increases when
the document is loaded onto the
scanner so that the leading edges
of the papers form a step-like
pattern as shown in the figure.
Do not scan more than 50 sheets continuously. The file may not be
created due to the file size becoming too large.
ScanSnap fi-5110EOXM Operator's Guide

3.3 Loading Documents

Step-like
Scanning direction
0.2" (5mm)
