LCD Backlight Brightness Adjustment Connector (LCDPJ1)

1.5.3

COM1/COM2 RI/+5V Selection (COMAJ1, COMBJ1)

1.5.4

COM1/COM2 +5V/+12V Selection (COMAPJ1, COMBPJ1)

User's Manual
+5V (Default)
+3.3V
Ring (Default)
+5V
+5V (Default)
+12V
NX800LX
