AMD GEODE NX800LX User Manual page 16

NX800LX
Internal Connector
Label
CFPJ1 CF power connector
CN5 ATX power connector
CN7 Power fan connector
CN8 SM Bus connector
COMB1 Serial port 1 in RS-232 mode
COMB2 Serial port 2 in RS-232 mode
FPANEL1 Front panel connector
IRB1 IrDA connector
IDEB1 Primary IDE connector
J1 AC97 line in connector
J2 GPIO connector
LCDB1 LCD inverter connector
LVDS1 LVDS connector
TTL1 TTL connector
USBB1 USB 2.0 connector
16
Function Note
3 x 2 header, pitch 2.54mm
3 x 2 header
3 x 1 wafer, pitch 2.54mm
4 x 1 wafer, pitch 2.00mm
5 x 2 header, pitch 2.00mm
5 x 2 header, pitch 2.00mm
5 x 2 header, pitch 2.00mm
5 x 1 header, pitch 2.00mm,
22 x 2 header, pitch 2.00mm
5 x 1 header, pitch 2.00mm
6 x 2 header, pitch 2.00mm
5 x 1 header, pitch 2.00mm
HIROSE DF13-20DP-1.25V
HIROSE DF13-40DP-1.25V
5 x 2 header, pitch 2.00mm
Page
21
21
21
22
22
22
23
24
24
25
25
26
26
27
27
