Specifications Summary - AMD GEODE NX800LX User Manual

NX800LX

Specifications Summary

Features
System
CPU
BIOS
System Chipset
I/O Chipset
Memory
SSD
Watchdog Timer
H/W Status Monitor
Expansion Slots
I/O
MIO
IrDA
USB
DIO
8
Onboard AMD Geode LX800 500 MHz @ 0.9 W with 128K L2 Cache &
1
64K L1 Cache CPU
2 AMD Geode CS5536 Companion Chip
3 One 200-pin SODIMM up to 1GB DDR 400 SDRAM
4 24-bit TTL, 18-bit LVDS
5 Realtek RTL8139DL 10/100Mbps LAN
6 1 Mini PCI, Type I/II CF
7 2 COM, 4 USB 2.0
Onboard AMD Geode LX800 @ 0.9 W with 128K L2 Cache or 64K L1 Cache
Award 4 Mb Flash BIOS
AMD Geode LX800/CS5536
Winbond W83627HG-AW
1 x 200-pin SODIMM socket supports up to 1 GB DDR 400 SDRAM
1 x CompactFlash Type I/II socket
Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
Monitoring CPU temperature, voltage, and cooling fan status. Auto throttling
control when CPU overheats
1 x Mini PCI
1 x EIDE (DMA 33), 2 x RS-232, 1 x K/B, 1 x Mouse
115k bps, IrDA 1.0 compliant
4 x USB 2.0 ports
8-bit General Purpose I/O for 4 DI and 4 DO
