Table of Contents

DO NOT

use or place the transceiver in areas with tem-

peratures below -30°C or above +60°C or, in areas subject

to direct sunlight, such as the dashboard.

AVOID

operate the transceiver without running the vehi-

cle's engine. The vehicle's battery will quickly run out if the

transceiver is in transmission while the vehicle's engine OFF.

AVOID

placing the transceiver in excessively dusty envi-

ronments.

AVOID

placing the transceiver against walls. This will ob-

struct heat dissipation.

AVOID

the use of chemical agents such as benzine or al-

cohol when cleaning, as they damage the transceiver sur-

faces.

BE CAREFUL!

The transceiver will become hot when

operating continuously for long periods.

For U.S.A. only

CAUTION: Changes or modifications to this transceiver, not ex-

pressly approved by Icom Inc., could void your authority to operate

this transceiver under FCC regulations.

IMPORTANT ........................................................................ i

EXPLICIT DEFINITIONS ..................................................... i

CAUTIONS .......................................................................... i

TABLE OF CONTENTS ...................................................... ii

1 PANEL DESCRIPTION ............................................. 1-5

I Front panel ............................................................................ 1

I Function display .................................................................... 2

I Programmable function keys ................................................ 3

2 OPERATION ............................................................. 6-8

I Turning power ON ................................................................ 6

I Channel selection ................................................................. 6

I Receiving and transmitting ................................................... 7

D Transmitting notes .......................................................... 7

D Tx code channel selection .............................................. 8

D Tx code number selection .............................................. 8

D DTMF transmission ........................................................ 8

3 CONNECTION AND MAINTENANCE .................... 9-12

I Rear panel and connection ................................................... 9

I Unpacking ........................................................................... 10

I Mounting the transceiver...................................................... 11

I Optional UT-96/UT-105 installation ..................................... 11

I Optional OPC-617 installation ............................................. 12

I Antenna ............................................................................... 12

I Fuse replacement ............................................................... 12

I Cleaning ............................................................................. 12

4 OPTIONAL SmarTrunk II™ OPERATION ........... 13-15

I SmarTrunk II™ and conventional modes ........................... 13

I SmarTrunk II™ operation ................................................... 13

5 OPTIONS .................................................................... 16
