EX500 Serial System
4. How to operate EX500 - GAB1 - X1 ( Rockwell Automation Remote I/O ( RIO))
4 -1. Applicable PLC
Applicable PLCs in which Rockwell Automation Remote I/O ( RIO ) system is installed.
Please contact Rockwell Automation for more details.
・ ・ ・ ・ Representative PLC
SLC500
PLC - 2 / 20
PLC - 5 / 11
PLC - 5 / 30
PLC - 5 / 60L
PLC - 5 / 250
4 -2. Parts description
Power supply connector
Communication port A
Communication port B
Communication port C
Communication port D
a. Fieldbus connector
b. Power supply connector
c. Communication port
d. LED display window
e. Station switch protection cover
！ ！ ！ ！
CAUTION
The station switch protection cover should be tightened with specified tightening torque
after it is opened. ( Tightening torque : 0.6 N・m )
PLC - 2 / 30
PLC - 3 / 10
PLC - 5 / 15
PLC - 5 / 20
PLC - 5 / 40
PLC - 5 / 40L
PLC - 5 / 80
PLC - 5 / VME
PLC - 5 / V40B
Fieldbus connector
(1771 Remote I/O)
: Port for PLC connection.
: The power source for Input Unit, SI Unit, and control and
:
: The state of the power source supply and the PLC
: Switches for the operation setting are inside.
PLC - 5 / 25
PLC - 5 / 60
for the solenoid valve is connected through this port.
Input Unit Manifold or the Manifold Valve with the SI Unit
is connected through this port.
communication is displayed. ( Refer to section 4 -3 )
( Refer to section 4 -4 )
- 17 -
LED display window
Station switch protection cover
EX## - OME0008
