EX500 Serial System
3 -3 -3. Input Block
How to Order
E X 5 0 0 - I E 1
Connector type
Input specification
1 M8 connector, PNP
2 M8 connector, NPN
3 M12 connector, PNP
4 M12 connector, NPN
5 8 point unit, M8 connector, PNP
6 8 point unit, M8 connector, NPN
Input Block specification
Item
Corresponding sensor
Sensor connector
Input points
Rated voltage
Logical " 1 " input voltage
Logical " 0 " input voltage
Logical " 1 " input current
Logical " 0 " allowable current
Input delay
Display
Insulation
Sensor supply current
Weight
Note) Internal circuit of the M12 Input Block and the position of the key for installing the sensor
connector of the M12 Input Block.
Each No.2 pin of each sensor connector of the M12 Input
Block is connected to the next No.4 pin which is the sensor
signal input pin of the connector.
Therefore, it is possible to incorporate the two input signals
of the sensor into one cable. ( just like a Y connection )
Confirm the specification of the output signal when
connecting the sensor. It will cause the malfunction.
The position of the key for installing the sensor connector
of the M12 Input Block refers to the right figure.
Confirm the type of the sensor connector when
selecting a sensor.
GW Unit compatible
DeviceNet
Nil
PROFIBUS-DP
-X1
Remote I/O ( RIO )
Current source type ( PNP output )
M8 connector ( 3 pin, socket )
Pin NO.
1. power supply (24V DC )
3. power supply ( 0V )
4. input
15V to 26.4V
0V to 5V
5mA Typ.
1.5mA
[ M8 : 20g ] [ M12 : 40g ] [ 8 points ( M8) : 55g ]
8 point unit Input Block ( M8 )
Specification
Current sink type ( NPN output )
M12 connector ( 4 pin, socket )
Pin NO.
1. power supply (24V DC )
2. ( input ) *Note
3. power supply ( 0V )
4. input
1
4
3
For Input Block
2 points / 8 points ( M8 only )
24V DC
1m sec. or less
LED ( green - colored ) light up
Nothing
30mA Max. / sensor
3
Input "1" ( n + 1 )
Input "0" ( n )
Figure of M12 Input Block ( the top of view )
- 12 -
M8 Input Block
M12 Input Block
１
4
For Input Block
0V to 8V
19V to 26.4V
- 5mA Typ.
- 1.5mA
Input "0" ( n ) side
Input "1" ( n + 1 ) side
4
Key
１
１
2
Key
EX## - OME0008
2
3
2
3
4
