EX500 Serial System

3 -6. Option

3 -6 -1.

Communication Connector / Cable

1. Communication Connector for Remote I/O ( RIO ) ( EX500 - GAB1 -X1 )
How to Order
E X 5 0 0 - A C 0 0 0 - A B
2
1 3
4
2. Communication Connector Cable for DeviceNet ( EX500 - GDN1 )
How to Order
E X 5 0 0 - A C 0 5 0 - D N
L : Cable length
010 1m
050 5m
M12
1 2
5
4 3
Socket connector
Pin assignment
Signal
Power supply
Drain
Outside
diameter
Sheath color
43.2
Applicable cable diameter
φ6 (φ5～φ6 )
.
40.7
L
Cable specification
AWG24 ( 41 / 0.08 )
AWG22 ( 19 / 0.16 )
AWG22 ( 19 / 0.16 )
Φ7
Light blue
Electric specification
Rated voltage 125V DC
Rated current 3A
Contact
40m ohms or less
resistance
( At 20mV DC or less, 100mA or less )
( connector part )
Insulation
1000M ohms or more ( At 500V DC )
resistance
Withstand
1500V AC 1min.
voltage
( Leak current 1mA or less )
( connector part )
Electric specification
Rated voltage 125V DC
Rated current 3A
Contact
40m ohms or less
resistance
( At 20mV DC or less, 100mA or less )
( connector part )
Insulation
1000M ohms or more ( At 500V DC )
resistance
Withstand
1500V AC 1min.
voltage
( Leak current 1mA or less )
( connector part )
50
Terminal NO.
1
2
3
4
5
Wiring
Terminal NO.
Blue /
White
Red /
Black
-
- 14 -
EX## - OME0008
Cable core
sheth color
: DRAIN
Red : V+
Black : V-
White : CAN H
Blue : CAN L
Cable color / Signal name
1 Bare DRAIN
2 Red
Black
3
4 White CAN H
5 Blue CAN L
V+
V-
