3 -6 -2. Branch Cable with M12 Connector
How to Order
E X 5 0 0 - A C 0 3 0
L : Cable length
003
0.3m
005
0.5m
010
1m
030
3m
050
5m
Electric specification
Rated voltage 36V DC
Rated current
1.5A
Contact
40m ohms or less
resistance
( At 20mV DC or less, 100mA or less )
( connector part )
Insulation
1000M ohms or more ( At 500V DC )
resistance
Withstand
1000V AC 1min.
voltage
( Leak current 1mA or less )
( connector part )
M12
M12
8
1
2
7
6
5
Socket connector
Pin assignment
S S P S
-
48
Straight connector type
31.3
3
Terminal NO.
4
1
2
3
4
5
6
7
8
Connector specification
SSPS
Socket side : Straight, Plug side : Straight
SAPA
Socket side : Angled, Plug side : Angled
L
L
Angled connector type
Cable core
sheath color
1
White
2
Brown
3
Green
4
Yellow
5
Gray
6
Pink
7
Blue
8
Shield
Wiring
- 15 -
52
M12
M12
31.3
8
2
3
4
5
Plug connector
Pin assignment
EX## - OME0008
1
7
6
