Viewing Sp Information; Synchronizing Blades For A Blade Chassis; Changing The Sol Port Number - Avocent MERGEPOINT SP MANAGER Installer/User Manual

• System: Use this tab to remotely perform system operations, including power, chassis and
other advanced operations.
• Configuration: Use this tab to remotely configure managed SPs, including changing LAN
parameters, managing user accounts, configuring PET settings, configuring SoL, setting
BMC time, performing provisioning recovery and setting up SNMP and Native IP.
• SEL: Use this tab to view SP SEL information.
• Sensor: Use this tab to view the sensor output from managed target.
• System Sessions: Use this tab to activate and use SoL or the SP, Telnet, or SSH consoles
for accessing managed SPs. You can also transparently access native TCP services on an SP
through DirectCommand.
• Remote Control: Use this tab to connect to Remote Desktop Protocol (RDP) and Virtual
Network Computing (VNC) servers.

Viewing SP information

To view the SP information:
1. In the side navigation bar, click an SP name.
2. Click the Properties tab.
3. In the top navigation bar, click SP. A window displaying SP information appears.

Synchronizing blades for a blade chassis

NOTE: The following procedure is only for SPs with blade chassis.
To synchronize the blades:
1. In the side navigation bar, click an SP name.
2. Click the Properties tab.
3. In the top navigation bar, click SP.
4. Click Synchronize BladeCenter. The blades on the side navigation bar are synchronized
with the selected SP.

Changing the SoL port number

To change the SoL port number:
1. In the side navigation bar, click an SP name.
2. Click the Properties tab.
3. In the top navigation bar, click SP.
Chapter 3: Operations 69
