MergePoint® SP Manager Installer/User Guide
140
Parameter
network hosts
network interface
eth0|eth1 for IPv4
network interface
bond0|eth0|eth1|priv0|br0
for IPv4
Command
After the add command is used to add a host to the hosts table, use the set command
to configure the host's IP address and optional alias.
Synopsis: set network hosts <IPaddress> name <host_name> alias <alias_name>
Example: set network hosts 192.168..100 host MergePoint5300 alias MP5300
NOTE: See the add network hosts command in The following table shows the
parameters that can be added using the add command. Summary of How to
Configure the Top Level Parameters on page 136 shows additional parameters and
values that must be set for each parameter after the parameter is added. When a
parameter is shown in the Parameter Level 2 column, the Parameter Level 1 and
Parameter Level 2 parameters must be entered together with the add command; for
example, to add a service processor user, you must enter add spmanager user
<username>; the user must then be configured after adding, using the set command.
on page 127.
Use the set command to configure one of the network interfaces with IPv4 for the
MergePoint SP5x00 manager.
Synopsis: set network interface eth0|eth1 method <static|dhcp> address <ip>
netmask <netmask> broadcast <broadcast> gateway <ip> mtu <num> alias <alias
name>
Example: set network interface eth1 method static address 192.168.1.100 netmask
255.255.255.0 gateway 192.168.1.1
Use the set command to configure one of the network interfaces with IPv4 for the
MergePoint SP5x24/SP5x40 manager.
Synopsis: set network interface bond0|eth0|eth1|priv0|br0 method <static|dhcp>
address <ip> netmask <netmask> broadcast <broadcast> gateway <ip> mtu <num>
alias <alias name>
Example: set network interface br0 method static address 192.168.1.100 netmask
255.255.255.0 gateway 192.168.1.1
set network interface priv0 address 192.168.1.120 netmask 255.255.255.0
