Avocent MERGEPOINT SP MANAGER Installer/User Manual page 149

Table 7.3: Setting Top Level CLI Parameters
Parameter
adsap2
auth
Command
Avocent DS Authentication Protocol configuration.
Synopsis: set adsap2 state <secure | trust-all> authserver <ip-address>
Example: set adsap2 state trust-all authserver 2.2.2.2
NOTE: The state of "secure" means the server is being managed by the DSView 3
software, while the state of "trust-all" means the server is unmanaged by the DSView
3 software. The parameter "authserver" specifies the IP address of authorization
server.
Use the set command with the type parameters to set an authentication type for logins
to the MergePoint SP manager, either krb5, ldap, nis, radius, smb, or tacplus.
Use the set command with the auth type ppp parameters to set an authentication type
for logins through the auxport modem and pcmcia/cardbus modems.
Authentication types supported for the MergePoint SP manager and for SPs are listed
in Configuring External Authentication Services on page 95.
Synopsis: set auth type <typename> nis domainname <name> server
<ip|broadcast> radius|tacplus accthost <server-name> authhost <server-name>
secret <secret> timeout <count> retries <count> tacplus service <ppp|raccess> krb5
realm <realm> server <ip-address> ldap host <host> base <base-name> binddn <dn>
bindpw <password> pam_login_attribute <attribute> ssl <on|off|start_tls> smb domain
<name> server <ip-address>
Example: set auth type local nis domainname subavt server 1.1.1.1 radius authhost1
a1 authhost2 a2 accthost1 c1 accthost2 c2 secret pwd timeout 4 retries 2 tacplus
authhost1 1.1.1.1 authhost2 12.2.2.2 accthost1 1.1.1.1 accthost2 12.2.2.2 secret
pwdd retries 2 timeout 4 service ppp krb5 realm dm server 2.2.2.2 ldap host 127.0.0.1
base dc=padl,dc=com binddn bdl bindpw pwd pam_login_attribute df ssl on smb
domain sudom server1 2.2.2.1 server2 3.3.3.3
Chapter 7: Using the CLI Utility 137
