- Page 1 Doc #: 118001UA Part #: 07M1206P-A MODEM E , X.21 LIMINATOR 1 2 0 6 P (CTS ME-X.21) NSTALLATION AND PERATIONS ANUAL An ISO-9001 Copyright© 2000 Patton Electronics Co., All Rights Reserved Certified Company...
-
Page 2: Copyright Notice
1 2 0 6 P ATTON LECTRONICS NSTALLATION PERATIONS ANUAL 1 1 8 0 0 1 U A COPYRIGHT NOTICE Copyright© 2000 Patton Electronics Co., All Rights Reserved. PROPRIETARY NOTICE The information contained herein is proprietary and confidential to Patton Electronics Co. - Page 3 1 2 0 6 P ATTON LECTRONICS NSTALLATION PERATIONS ANUAL 1 1 8 0 0 1 U A EMISSION REQUIREMENTS FCC CLASS A Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC rules.
-
Page 4: Table Of Contents
1 2 0 6 P ATTON LECTRONICS NSTALLATION PERATIONS ANUAL 1 1 8 0 0 1 U A ABLE OF ONTENTS CHAPTER 1 - O PERATION Clocking ........................... 1 - 1 Delaying INDICATE ......................1 - 1 Power ..........................1 - 1 Approvals......................... -
Page 5: Chapter 1 - O
110 or 220 Volt operation is provided by a convenient switch located on the rear panel of the 1206P (CTS ME-X.21). Simply install the proper fuses (110VAC - .16ASB, 250V or 220VAC - .8ASB, 250V) and power plug for the country of use and select the proper line voltage and the unit is ready for operation. -
Page 6: Approvals
Technical Support. Available Options 1206P (CTS ME-X.21) is available in both stand-alone subset or rack-mountable versions (1206PRC). Various configuration of the interface are also available from the factory. The 1206PRC fits into the Model 1010R16 16 Card Rack Assembly. -
Page 7: Chapter 2 - S
NSTALLATION Power Connection Before connecting the 1206P (CTS ME-X.21) to a AC power source the top cover must be installed and secured with the supplied #8-32 screws. The unit is supplied with a 110/220VA voltage switch, turn the switch with a coin or screw driver to the appropriate voltage for your country. -
Page 8: Disassembly
X.21 (DB-15) connectors should be used to connect the two terminals to the 1206P (CTS ME-X.21). Set the switches and Jumpers to match the required configuration using the descriptions in this chapter and the strapping guide in the appendix. -
Page 9: High Speed Option Rates (Jp7,Jp8,Jp9,Jp10)
1 2 0 6 P ATTON LECTRONICS NSTALLATION PERATIONS ANUAL 1 1 8 0 0 1 U A Selection of internal rates is provided by configuration of SW1 positions 1 through 4 and JP7 through JP10 if the High Speed Option has been installed by the factory. The following table shows the rates available: SW1-1 SW1-2... - Page 10 1 2 0 6 P ATTON LECTRONICS NSTALLATION PERATIONS ANUAL 1 1 8 0 0 1 U A The factory test jumper must be installed for the Modem eliminator to properly function. Insure this jumper is installed prior to operation of the unit. &...
-
Page 11: Appendix
1 2 0 6 P ATTON LECTRONICS NSTALLATION PERATIONS ANUAL 1 1 8 0 0 1 U A PPENDIX Technical Specifications Application Data Rates I, S Interconnect two X.21 terminal 4.8K, 9.6K, 14.4K, 19.2K, Channel Interface type devices 28.8K, 38.4K. 48K, 56K, Two CCITT X.21(V.11) female 57.6K, 64K, 72K, 128K, 192K, Capacity... - Page 12 Install Only One Jumper to Select the Required Rate Power Baud Rate Select SW1 Speed HS Option 768K 384K 192K 128K Ch 1 IND Delay SW2 CGND Delay Constant 57.6K 0 mS DGND 8 mS 50mS 38.4K 28.8K 19.2K 14.4K Ch 2 IND Delay SW2 9.6K Delay...
