Patton electronics 1140RC User Manual

Rs-232 fiber optic rack card modem w/ v.54 & v.52 diagnostics
Hide thumbs Also See for 1140RC:

Advertisement

Quick Links

Dear Valued Customer,
Thank you for purchasing Patton Electronics products! We do
appreciate your business. I trust that you find this user manual helpful.
We manufacture one of the widest selections of data
communications products in the world including CSU/DSU's, network
termination units, powered and self-powered short range modems, fiber optic
modems, interface converters, baluns, electronic data switches, data-line surge
protectors, multiplexers, transceivers, hubs, print servers and much more. We
produce these products at our Gaithersburg, MD, USA, facility, and can
custom manufacture products for your unique needs.
We would like to hear from you. Please contact us in any of the
following ways to tell us how you like this product and how we can meet your
product needs today and in the future.
Web:
http://www.patton.com
Sales E-mail:
sales@patton.com
Support E-mail:
support@patton.com
Phone - Sales
(301) 975-1000
Phone - Support
(301) 975-1007
Fax:
(301) 869-9293
Mail:
Patton Electronics Company
7622 Rickenbacker Drive
Gaithersburg, MD 20879 USA
We are committed to a quality product at a quality price. Patton
Electronics is BABT and ISO 9001 certified. We meet and exceed the highest
standards in the industry (CE, UL, etc.).
It is our business to serve you. If you are not satisfied with any
aspect of this product or the service provided from Patton Electronics or its
distributors, please let us know.
Thank you.
Burton A.Patton
Vice President
P.S. Please tell us where you purchased this product.
_________________________________________________________
_________________________________________________________
_________________________________________________________
_________________________________________________________
_________________________________________________________
_________________________________________________________
_________________________________________________________
USER
MANUAL
MODEL 1140RC
RS-232 Fiber Optic
Rack Card Modem
w/ V.54 & V.52 Diagnostics
Part #07M1140RC-C
Doc #018031UC
Revised 6/6/97
C E R T I F I E D
An ISO-9001
Certified Company
SALES OFFICE
(301) 975-1000
TECHNICAL SUPPORT
(301) 975-1007
http://www.patton.com

Advertisement

Table of Contents
loading

Summary of Contents for Patton electronics 1140RC

  • Page 1: User Manual

    P.S. Please tell us where you purchased this product. _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ USER MANUAL MODEL 1140RC RS-232 Fiber Optic Rack Card Modem w/ V.54 & V.52 Diagnostics Part #07M1140RC-C SALES OFFICE Doc #018031UC (301) 975-1000 Revised 6/6/97 TECHNICAL SUPPORT...
  • Page 2: Warranty Information

    The Model 1140RC has been tested and found to comply with the limits for a Class A computing device in accordance...
  • Page 3: General Information

    3.1 FRONT CARD CONFIGURATION The Model 1140RC front card has two sets of eight switches (S1 & S2), which are mounted on the PC board (Figure 1, below). These configuration switches allow you to configure the Model 1140RC for a wide range of applications.
  • Page 4: Configuration Switch Set "S1"

    S1-7 Async./Sync. S1-8 Carrier Control S1-1 through S1-4: Data Rate Setting Switches S1-1 through S1-4 are set in combination to determine the asynchronous and synchronous data rate for the Model 1140RC. S1-1 S1-2 S1-3 S1-4 S1-5 and S1-6: Clock Source transmit clock source for the Model 1140RC.
  • Page 5: Configuration Switch Set "S2"

    Basic -2.5% to +2.3% Extended S2-4 and S2-5: RTS/CTS Delay amount of delay between the time the Model 1140RC “sees” RTS and when it sends CTS. Options are no delay, 7 ms and 53 ms. Factory Default 10 bits S2-8: V.54 Loopback Test Enable Off -2.5% to +2.3%...
  • Page 6: Installation

    4.0 INSTALLATION This section describes the functions of the Model 1000R16 rack chassis, tells how to install front and rear Model 1140RC cards into the chassis, and provides instructions for connecting the interface cables. 4.1 THE MODEL 1000R16 RACK CHASSIS The 1000R16 Rack Chassis (Figure 5, below) has sixteen short range modem card slots, plus its own power supply.
  • Page 7 Figure 6. Model 1140RC interface card options 4.3.1 RS-232 CONNECTION The RS-232 port on the rear card of the Model 1140RC is wired as a DCE, and uses a female HD-26 connector. The HD-26 is an alternate connector according to the EIA RS-232E specification, and the pin-out is the same as a standard DB-25.
  • Page 8: Fiber Connections

    The red “RTS” and “CD” indicators glow solid to show faces down the control signal is off. When the 1140RC is connected to a DTE, RTS will glow green for an incoming signal on RS-232 pin 4. CD will glow green for an incoming signal from the line, and an outgoing signal on RS-232 pin 8.
  • Page 9: Test Modes

    The Local Analog Loopback (LAL) test checks the operation of the local Model 1140RC, and is performed separately on each unit. Any data sent to the local Model 1140RC in this test mode will be echoed (returned) back to the user device. For example, characters typed on the keyboard of a terminal will appear on the terminal screen.
  • Page 10: Specifications

    Locate the lower of the two toggle switches on the front panel of the Model 1140RC and move it to the right. This will activate the V.52 BER test mode and transmit a “511” test pattern to the other unit. If any errors are present, the receiving modem’s red “Error”...
  • Page 11: Factory Replacement Parts

    APPENDIX B FACTORY REPLACEMENT PARTS The Patton Model 1140RC rack system features interchangeable rear half cards, power cords/fuses for international various operating environments and other user-replaceable parts. Model numbers and descriptions for these parts are listed below: Patton Model # Description 1000RPEM...120/240V Rear Power Entry Module...
  • Page 12: Block Diagram

    APPENDIX D BLOCK DIAGRAM Copyright © Patton Electronics Company All Rights Reserved...
