Patton electronics 1088/C User Manual

Mdsl modem with v.35 or x.21 interface
Hide thumbs
Table of Contents

Advertisement

Quick Links

Part# 07M1088-UM
Doc# 03312U2-001
Rev. E
Revised 10/23/06
An ISO-9001Certified
Company
USER
MANUAL
MODEL 1088/C
and 1088/D
mDSL Modem with
V.35 or X.21 Interface
SALES OFFICE
(301) 975-1000
TECHNICAL SUPPORT
(301) 975-1007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1088/C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Patton electronics 1088/C

Summary of Contents for Patton electronics 1088/C

  • Page 1 USER MANUAL MODEL 1088/C and 1088/D mDSL Modem with V.35 or X.21 Interface Part# 07M1088-UM SALES OFFICE Doc# 03312U2-001 (301) 975-1000 Rev. E TECHNICAL SUPPORT Revised 10/23/06 (301) 975-1007 An ISO-9001Certified Company...

  • Page 2: Table Of Contents

    Connecting the Model 1088/C (V.35) Serial Interface ....13 Connecting the Model 1088/C (V.35) to a “DTE” Device.... 13 Connecting the Model 1088/C (V.35) to a “DCE” Device ... 14 Connecting the Model 1088/D (X.21) Serial Interface ....14 Connecting the Model 1088/D (X.21) to a “DCE” or “DTE”...
  • Page 3 A.13 Line Interface ................28 A.14 mDSL Physical Connection ............28 A.15 Environment ................28 Factory Replacement Parts and Accessories......29 Model 1088/C Interface Pin Assignments....... 30 Model 1088/D Interface Pin Assignments....... 31 Model 1088/C and 1088/D Transmission distance chart ..32...

  • Page 4: Warranty Information

    1.0 WARRANTY INFORMATION Patton Electronics warrants all Model 1088 components to be free from defects, and will—at our option—repair or replace the product should it fail within one year from the first date of shipment. This warranty is limited to defects in workmanship or materials, and does not cover customer damage, abuse or unauthorized modification.

  • Page 5: Service

    1.3 SERVICE All warranty and non-warranty repairs must be returned freight prepaid and insured to Patton Electronics. All returns must have a Return Materi- als Authorization number on the outside of the shipping container. This number may be obtained from Patton Electronics Technical Services at: •...

  • Page 6: General Information

    LAN to LAN interconnection, and WAN access networks over 3.6 miles/5.8 km (1.054 Mbps on 24AWG/.5 mm wire). Model 1088/C provides a V.35 interface on an M/34 female connector. Model 1088/D provides an X.21 interface on a DB-15 female connector. Features include loopback diagnostics, SNMP/HTTP remote management capabilities using NetLink Plug-and-Play and inband externally accessible configuration...

  • Page 7: Configuration

    3.0 CONFIGURATION The Model 1088 is equipped with two sets of eight DIP switches, which allow configuration of the unit for a wide variety of applications. This section describes switch locations and explains all possible configurations. 3.1 CONFIGURING THE HARDWARE DIP SWITCHES The 16 external switches are grouped into two eight-switch sets, and are externally accessible from the underside of the Model 1088 (See Figure 1).

  • Page 8: Configuration Dip Switch Set "S2

    Reserved Switch S2-8: Enable/Disable Loop Tests from DTE. Switch S2-8 may be used to allow Model 1088/C to enter loopback diagnostic tests (Local or Remote) when the V.35 DTE raises the appropriate loop request pin (LLB: Pin L or RDL: Pin N). When Switch S2-8 is in the On position, the Model 1088/C will enter Local Loopback or Remote Loopback at the request of the DTE.

  • Page 9: Configuration Switch Set "S3

    1088/C ignores DTE loop requests. In the Off position, loop requests may still be initiated by the front panel switch. S2-8 Setting DTE Loopback Request Enabled DTE Loopback Request Disabled Configuration Switch Set “S3” Use the six DIP Switches in Switch S3 to enable the DTE bit rate. The following table summarizes default positions of DIP Switch S3.

  • Page 10: Switch S3-7: Reset Software Defaults

    S3-1 S3-2 S3-3 S3-4 S3-5 S3-6 DTE Rate (kbps) 1024 1088 1152 1216 1280 1344 1408 1472 1536 1600 1664 1728 1792 1856 1920 1984 2048 2112 2176 2240 2304 Note Based on the DTE rate chosen, the Model 1088 will automati- cally select the optimum line rate depending on distance and line conditionsfor the distance.

  • Page 11: Switch S3-8: Transmit Data (Td) Sampling Point

    Switch S3-8: Transmit Data (TD) Sampling Point. Switch 3-8 controls the Transmit Data (TD) sampling point. S3-8 Setting Description Normal TD sampled on the falling edge of the 1088 Trans- mit Clock (TC) Invert TD sampled on the rising edge of the 1088 Transmit Clock.
  • Page 12 When the CO and CP units connect over DSL, the CP will enter a pre- defined default configuration (Receive Recovered Clocking). During the negotiation process between the units, the CO unit will configure the DTE rate/line rate on the CP unit as defined by the settings of the CO unit.

  • Page 13: Installation

    The Model 1088/C provides a V.35 DCE (Data Circuit Terminating Equip- ment) interface on an M/34 female connector. As a DCE, this interface is designed to connect to DTE equipment, such as a router. When connect- ing the V.35 interface of the Model 1088/C to your DTE device, use a...

  • Page 14: Connecting The Model 1088/C (V.35) To A "Dce" Device

    Figure 5. Connecting the Model 1088/C to V.35 Serial DTE Connecting the Model 1088/C (V.35) to a “DCE” Device The Model 1088/C provides a V.35 DCE (Data Circuit Terminating Equip- ment) interface on an M/34 female connector. As a DCE, this interface is designed to connect to DTE equipment, such as a router.

  • Page 15: Opening The Case

    DTE (Data Terminal Equipment) for connection to DCE such as a modem or multiplexer. When connecting the X.21 interface of the Model 1088/C to your DTE device, use a X.21 straight through cable (See Figure 7). DSL Span...

  • Page 16: Connecting Power

    The DCE/DTE strap is located on the top side of the 1088/D pc board (See Figure 9, below). The arrows on the top of the strap indicate the configuration of the X.21 port (for example, if the DCE arrows are point- ing toward the DB-15 connector, the X.21 port is wired as a DCE).

  • Page 17: 120 Vac Power (Us)

    120 VAC Power (US) The 100–132 VAC adapter supplied with the U.S. version of the Model 1088 is a wall mount type and may be plugged into any approved 120 VAC wall jack. 230 VAC Power (International) The 230 VAC adapter supplied with the International version of the Model 1088 is a wall mount type and may be plugged into any approved 230 VAC wall jack.

  • Page 18: Operation

    5.0 OPERATION Once the Model 1088 is properly configured and installed, it should oper- ate transparently. This sections describes power-up, reading the LED status monitors, and using the built-in loopback test modes. 5.1 POWER-UP To apply power to the Model 1088, first be sure that you have read sec- tion 4.4, “Connecting Power”...

  • Page 19: Model 1088 Led Descriptions Chart

    • Only at power up, blinks once every 200 ms if the DTE Rate is set to an unsupported settings Glows yellow to indicate that the Model 1095 has been placed in Test Mode. The unit can be placed in test mode by the local user or by the remote user.

  • Page 20: Overview

    Overview Figure 13 shows the major elements used in the loop-back and pattern tests available in the Model 1088. Each block has several functions. Fol- lowing Figure 13 are descriptions that show how the elements are used during Test Modes. Pattern Pattern Loop...
  • Page 21 lish a connection after the framer begins seeing unframed pack- ets. The Test Model Timing Chart below shows the amount of time the framer must see consecutive unframed packets before the unit will restart and try to establish a new line connection. The reason that there are different Restart Times will become apparent after reading the rest of the document.

  • Page 22: Loops And Patterns

    5.4 LOOPS AND PATTERNS The following section describes the Test Modes used in the Model 1088. At the bottom of each Test Mode, a figure is included to show the data path.. Pattern Loop Loop Pattern Framer Framer Line Gen/Det Gen/Det Contr Contro...
  • Page 23 data presented at the far end DTE will be transmitted to the local DTE and then looped back within the local DTE Loop Con- trol block with the Processor. After the Local Loop is deselected, the units will be placed back into DataMode and the normal data paths will be re-established.
  • Page 24 DTE are not valid. Because the data is unframed there is no way for the framer to send this data out to the DTE. This is an important distinction because other Patton units will send out the 511 pattern. When the unit is placed into a Mode 2 Local Loop, the 511/511E pattern generator on the local unit is unavailable for transmis- sion.
  • Page 25 Pattern Loop Loop Framer Pattern Framer Line Contro Gen/Det Contr Gen/Det Processor Processor Figure 19. Block Remote Loop with 511/511E Remote Digital Loop with 511/511E The Remote Digital Loop with 511/511E is shown above. After RDL is established the Remote units' Restart Timer is set to one minute.

  • Page 26: Using The V.52 (Ber) Test Pattern Generator

    units enable the 511/511E pattern within 4 seconds of each other, both units will be transmitting and receiving the 511/511E pattern. Both framers are now receiving unframed data and will restart after one minute. The 511/511E pattern generators will TimeOut after 45 seconds re-enabling the normal data path. The ER led will begin flashing until the user terminates the test.

  • Page 27: Specifications

    Internal, External, or Receive Recovered A.2 DTE RATE All 64k steps from 64 to 2304 kbps A.3 DTE INTERFACE V.35 (Model 1088/C), DCE Orientation; X.21 (Model 1088/D), DCE or DTE Orientation depending upon orienta- tion of PC-board mounted daughter board A.4 DTE CONNECTOR...

  • Page 28: Power

    A.8 POWER +5 VDC external desk top power supply, 90-260VAC, 50-60 Hz (Univer- sal Input), 10W or -48 VDC A.9 COMPLIANCE FCC Part 15, CE, CTR1 A.10 TRANSMISSION LINE Single Twisted Pair A.11 LINE CODING CAP (Carrierless Amplitude and Phase Modulation A.12 LINE RATES (DSL LINE) 144, 272, 400, 528, 784, 1040, 1552, 2064, 2320 kpbs A.13 LINE INTERFACE...

  • Page 29: Factory Replacement Parts And Accessories

    APPENDIX B FACTORY REPLACEMENT PARTS AND ACCESSORIES Model # Description 1088/C V.35 mDSL Rocket (CAP) 1088/D X.21 mDSL Rocket (CAP) 080551 120V Power Supply 080552 230V Power Supply 48V-PSM DC Power Supply Module 08055DCUI 100-240VAC (+5V ±5% reg. DC/2A) Universal Input Adapter 0805EUR European Power Cord CEE 7 (“A”)

  • Page 30: Model 1088/C Interface Pin Assignments

    APPENDIX C MODEL 1088/C INTERFACE PIN ASSIGNMENTS V.35 Interface (M/34 Female Connector) (DCE Orientation) Pin # Signal SGND (Signal Ground) RTS (Request to Send) (DTE Source) CTS (Clear to Send) (DCE Source) DSR (Data Set Ready) (DCE Source) CD (Carrier Detect) (DCE Source)

  • Page 31: Model 1088/D Interface Pin Assignments

    APPENDIX D MODEL 1088/D INTERFACE PIN ASSIGNMENTS X.21 Interface (D-Sub-15 Female Connector) (DTE /DCE Orientation) Pin # Signal Frame Ground T (Transmit Data-A) (DTE Source) C (Control-A) (DTE Source) R (Receive Data-A) (DCE Source) I (Indication-A) (DCE Source) S (Signal Element Timing-A) (DCE Source) BT (Byte Timing-A) (DCE Source) SGND (Signal Ground) T/ (Transmit Data-B) (DTE Source)

  • Page 32: Model 1088/C And 1088/D Transmission Distance Chart

    APPENDIX E MODEL 1088/C AND 1088/D TRANSMISSION DISTANCE CHART Table 3: Transmission Distance - Patton NetLink Model 1088 Transmission Distance - Patton NetLink Model 1088 No Cross Talk Line Rate DTE Rates 26 AWG (0.4mm) 24 AWG (0.5mm) kbps feet miles km...
