Operator Display Screens; Standard Screens; Custom Screens - Trane BCU Operator Display Operations

BCU Operator Display Overview
6

Operator Display Screens

The operator-display touch screen can display both standard and custom
screens, confirmation screens, and a security screen.

Standard Screens

Standard screens are a part of the Tracer Summit BCU operator display
software. (See Appendix B on page 67 for a list of standard screens avail-
able at the operator display.) Standard screens are identified by a title bar
at the top of each screen (see Figure 4). .
Figure 4: Standard Screen—Example

Custom Screens

The Trane installer or programmer can create custom screens for use at
the operator display. These screens can be used in place of standard
screens to accomodate specific user requirements at your facility. Custom
screens can be linked to standard view screens by a navigation button
(see Figure 5 on page 7).
Note:
Navigation of custom screens is not discussed in this guide.
