Chapter 1 Bcu Operator Display Overview - Trane BCU Operator Display Operations

BMTW-SVU02C-EN
Chapter 1
BCU Operator Display
Overview
The BCU operator display is a liquid crystal display (LCD) touch screen.
It is installed in Tracer Summit BMTW building control units (BCUs) as
an option (see Figure 1). The operator-display touch screen enables you to
perform most of the Tracer Summit PC Workstation daily activities at the
BCU. The Tracer Summit workstation is the PC software program that
enables you to control and monitor the operation of HVAC equipment in
your building.
From the operator-display touch screen you can perform the following
tasks:
View and manage alarms and events
•
View and change setpoints
•
Override schedules and equipment
•
Modify schedule start times and stop times
•
Maintain and calibrate the display
•
Figure 1: BCU Operator Display
Operator-display
touch screen
BMTW BCU
1
