High-Shelf EQ
The High-Shelf EQ boosts or cuts frequencies at
and above the Frequency setting. The amount of
boost or cut is determined by the Gain setting.
The Q setting determines the shape of the shelv-
ing curve.
1 Band EQ set to High-Shelf EQ
Low-Shelf EQ
The Low-Shelf EQ boosts or cuts frequencies at
and below the Frequency setting. The amount
of boost or cut is determined by the Gain set-
ting. The Q setting determines the shape of the
shelving curve.
1 Band EQ set to Low-Shelf EQ
56
DigiRack Plug-ins Guide
Peak EQ
The Peak EQ boosts or cuts a band of frequencies
centered around the Frequency setting. The
width of the affected band is determined by the
Q setting.
1 Band EQ set to Peak EQ
Low-Pass Filter
The Low-Pass filter attenuates all frequencies
above the cutoff frequency setting at the se-
lected rate (6 dB, 12 dB, 18 dB, or 24 dB per oc-
tave) while letting all frequencies below pass
through. No gain control is available for this fil-
ter type.
1 Band EQ set to Low-Pass Filter
