  • Page 1 ONSIP 02DP7...
  • Page 2 ’ ’ Directions Be careful not to cause any physical damage by dropping or throwing ONSIP O2DP7. Especially keep the device out of reach from children. Do not disassemble ONSIP O2DP7. No After Service is assumed when disassembled. Use only the power adapter provided with ONSIP O2DP7. Be careful to prevent moisture or water penetration into the unit.
  • Page 3 ’ ’ Caution Any changes or modifications to this device could void the warranty. Revision History Date Revision Details 2011-11-01 First manual revision creation. Rev.1.0(Nov., 2011)

  • Page 4: Table Of Contents

    ’ ’ Contents Contents ......................4 1. Introduction....................6 1.1. Overview ........................6 1.2. Specification ....................... 7 1.3. Applications of ONSIP O2DP7 ................... 9 2. Product Description ..................10 2.1. Contents ........................10 2.2. Product Preview ....................... 11 2.3. Physical description....................12 2.4.
  • Page 5 ’ ’ 5. Trouble Shooting ..................27 5.1. No power is applied ....................27 5.2. Cannot connect to the Video ..................28 5.3. Windows Vista or Windows 7 ................... 29 5.4. Technical Assistance ....................32 Rev.1.0(Nov., 2011)

  • Page 6: Introduction

    ’ ’ 1. Introduction 1.1. Overview The ONSIP O2DP7 is a state-of-the-art (Megapixel), multi-codec (H.264, MJPEG) IP camera (or network camera) built with embedded software and hardware technology. It enables real time transmission of synchronized video of up to 2 M pixels and audio data. Remote clients can connect to ONSIP O2DP7 for the real time video/audio data through various client solutions running on PC, PDA or mobile phones.

  • Page 7: Specification

    Upgrade Firmware upgrade over IP network Administration Remote administration over IP network Web Viewer Simple viewing over internet explorer Client & Viewer Speco-NVR Standard CMS software Dynamic IP support DDNS support Supported Video/Audio stream encryption ID and Password protection Security...
  • Page 8 ’ ’ Sync to PC Synchronize to PC Manual Manual time setting Time management Internet Time Server Synchronize to Time Server Day light saving Active-X SDK support HTTP Rev.1.0(Nov., 2011)

  • Page 9: Applications Of Onsip O2Dp7

    ’ ’ 1.3. Applications of ONSIP O2DP7  Security surveillance (buildings, stores, manufacturing facilities, parking lots, banks, government facilities, military, etc.) Remote monitoring (hospitals, kindergartens, traffic, public areas, etc.) Teleconference (Bi-directional audio conference). Remote Learning, Internet broadcasting Weather and environmental observation ...

  • Page 10: Product Description

    ’ ’ 2. Product Description 2.1. Contents The product package contains followings: Contents Description Remarks ONSIP O2DP7 IP camera ONSIP O2DP7 main unit Default built in standard PoE module 12VDC Adaptor Power Adaptor (IEEE802.3af) (Optional item) Embedded Mounting bracket Standard ceiling mount bracket (Optional item) Software &...

  • Page 11: Product Preview

    ’ 2.2. Product Preview 2.2.1. Preview CMS Software ONSIP O2DP7 IP-Installer (Speco-NVR) PC software to view and record the A/V streaming data transmitted PC software to allocate an IP (Megapixel) IP Camera from IP camera. address to the IP Camera...

  • Page 12: Physical Description

    ’ ’ 2.3. Physical description 2.3.1. External View Figure 2-1. External view of ONSIP O2DP7 2.3.2. Rear panel Sensor In Relay Out Video Out Serial (pin 1 Mic/Line In Line Out DC In at leftmost) Figure 2-2. Rear panel of ONSIP O2DP7 Rev.1.0(Nov., 2011)

  • Page 13: Functional Description

    ’ ’ 2.4. Functional Description  DC 12V: Power input for supplying 12V DC power.  Caution: If ONSIP O2DP7 is powered by PoE, do not plug in DC Jack with active DC power into DC power connector.  MIC/LINE IN Connect external audio source or microphone.
  • Page 14 ’ ’ Description Misc. Not used Not used RxD (Connect to TxD of the other end) TxD (RxD (Connect to RxD of the other end)) For debugging & factory use only. Ground of RS-232C  ALARM IN/OUT and Composite Video Output ...
  • Page 15 ’ ’ sensor devices can be connected in parallel. Pho to Coup ler NO/ NCType Op en Co llec to rTyp e Sen so r1+ Sen so r Sensor Devic e Devic e Sen so r1- + 12V Sen so r Sen so r Po wer Po wer...
  • Page 16 ’ ’ Figure 2-6 Factory Default switch of ONSIP O2DP7 Caution: Restoring the factory default will erase all settings. Rev.1.0(Nov., 2011)

  • Page 17: On Site Installation

    ’ ’ 3. On Site Installation 3.1. Please follow through the procedures in the order of the numbers for each procedure. Mounting Knob Holes . Fix the mounting bracket. Mounting Bracket . Seat the IP camera onto the mounting Mounting Knobs bracket.

  • Page 18: Embedded Mount Bracket

    ’ ’ 3.2. Please follow through the procedures in the order of the numbers for each procedure. . Place the bracket holder above the ceiling panel through prepared hole. Bracket Holder . Prepare a 165mm diameter hole on the Ceiling Panel ceiling Recessed Mounting .
  • Page 19 ’ ’ Mounting Knob Holes Mounting Knobs Make sure to align the positions of the “ mounting knobs” and “ mounting knob holes” when you plug in the IP camera into the mounting bracket. Once it is firmly plugged in, twist the IP camera to the right until it is locked.

  • Page 20: Getting Started

    ’ ’ 4. Getting Started Brief information for first time operation of ONSIP O2DP7 is provided in this chapter. 4.1. PC Requirement Audio/Video streaming data received from ONSIP O2DP7 can be displayed or stored in a PC running client programs. Minimum requirement of the PC is described below: Recommended Remark Pentium IV 3G...

  • Page 21: Quick Installation Guide

    ’ ’ 4.2. Quick Installation Guide 1. Connect PC and ONSIP O2DP7 to network. 1) Prepare a PC to run programs for the installation and video connection (PC is needed to assign IP address to ONSIP O2DP7) 2) In case of using PoE, connect the PC and ONSIP O2DP7 to the network using one of the following ways.
  • Page 22 ’ ’ 2. Install Speco-NVR Speco-NVR is a multi-channel CMS program for to IP camera or Video server. Install Speco-NVR on remote PC to connect to these products. It is needed to assign connection information to Speco-NVR program before connection.
  • Page 23 ’ ’ Click on the field in ③ for sorting and rearranging the list. Select network mode that best suits from the drop down list in ⑤ . You can choose either Static or ADSL and Auto (DHCP), respectively. If ADSL and Auto are selected, the fields in ⑥ is deactivated.
  • Page 24 Note : Active-X module should be installed on your PC before actual connection. If your PC is not connected to the internet, you cannot download Active-X module. Most convenient way of installing the Active-X module is installing Speco-NVR which is available from the CD or our web site.
  • Page 25 SAVE button. You can see the live video when you click the live view button as below. When you exit Speco-NVR, you have to input the ID/PW, admin/1234. Details for the Speco-NVR can be found in [Speco-NVR User’s Guide].
  • Page 26 ’ ’ 4. Additional settings through connection to the Admin Page All the parameters of new IP camera follows factory default values. For more sophisticated target application it is needed to change parameters. The admin page can be connected through ”http://IP_address:HTTP_port_number ”/admin.htm It is needed to enter ID and password of the administrator.

  • Page 27: Trouble Shooting

    If PoE is not applied, the power and network connection should be made through separate cables. It is recommended to use DC adaptor supplied by Speco Technology for the feeding of the power. In case of replacing the DC power supply, make sure that the power supply meets with the power requirement of the IP camera to prevent damage or malfunction.

  • Page 28: Cannot Connect To The Video

    ’ ’ 5.2. Cannot connect to the Video Check the status of the network connection through PING test. Try the following on your PC : Start > Run > Cmd > Ping IP address (Ex : Ping 172.16.42.51) If “Reply from ~”...

  • Page 29: Windows Vista Or Windows 7

    5.3. Windows Vista or Windows 7 Windows Vista and Windows 7 users need to configure UAC (User Access Control) and Privilege Level for proper recording and still video capture in Speco-NVR and Web Viewer. <Windows Vista> 1. UAC (User Access Control) configuration 1) Double-click “User Accounts”...
  • Page 30 ’ ’ <Windows 7> 1. UAC (User Access Control) configuration 1) Double-click “User Accounts” in control panel 2) Double-click “Change User Account Control setting” 3) Set to “Never notify” Rev.1.0(Nov., 2011)
  • Page 31 ’ ’ 2. Privilege Level Control 1) Select “NVR” icon on the desktop 2) Click right mouse button and select “properties” 3) Check “Privilege Level” in “Compatibility” tab Rev.1.0(Nov., 2011)

  • Page 32: Technical Assistance

    ’ ’ 5.4. Technical Assistance If you need any technical assistance, please contact your dealer. For immediate service please provide the following information. 1. Model name 2. MAC address and Registration number 3. Purchase date 4. Description of the problem 5.
