Speco ONSIP OD8 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
'
'
O
N
S
I
P
O
D
8
O
w
n
e
r
s
O
N
S
I
P
O
D
8
O
w
n
e
r
s
ONSIP OD8
M
a
n
u
a
l
M
a
n
u
a
l
Rev.1.0(Nov., 2011)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ONSIP OD8 and is the answer not in the manual?

Questions and answers

Related Manuals for Speco ONSIP OD8

Summary of Contents for Speco ONSIP OD8

  • Page 1 ’ ’ ONSIP OD8 Rev.1.0(Nov., 2011)
  • Page 2 ’ ’ Directions Be careful not to cause any physical damage by dropping or throwing ONSIP OD8. Especially keep the device out of reach from children. Do not disassemble ONSIP OD8. No After Service is assumed when disassembled. Use only the power adapter provided with ONSIP OD8.
  • Page 3 ’ ’ Caution Any changes or modifications to this device could void the warranty. Revision History Date Revision Details 2011-11-01 First manual revision creation. Rev.1.0(Nov., 2011)

  • Page 4: Table Of Contents

    Contents ................... 4 1. Introduction ................... 5 1.1. Overview ....................5 1.2. Specification ....................6 1.3. Applications of ONSIP OD8 ................8 2. Product Description................. 9 2.1. Contents ....................9 2.2. Product Preview ..................10 2.3. Physical description .................. 11 2.4.

  • Page 5: Introduction

    It enables real time transmission of synchronized video of up to D1 pixels and audio data. Remote clients can connect to ONSIP OD8 for the real time video/audio data through various client solutions running on PC, PDA or mobile phones. Real time 2-way communication is available through bidirectional audio communication feature.

  • Page 6: Specification

    Upgrade Firmware upgrade over IP network Administration Remote administration over IP network Web Viewer Simple viewing over internet explorer Client & Viewer Speco-NVR Standard CMS software Dynamic IP support DDNS support Supported Video/Audio stream encryption ID and Password protection Security...
  • Page 7 ’ ’ Sync to PC Synchronize to PC Manual Manual time setting Time management Internet Time Server Synchronize to Time Server Day light saving Active-X SDK support HTTP Rev.1.0(Nov., 2011)

  • Page 8: Applications Of Onsip Od8

    ’ ’ 1.3. Applications of ONSIP OD8  Security surveillance (buildings, stores, manufacturing facilities, parking lots, banks, government facilities, military, etc.)  Remote monitoring (hospitals, kindergartens, traffic, public areas, etc.)  Teleconference (Bi-directional audio conference). Remote Learning, Internet broadcasting ...

  • Page 9: Product Description

    ’ 2. Product Description 2.1. Contents The product package contains followings: Contents Description Remarks ONSIP OD8 IP camera ONSIP OD8 main unit Default built in standard PoE module Power Adaptor (IEEE802.3af) Embedded Mounting bracket Standard ceiling mount bracket (Optional item) Software &...

  • Page 10: Product Preview

    ’ ’ 2.2. Product Preview 2.2.1. Preview CMS Software ONSIP OD8 IP-Installer (Speco-NVR) PC software to view and record the A/V streaming data transmitted PC software to allocate an IP IP Camera from IP camera. address to the IP Camera...

  • Page 11: Physical Description

    ’ ’ 2.3. Physical description 2.3.1. External View Figure 2-1. External view of ONSIP OD8 2.3.2. Rear panel Mic/Line In Line Out Serial (pin 1 at leftmost) Figure 2-2. Rear panel of ONSIP OD8 Rev.1.0(Nov., 2011)

  • Page 12: Functional Description

    100Mbps Ethernet connector (RJ-45) with PoE standard (802.3af). 2 LEDs on the Ethernet connector shows the status of ONSIP OD8 as the followings: Status LED (Dual Color - Red/Green): It will be lit in green or red depending on the status.
  • Page 13 A switch provided for returning the IP camera to factory default state. Open the dome cover to access the switch. Press the switch for a few seconds while power is applied. Figure 2-6 Factory Default switch of ONSIP OD8 Caution: Restoring the factory default will erase all settings.

  • Page 14: On Site Installation

    ’ ’ 3. On Site Installation 3.1. Please follow through the procedures in the order of the numbers for each procedure. Mounting Knob Holes . Fix the mounting bracket. Mounting Bracket . Seat the IP camera onto the mounting Mounting Knobs bracket.

  • Page 15: Embedded Mount Bracket

    ’ ’ 3.2. Please follow through the procedures in the order of the numbers for each procedure. . Place the bracket holder above the ceiling panel through prepared hole. Bracket Holder . Prepare a 165mm diameter hole on the Ceiling Panel ceiling Recessed Mounting .
  • Page 16 ’ ’ Mounting Knob Holes Mounting Knobs Make sure to align the positions of the “mounting knobs” and “mounting knob holes” when you plug in the IP camera into the mounting bracket. Once it is firmly plugged in, twist the IP camera to the right until it is locked.

  • Page 17: Getting Started

    Brief information for first time operation of ONSIP OD8 is provided in this chapter. 4.1. PC Requirement Audio/Video streaming data received from ONSIP OD8 can be displayed or stored in a PC running client programs. Minimum requirement of the PC is described below:...

  • Page 18: Quick Installation Guide

    (PC is needed to assign IP address to ONSIP OD8) 2) In case of using PoE, connect the PC and ONSIP OD8 to the network using one of the following ways. If your LAN Switch does not support standard PoE, connect...
  • Page 19 ’ ’ 2. Install Speco-NVR Speco-NVR is a multi-channel CMS program for to IP camera or Video server. Install Speco-NVR on remote PC to connect to these products. It is needed to assign connection information to Speco-NVR program before connection.
  • Page 20 ’ ’ Click on the field in ③ for sorting and rearranging the list. Select network mode that best suits from the drop down list in ⑤. You can choose either Static or ADSL and Auto (DHCP), respectively. If ADSL and Auto are selected, the fields in ⑥ is deactivated.
  • Page 21 3. Remote video connection to ONSIP OD8 1) Connection through Web Viewer Web Viewer offers simplest way of video connection to ONSIP OD8. For video connection, enter the IP address of ONSIP OD8 in the URL window of Internet Explorer as : Can be omitted the [e.g.] Port 80...
  • Page 22 SAVE button. You can see the live video when you click the live view button as below. When you exit Speco-NVR, you have to input the ID/PW, admin/1234. Details for the Speco-NVR can be found in [Speco-NVR User’s Guide].
  • Page 23 ’ ’ 4. Additional settings through connection to the Admin Page All the parameters of new IP camera follows factory default values. For more sophisticated target application it is needed to change parameters. The admin page can be connected through ”http://IP_address:HTTP_port_number”/admin.htm It is needed to enter ID and password of the administrator.

  • Page 24: Trouble Shooting

    If PoE is not applied, the power and network connection should be made through separate cables. It is recommended to use DC adaptor supplied by Speco Technology for the feeding of the power. In case of replacing the DC power supply, make sure that the power supply meets with the power requirement of the IP camera to prevent damage or malfunction.

  • Page 25: Cannot Connect To The Video

    ’ ’ 5.2. Cannot connect to the Video Check the status of the network connection through PING test. Try the following on your PC : Start > Run > Cmd > Ping IP address (Ex : Ping 172.16.42.51) If “Reply from ~”...

  • Page 26: Windows Vista Or Windows 7

    5.3. Windows Vista or Windows 7 Windows Vista and Windows 7 users need to configure UAC (User Access Control) and Privilege Level for proper recording and still video capture in Speco-NVR and Web Viewer. <Windows Vista> 1. UAC (User Access Control) configuration 1) Double-click “User Accounts”...
  • Page 27 ’ ’ <Windows 7> 1. UAC (User Access Control) configuration 1) Double-click “User Accounts” in control panel 2) Double-click “Change User Account Control setting” 3) Set to “Never notify” Rev.1.0(Nov., 2011)
  • Page 28 ’ ’ 2. Privilege Level Control 1) Select “NVR” icon on the desktop 2) Click right mouse button and select “properties” 3) Check “Privilege Level” in “Compatibility” tab Rev.1.0(Nov., 2011)

  • Page 29: Technical Assistance

    ’ ’ 5.4. Technical Assistance If you need any technical assistance, please contact your dealer. For immediate service please provide the following information. 1. Model name 2. MAC address and Registration number 3. Purchase date 4. Description of the problem 5.
