- Page 1 Redbox Embedders & De-Embedders User Handbook RB-VHDMA8 3G/HD/SD-SDI De-Embedder, 8 Channel Analogue Outputs RB-VHEMA8 3G/HD/SD-SDI Embedder, 8 Channel Analogue Inputs RB-VHCMA4 3G/HD/SD-SDI Embedder & De-Embedder, 4 Channel Analogue I/O RB-VHCMD16 3G/HD/SD-SDI Embedder & De-Embedder, 16 Channel Digital I/O...
- Page 2 Information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. Sonifex Ltd shall not be liable for any loss or damage whatsoever arising from the use of information or any error contained in this manual.
-
Page 3: Table Of Contents
Installation Information Atmosphere Electromagnetic Radiation Fitting Redboxes WEEE & RoHS Directives - Sonifex Statement Redbox Audio Embedders & De-Embedders RB-VHDMA8 3G/HD/SD-SDI De-Embedder, 8 Channel Analogue Outputs RB-VHEMA8 3G/HD/SD-SDI Embedder, 8 Channel Analogue Inputs RB-VHCMA4 3G/HD/SD-SDI Embedder & De-Embedder 4 Channel Analogue I/O RB-VHCMD16 3G/HD/SD-SDI Embedder &... - Page 4 CONTENTS Audio Connections Analogue Audio Inputs Audio Input Gain Adjustment RB-VHEMA8 D-type Pin-out Control Modes Bank Mode Channel Mode Changing Control Mode Embedding Bank Mode Channel Mode SD & 24-bit Audio Deleting Audio Groups Technical Specification For RB-VHEMA8 Remote Interface Commands & Responses Protocol Command Format Remote Control Commands RB-VHCMA4 3G/HD/SD-SDI Embedder &...
- Page 5 CONTENTS Control Modes Bank Mode Channel Mode Changing Control Mode Embedding Bank Mode Channel Mode SD & 24-bit Audio De-Embedding Bank Mode Channel Mode Deleting Audio Groups Technical Specification For RB-VHCMD16 Remote Interface Commands & Responses Protocol Command Format Remote Control Commands Common Specifications For RB-VHEMA8, RB-VHDMA8, RB-VHCMA4 &...
- Page 6 FIGURES Figures Fig A: Packing List Fig B: Power Connections Fig C: Mains Lead Table Fig D: RB-RK3 Large Redbox Rear Rack-mount Kit Fig 2-1: RB-VHDMA8 System Block Diagram Fig 2-2: RB-VHDMA8 Front Panel Fig 2-3: RB-VHDMA8 Rear Panel Fig 3-1: RB-VHEMA8 Block Diagram Fig 3-2: RB-VHEMA8 Front Panel Fig 3-3: RB-VHEMA8 Rear Panel Fig 4-1: RB-VHCMA4 System Block Diagram...
-
Page 7: Warranty
WARRANTY Warranty Warranty and Liability Important: the purchaser is advised to read this clause The Company agrees to repair or (at its discretion) replace Goods which are found to be defective (fair wear and tear excepted) and which are returned to the Company within 12 months of the date of despatch provided that each of the following are satisfied: notification of any defect is given to the Company immediately upon its... - Page 8 WARRANTY The Company accepts liability: for death or personal injury to the extent that it results from the negligence of the Company, its employees (whilst in the course of their employment) or its agents (in the course of the agency); (ii) for any breach by the Company of any statutory undertaking as to title, quiet possession and freedom from encumbrance.
-
Page 9: Unpacking The Redbox Embedder/De-Embedder
Sonifex Ltd in the UK. For your own records you should write down the serial number (which can be found on the rear of the Redbox Embedder/De-embedder. -
Page 10: Safety Information
– this is a legal requirement. If no moulded plug has been supplied with your Redbox Embedder/De-embedder, please contact your supplier, because an IEC connector is always supplied from the Sonifex factory. If for any reason, you need to use the Redbox Embedder/De-embedder with a different power cable, you should use the following wiring guidelines. -
Page 11: Ordering The Correct Mains Lead
SAFETY INFORMATION Ordering the Correct Mains Lead When ordering a Redbox from Sonifex, it is helpful if you can specify your required operating voltage and mains lead. After the product code add: UK, for 230V, UK 3 pin to IEC lead... -
Page 12: Weee & Rohs Directives - Sonifex Statement
It gives a contact for individuals who are unsure about the correct procedure when the product has reached its “end of use”. Sonifex Ltd will be happy to give you information about local organisations that can reprocess the products, or alternatively all products that have reached “end of use” can be returned to Sonifex and will be reprocessed correctly free of charge. -
Page 13: Redbox Audio Embedders & De-Embedders
The de-embedding channel routing is controlled via the front panel buttons and indicators. There is also LED indication for SDI input status and audio group presence. The unit can be remote controlled via Ethernet or serial port connections using the Sonifex SCi software. -
Page 14: Rb-Vhcma4 3G/Hd/Sd-Sdi Embedder & De-Embedder 4 Channel
There is also LED indication for SDI input status and audio group presence. The unit can be remote controlled via Ethernet or serial port connections using the Sonifex SCi software. It has a triple rate SDI receiver with automatic input rate detection and equalisation along with two re-clocked and individually buffered SDI outputs. -
Page 15: Embedding And De-Embedding Overview
There is also LED indication for SDI input status and audio group presence. The unit can be remote controlled via Ethernet or serial port connections using the Sonifex SCi software. It has a triple rate SDI receiver with automatic input rate detection and equalisation along with two re-clocked and individually buffered SDI outputs. -
Page 16: Rb-Vhdma8 3G/Hd/Sd-Sdi De-Embedder, 8 Channel Analogue Outputs
The de-embedding channel routing is controlled via the front panel buttons and indicators. There is also LED indication for SDI input status and audio group presence. The unit can be remote controlled via Ethernet or serial port connections using the Sonifex SCi software. -
Page 17: Front Panel Indicators & Controls
R B - V H D M A 8 Front Panel Indicators & Controls Power BANK BANK GROUP GROUP STATUS Button Channel Button Channel Button Fig 2-2: RB-VHDMA8 Front Panel Power LED The POWER LED illuminates whilst internal power is present within the unit. If this indicator is not on, the most likely reason is simply the absence of mains power, but under fault conditions it may also indicate a ruptured mains fuse or a problem with the internal power supply module. -
Page 18: Rear Panel Connections
2A, 5 x 20mm SB fuse is used. The Earth pin MUST be connected to ensure safety. Remote Control The unit can be controlled remotely either by serial RS-232 or Ethernet using the Sonifex SCi software. Using remote control allows the user to monitor the status of the unit and also set various options and settings not available via the front panel. - Page 19 RS232 signal levels using a straight-through cable. The default format is 19200 baud with 8 data bits, even parity and 1 stop bit. Sonifex SCi software, when installed on a suitable PC, provides straightforward graphical access to all remote control and configuration options via both RS232 and Ethernet interfaces.
-
Page 20: Audio Connections
R B - V H D M A 8 The Network connectors pin assignations are as follows: Network Connector (RJ-45) Pin No. Function Transmit Data (Positive) Transmit Data (Negative) Receive Data (Positive) No connection No connection Receive Data (Negative) No connection No connection SDI Input The SDI input is connected using a single female BNC and has a 75Ω... -
Page 21: Audio Output Gain Adjustment
R B - V H D M A 8 Full Scale Setting The analogue output full-scale settings, which determine the full-scale 0dBFS level for the digital audio, are set internally via jumpers. They are factory set to +18dBu by default. Full-scale Settings Jumper +12dBu... -
Page 22: Control Modes
R B - V H D M A 8 Control Modes There are two modes available to control the de-embedding channel routing process. These are the BANK mode and the CHANNEL mode. Bank Mode In Bank mode, audio is routed on a per bank basis, so when controlling de-embedding a group of audio is selected to be sent to a bank. -
Page 23: Channel Mode
R B - V H D M A 8 In this mode, the channels of the group are mapped directly to the bank channels. For example channel 1 in the selected group is de-embedded to channel 1 of the selected bank. -
Page 24: Technical Specification For Rb-Vhdma8
R B - V H D M A 8 Technical Specification For RB-VHDMA8 Front Panel Controls & Indicators De-embed Bank Select: Bank 1 or 2 Bank Channel Select: Channels 1, 2, 3 or 4 Group Select: Groups 1, 2, 3 or 4 Group Channel Select: Group channels 1,2,3 or 4 Status:... -
Page 25: Remote Interface Commands & Responses Protocol
R B - V H D M A 8 Remote Interface Commands & Responses Protocol Sonifex SCi remote control software handles all communication with the unit via a convenient graphical user interface. However, this protocol is provided for those users who wish to develop their own remote control applications or communicate with the unit using a text-based terminal program. - Page 26 R B - V H D M A 8 Command Description Response DMB:b,e De-Embed Bank Enable ACK: b is the group (0 to 3) e is the option 0 = off 1 = on DMR:b[,bc],g[,gc] De-Embed Route Control ACK: b is the bank (0 to 3) bc is the bank channel (0 to 3) –...
-
Page 27: Rb-Vhema8 3G/Hd/Sd-Sdi Embedder, 8 Channel Analogue Inputs
The embedding channel routing is controlled via the front panel buttons and indicators. There is also LED indication for SDI input status and audio group presence. The unit can be remote controlled via Ethernet or serial port connections using the Sonifex SCi software. -
Page 28: Front Panel Indicators & Controls
R B - V H E M A 8 Front Panel Indicators & Controls Power BANK BANK GROUP GROUP STATUS Button Channel Button Channel Button Fig 3-2: RB-VHEMA8 Front Panel Power LED The POWER LED illuminates whilst internal power is present within the unit. If this indicator is not on, the most likely reason is simply the absence of mains power, but under fault conditions it may also indicate a ruptured mains fuse or a problem with the internal power supply module. -
Page 29: Rear Panel Connections
2A, 5 x 20mm SB fuse is used. The Earth pin MUST be connected to ensure safety. Remote Control The unit can be controlled remotely either by serial RS-232 or Ethernet using the Sonifex SCi software. Using remote control allows the user to monitor the status of the unit and also set various options and settings not available via the front panel. -
Page 30: Ethernet
RS232 signal levels using a straight-through cable. The default format is 19200 baud with 8 data bits, even parity and 1 stop bit. Sonifex SCi software, when installed on a suitable PC, provides straightforward graphical access to all remote control and configuration options via both RS232 and Ethernet interfaces. -
Page 31: Sdi Input
R B - V H E M A 8 SDI Input The SDI input is connected using a single female BNC and has a 75Ω input impedance. It is a triple rate SDI receiver with automatic input rate detection and equalisation. It supports the full range of 3G, SD and HD standards from NTSC and PAL up to 1080p 60Hz. -
Page 32: Rb-Vhema8 D-Type Pin-Out
R B - V H E M A 8 RB-VHEMA8 D-type Pin-out Pin No. Function Function Embed Bank 1 Embed Bank 2 Channel 1+ Channel 1+ Channel 1- Channel 1- Channel 1 Ground Channel 1 Ground Channel 2+ Channel 2+ Channel 2- Channel 2- Channel 2 Ground... -
Page 33: Embedding
R B - V H E M A 8 after this time and the button can be released. Bank mode is in use when both the BANK CHANNEL and GROUP CHANNEL button LEDs are not lit. Conversely, when Channel mode is in use these two LEDs are lit. -
Page 34: Sd & 24-Bit Audio
R B - V H E M A 8 To enable embedding to this group and channel, both the GROUP and GROUP CHANNEL must be enabled. This is indicated by the button LED being lit green. If either are red, then simply enable them by holding down the relevant button for two seconds. -
Page 35: Technical Specification For Rb-Vhema8
R B - V H E M A 8 Technical Specification For RB-VHEMA8 Front Panel Controls & Indicators Embed Bank Select: Bank 1 or 2 Bank Channel Select: Channels 1, 2, 3 or 4 Group Select: Groups 1, 2, 3 or 4 Group Channel Select: Group channels 1,2,3 or 4 Status:... -
Page 36: Remote Interface Commands & Responses Protocol
R B - V H E M A 8 Remote Interface Commands & Responses Protocol Sonifex SCi remote control software handles all communication with the unit via a convenient graphical user interface. However, this protocol is provided for those users who wish to develop their own remote control applications or communicate with the unit using a text-based terminal program. - Page 37 R B - V H E M A 8 Command Description Response EMG:o,g,e Embed Group Enable ACK: o is the output (0 or 1) g is the group (0 to 3) e is the option 0 = off 1 = on EMR:o,g[,gc],b[,bc] Embed Route Control ACK:...
- Page 38 R B - V H E M A 8 Command Description Response SDB:o,e SD Audio Sample Width ACK: o is the output (0 or 1) e is enable 0 = 20-bit 1 = 24-bit SRQ: Status Request UID: Unit ID UID:RB-VHEMA8 VER: Version information...
-
Page 39: Analogue I/O
There is also LED indication for SDI input status and audio group presence. The unit can be remote controlled via Ethernet or serial port connections using the Sonifex SCi software. It has a triple rate SDI receiver with automatic input rate detection and equalisation along with two re-clocked and individually buffered SDI outputs. -
Page 40: Front Panel Indicators & Controls
R B - V H C M A 4 Front Panel Indicators & Controls Power BANK BANK GROUP GROUP STATUS Button Channel Button Channel Button Fig 4-2: RB-VHCMA4 Front Panel Power LED The POWER LED illuminates whilst internal power is present within the unit. If this indicator is not on, the most likely reason is simply the absence of mains power, but under fault conditions it may also indicate a ruptured mains fuse or a problem with the internal power supply module. - Page 41 R B - V H C M A 4 De-Embed The BANK CHANNEL button and its indicators are only used when the unit is operating in Channel mode and are used to select the audio output bank channel when controlling the de-embedding channel routing.
-
Page 42: Rear Panel Connections
2A, 5 x 20mm SB fuse is used. The Earth pin MUST be connected to ensure safety. Remote Control The unit can be controlled remotely either by serial RS-232 or Ethernet using the Sonifex SCi software. Using remote control allows the user to monitor the status of the unit and also set various options and settings not available via the front panel. - Page 43 RS232 signal levels using a straight-through cable. The default format is 19200 baud with 8 data bits, even parity and 1 stop bit. Sonifex SCi software, when installed on a suitable PC, provides straightforward graphical access to all remote control and configuration options via both RS232 and Ethernet interfaces.
-
Page 44: Audio Connections
R B - V H C M A 4 The Network connectors pin assignations are as follows: Network Connector (RJ-45) Pin No. Function Transmit Data (Positive) Transmit Data (Negative) Receive Data (Positive) No connection No connection Receive Data (Negative) No connection No connection SDI Input The SDI input is connected using a single female BNC and has a 75Ω... -
Page 45: Analogue Audio Outputs
R B - V H C M A 4 Full Scale Setting The analogue input full-scale settings, which determine the full-scale 0dBFS level for the digital audio, are set internally via jumpers. They are factory set to +18dBu by default. Full-scale Settings Jumper +12dBu... -
Page 46: Rb-Vhcma4 D-Type Pin-Out
R B - V H C M A 4 RB-VHCMA4 D-type Pin-out Pin No. Function Function De-Embed Bank Embed Bank Channel 1+ Channel 1+ Channel 1- Channel 1- Channel 1 Ground Channel 1 Ground Channel 2+ Channel 2+ Channel 2- Channel 2- Channel 2 Ground Channel 2 Ground... -
Page 47: Changing Control Mode
R B - V H C M A 4 Changing Control Mode To switch between Bank and Channel control modes, simultaneously press and hold the GROUP CHANNEL and BANK CHANNEL buttons for 5 seconds. The mode will switch after this time and the button can be released. Bank mode is in use when both the BANK CHANNEL and GROUP CHANNEL button LEDs are not lit. -
Page 48: Sd & 24-Bit Audio
R B - V H C M A 4 To enable embedding to this group and channel, both the GROUP and GROUP CHANNEL must be enabled. This is indicated by the button LED being lit green. If either are red, then simply enable them by holding down the relevant button for two seconds. -
Page 49: Channel Mode
R B - V H C M A 4 Cycling through the banks using the BANK button, allows the user to determine which banks are currently enabled for de-embedding and will also show the source group for that bank. Channel Mode In channel mode, de-embedding is controlled on a per channel basis. -
Page 50: Technical Specification For Rb-Vhcma4
R B - V H C M A 4 Technical Specification For RB-VHCMA4 Front Panel Controls & Indicators Bank Select: De-embed bank or Embed bank Bank Channel Select: Channels 1, 2, 3 or 4 Group Select: Groups 1, 2, 3 or 4 Group Channel Select: Group channels 1,2,3 or 4 Status:... -
Page 51: Remote Interface Commands & Responses Protocol
4 channel analogue I/O Remote Interface Commands & Responses Protocol Sonifex SCi remote control software handles all communication with the unit via a convenient graphical user interface. However, this protocol is provided for those users who wish to develop their own remote control applications or communicate with the unit using a text-based terminal program. - Page 52 R B - V H C M A 4 Command Description Response DWN: Initiates a Firmware Update EMC:o,g,c,e Embed Group Channel Enable ACK: This is only used when operating in channel mode o is the output (0 or 1) g is the group (0 to 3) c is the channel (0 to 3) e is the option 0 = off...
- Page 53 R B - V H C M A 4 Command Description Response DMR:b[,bc],g[,gc] De-Embed Route Control ACK: b is the bank (0 to 3) bc is the bank channel (0 to 3) – only in channel mode g is the group (0 to 3) gc is the group channel (0 to 3) –...
- Page 54 R B - V H C M A 4 Command Description Response SDB:o,e SD Audio Sample Width ACK: o is the output (0 or 1) e is enable 0 = 20-bit 1 = 24-bit SRQ: Status Request UID: Unit ID UID:RB-VHEMA8 VER: Version information...
-
Page 55: Rb-Vhcmd16 3G/Hd/Sd-Sdi Embedder & De-Embedder
There is also LED indication for SDI input status and audio group presence. The unit can be remote controlled via Ethernet or serial port connections using the Sonifex SCi software. It has a triple rate SDI receiver with automatic input rate detection and equalisation along with two re-clocked and individually buffered SDI outputs. -
Page 56: Front Panel Indicators & Controls
INTRODUCTION Front Panel Indicators & Controls Power BANK BANK FUNCTION GROUP GROUP STATUS Button Channel Button Button Channel Button Fig 5-2: RB-VHCMD16 Front Panel Power LED The POWER LED illuminates whilst internal power is present within the unit. If this indicator is not on, the most likely reason is simply the absence of mains power, but under fault conditions it may also indicate a ruptured mains fuse or a problem with the internal power supply module. - Page 57 R B - V H C M D 1 6 Function Button This button is used to select between embedding or de-embedding control. Group Embed The GROUP button and its indicators are used to select the group number with which to embed the analogue input channels to.
-
Page 58: Rear Panel Connections
2A, 5 x 20mm SB fuse is used. The Earth pin MUST be connected to ensure safety. Remote Control The unit can be controlled remotely either by serial RS-232 or Ethernet using the Sonifex SCi software. Using remote control allows the user to monitor the status of the unit and also set various options and settings not available via the front panel. - Page 59 RS232 signal levels using a straight-through cable. The default format is 19200 baud with 8 data bits, even parity and 1 stop bit. Sonifex SCi software, when installed on a suitable PC, provides straightforward graphical access to all remote control and configuration options via both RS232 and Ethernet interfaces.
-
Page 60: Audio Connections
INTRODUCTION the network and the unit cannot retrieve a valid IP address after 45 seconds it will default to a static address. This static address is set to 192.168.0.100 by default but can be altered through SCi using the serial port connection. If DHCP is not required then this can also be disabled through SCi using the serial port connection. -
Page 61: Audio Input And Output Gain Adjustment
R B - V H C M D 1 6 The digital inputs are sample rate converted to 48kHz so that the audio is synchronous to the video input signal. This can be disabled via a remote control option. The digital outputs are always output at 48kHz and will be synchronous to the video signal. No sample rate conversion is applied to the digital outputs. -
Page 62: Control Modes
R B - V H C M D 16 Digital 2 In Ground Digital 6 In Ground Digital 2 Out+ Digital 6 Out+ Digital 2 Out- Digital 6 Out- Digital 2 Out Ground Digital 6 Out Ground Digital 3 In+ Digital 7 In+ Digital 3 In- Digital 7 In-... -
Page 63: Embedding
R B - V H C M D 1 6 CHANNEL and GROUP CHANNEL button LEDs are not lit. Conversely, when Channel mode is in use these two LEDs are lit. When switching from Channel to Bank mode, all channel mappings are reset and no groups are selected for embedding. -
Page 64: Sd & 24-Bit Audio
R B - V H C M D 16 To enable embedding to this group and channel, both the GROUP and GROUP CHANNEL must be enabled. This is indicated by the button LED being lit green. If either are red, then simply enable them by holding down the relevant button for two seconds. -
Page 65: Channel Mode
R B - V H C M D 1 6 Cycling through the banks using the BANK button, allows the user to determine which banks are currently enabled for de-embedding and will also show the source group for that bank. Channel Mode In channel mode, de-embedding is controlled on a per channel basis. -
Page 66: Technical Specification For Rb-Vhcmd16
R B - V H C M D 16 Technical Specification For RB-VHCMD16 Front Panel Controls & Indicators Bank Select: Bank 1, 2, 3 or 4 Bank Channel Select: Channels 1, 2, 3 or 4 Function Select: De-embed or embed Group Select: Groups 1, 2, 3 or 4 Group Channel Select:... -
Page 67: Remote Interface Commands & Responses Protocol
R B - V H C M D 1 6 Remote Interface Commands & Responses Protocol Sonifex SCi remote control software handles all communication with the unit via a convenient graphical user interface. However, this protocol is provided for those users who wish to develop their own remote control applications or communicate with the unit using a text-based terminal program. - Page 68 R B - V H C M D 16 Command Description Response EMC:o,g,c,e Embed Group Channel Enable ACK: This is only used when operating in channel mode o is the output (0 or 1) g is the group (0 to 3) c is the channel (0 to 3) e is the option 0 = off...
- Page 69 R B - V H C M D 1 6 Command Description Response DMR:b[,bc],g[,gc] De-Embed Route Control ACK: b is the bank (0 to 3) bc is the bank channel (0 to 3) – only in channel mode g is the group (0 to 3) gc is the group channel (0 to 3) –...
- Page 70 R B - V H C M D 16 Command Description Response SDB:o,e SD Audio Sample Width ACK: o is the output (0 or 1) e is enable 0 = 20-bit 1 = 24-bit SRQ: Status Request UID: Unit ID UID:RB-VHEMA8 VER: Version information...
-
Page 71: Common Specifications For Rb-Vhema8, Rb-Vhdma8
CO M M O N S P E C I F I C AT I O N 6 Common Specifications For RB-VHEMA8, RB-VHDMA8, RB-VHCMA4 & RB-VHCMD16 SDI Specification SDI Input: 1 x BNC, 3G/HD/SD-SDI SDI Outputs: 2 x BNC, 3G/HD/SD-SDI, Re-clocked Impedance: 75Ω... - Page 72 CO M M O N S P E C I F I C AT I O N Serial Port: RS232, 9 way D-type Ethernet Port: 10/100Mbps, RJ-45 Fuse Rating: Anti-surge fuse 2A 20 x 5mm Physical Specifications Dimensions (Raw): 48cm (W) x 10.8cm (D*) x 4.2cm (H) (1U) 19”...
-
Page 73: Sci
7 SCi System Page Fig 7-1: SCi System Screen This page is used for the connecting and disconnecting SCi to the unit, updating the firmware in the units, displaying the current status of the unit and controlling various settings. Status Video Input Shows the current SDI input rate, video format and the audio groups status. -
Page 74: Fig 7-2: Network Settings
S C I Admin Connection This displays any connection which has “Administrator” rights to the unit. Network Status This displays the current network settings assigned to the unit. Settings General Front Panel Lock When selected, this control disables the front panel and prohibits any changes to be made via the front panel. -
Page 75: De-Embed Page
Updating The Firmware The firmware will occasionally be updated to add new features or correct any possible issues that may arise. Check for updates at: http://www.sonifex.co.uk/technical/software To update the firmware click on the button labeled “Update Firmware” and then select the downloaded firmware file. -
Page 76: Embed Page
This page allows you to configure the group sources for each of the available De-Embed banks on the unit. This page is not available on the RB-VHEMA8 unit. When in bank control mode, only the top group selection box is available for each bank. This selects the group to de-embed to all the channels in that bank. -
Page 77: Audio Inputs Page
When in channel control mode, all of the bank and channel selection boxes become available, allowing you to individually select a bank and channel to embed to each group channel. Embed Enable: This control enables embedding for the selected group. Bank/Channel: Selects the Embed bank and/or channel to embed to the group. -
Page 78: Audio Outputs Page
Gain Slide Bars: Controls the input gain or attenuation for each input channel. Can be set from -24 dB to +24 dB in 0.5 dB steps. Double clicking the gain value label at the bottom of the slide bar will set the gain to 0 dB. Link: If selected, the gain slide bars are linked together so that changing one will change the others in that bank. -
Page 79: Delay Page
Termination: Only available on the the RB-VHCMD16, these controls select the output termination from between 75 and 110Ω. Delay Page Fig 7-7: SCi Delay Screen This page allows control over the video delay through the unit. This control is only available in the newer units running firmware V2.X.X or greater. -
Page 80: Glossary
G LO S S A R Y 8 Glossary Audio Engineering Society. Attenuation The reduction of a signal level. Attenuation is usually measured in dB. Balanced Audio A way of sending audio over cable that protects it from induced interference Bayonet Neill-Concelman connector. - Page 81 G LO S S A R Y Local Area Network - scheme where several computers on the same premises are connected together so that they can exchange data. Light Emitting Diode (small lights e.g. on computers). Mega-hertz - One million cycles per second. NTSC National Television System Committee.
- Page 82 N OT E S Redbox Embedder/De-embedder User Handbook...
- Page 83 N OT E S Redbox Embedder/De-embedder User Handbook...
- Page 84 w w w . s o n i f e x . c o . u k t:+44 (0)1933 650 700 f:+44 (0)1933 650 726 s a l e s @ s o n i fe x . co. u k...
